D i s h w a s h e r
Model ESL 6114
UK
Instruction book
0 01/03

Advertisement

loading

  Related Manuals for Electrolux ESL 6114

  Summary of Contents for Electrolux ESL 6114

  • Page 1 D i s h w a s h e r Model ESL 6114 Instruction book 0 01/03...
  • Page 2: Description Of The Appliance

    Description of the appliance Water hardness adjustment Levelling spacers Upper basket stop Salt container Lower spray arm Detergent dispenser Control panel Rating plate Rinse aid dispenser 10. Large filter 11. Central filter 12. Upper spray arm 13. Upper basket The control panel IN85...
  • Page 3: The Lower Basket

    Open the door and slide out the baskets to load the dishes. The lower basket The lower basket is designed to take saucepans, lids, plates, salad bowls, cutlery etc. Serving dishes and large lids should be arranged around the edge of the basket, ensuring that the upper spray arm can turn freely.
  • Page 4: Washing Programmes

    Hot steam may escape from the appliance when opening the door immediately after the end of the programme, therefore, open the door carefully. Switch off the dishwasher by pressing the On/Off push button. Unloading the dishwasher Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down before removing from the appliance.
  • Page 5: Fixing To The Adjacent Units

    Remove all packaging before positioning the machine. If possible, position the machine next to a water tap and a drain. Building-in This dishwasher is designed to be fitted under a kitchen counter or worksurface. Attention! Carefully follow the instructions on the enclosed template for building in the dishwasher and fitting the furniture panel.
  • Page 6: Service And Spare Parts

    Guarantee Conditions Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we...
  • Page 7: Hints For Test Centres

    Hints for test centres Testing in accordance with EN 60704 must be carried out with appliance fully loaded and using the test programme (see "Washing programmes" chart). Test in accordance with EN 50242 must be carried out when the salt dispenser and rinse aid container have been filled with salt and rinse aid respectively and using the test programme (see "Washing programmes"...
  • Page 8 The Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
  • Page 9: Table Of Contents

    Items that are contaminated by petrol, paint, steel or iron debris, corrosive, acidic or alkaline chemicals must not be washed in this dishwasher. Under no circumstances should you open the door whilst the appliance is in operation. Always turn off the appliance before opening the door.
  • Page 10: Before Use

    6. Run a "Rinse and Hold" programme. Setting the water softener The dishwasher is equipped with a water softener designed to remove minerals and salts from the water supply, which would have a detrimental or adverse effect on the operation of the appliance.
  • Page 11: Filling With Rinse Aid And Adjusting The Dose

    3. For all programmes with prewash; place a portion of a further tablet on the lid of the detergent dispenser. If your dishwasher has a SID dispenser and you require a prewash, put the extra detergent into the SID dispenser and not on the lid of the detergent dispenser.
  • Page 12: Hints And Tips

    To save energy Place dishes in the machine immediately after every meal and wait until the dishwasher is full before washing. If necessary run the Rinse and Hold programme (see "Washing Programmes" chart) so that any food scraps do not become caked on the dishes while you are waiting to run the complete wash programme.
  • Page 13: Maintenance And Cleaning

    Ensure that the seals around the door, the detergent and rinse aid dispensers are cleaned regularly with a damp cloth. We recommend the use of Finish Dishwasher Cleaner every 3 months or run a 65°C wash without dishes using detergent.
  • Page 14: Something Not Working

    If after all these checks, the problem persists, contact your local Service Force Centre, quoting the model and serial number. This information can be found on the rating plate located on the right hand side of the dishwasher door. RA01 Solution The door has not been properly closed.
  • Page 15: Installation

    Water supply connections This dishwasher must be plumbed into a cold water supply. The water pressure must be within the limits given in the "Technical specifications" (Instruction Book - Part 2).
  • Page 16 This appliance complies with the following E.E.C. Directives: - 73/23 or 19.2.73 (Low Voltage Directive) and subsequent modifications; - 89/336 or 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications. 152981 19/5 Subject to change without notice 5 01/03...
