Dear Customer Thank you for choosing one of our high quality products. With this appliance you will experience the perfect combination of functional design and cutting edge technology. Convince yourself that our appliances are engineered to deliver the best per formance and control indeed we are setting the highest standards of excel lence.
Using 3 in 1 detergents Selecting the dishwashing cycle (Cycle Table) Starting a dishwashing cycle Setting the Delay Timer Switching Off the dishwasher Care and cleaning What to do if… Remedying small malfunctions If the dishwashing results are not satisfactory...
• Never sit or stand on the open door. • If the dishwasher is located in a room where there may be a frost, remove the connection hose from the tap after each use of the dishwasher.
Diagram of Appliance Diagram of Appliance Upper basket spray arm and lower spray arm Water softener unit. Salt Container Detergent Dispenser Rinse aid dispenser Control panel Rating plate Filters...
Control Panel Control Panel To use the appliance, always open the dishwasher door first. The ON/OFF button is used to turn the dishwasher on and off. Set delay Multi display The Programme buttons are used to select the desired dishwashing cycle.
– the start delay that has been set. – the estimated time remaining for the current dishwashing cycle. – what type of error has occurred with the dishwasher. The control indicators have the following meanings: 1) These control indicators are never illuminated while a dishwashing cycle is running.
Setting the Water Softener The water softener must be set manually and electronically: To avoid scale deposits on the dishes and in the dishwasher, the dishes must be washed with soft water, i.e. water with a low lime content. The water softener must be set according to the table to the water hardness in the area where you live.
Page 9
Water hardness Range °d mmol/l 51 70 9,0 12,5 43 50 7,6 8,9 37 42 6,5 7,5 29 36 5,1 6,4 23 28 4,0 5,0 19 22 3,3 3,9 15 18 2,6 3,2 11 14 1,9 2,5 4 10 0,7 1,8 below 4 below 0.7 1) The water hardness will only be indicated acoustically if the acoustic signal has been activated.
This will wash away salt water and salt crystals that have been spilt. Depending on the size of the salt granules, it can take several hours for the salt to dissolve in the water and for the control indicator for dishwasher salt to go out.
If you do not use 3in1 detergent, fill up with rinse aid: – Before using the dishwasher for the first time. – When the control indicator for rinse aid is illuminated on the control panel. Use only special rinse aid for dishwashers.
(See section “If dishwashing results are not satisfactory”.) The dosage can be set from 1 6. The dosage is pre set to “4” in the factory. 1. Open the dishwasher door. 2. Press the release button on the rinse aid compartment.
Sponges, cleaning cloths and any other objects that can absorb water must not be washed in the dishwasher. Plastic and Teflon coated dishes and pans tend to retain water droplets. These dishes and pans therefore do not dry as well as those made of china and stainless steel.
The cutlery basket can be opened out. Always make sure that you put your hand around both parts of the two part handle when removing it from the dishwasher. 1. Place the cutlery basket on a table or work surface.
Page 15
In daily use Loading / Unloading lower basket and upper basket To load and unload, pull out or push in the upper and lower baskets in the middle us ing the handle on the front of the basket. Pots, Pans, Large Plates Load larger and heavily soiled dishes and pans in the lower basket.
Page 16
In daily use Cups, Glasses, Coffee Service Load smaller, fragile crockery and long, sharp cutlery in the upper basket. • Arrange items of crockery on and under the folding cup racks so that they are offset from each other and water can reach all items.
• The row of spikes on the left of the upper basket is also in two parts and can be folded away. Spikes not folded away: place glasses, mugs etc. in the upper basket. Spikes folded away: More room for serv ing dishes.
In daily use Adding Detergent Detergents remove the dirt from dishes and cutlery. The detergent must be added before the cycle starts. Only use detergent intended for domestic dishwashers. The detergent compartment is located on the inside of the door. 1.
Concentrated detergents Today’s detergents for dishwashers are almost exclusively low alkaline concen trated detergents with natural enzymes in tablet or powder form. Using 50°C dishwashing cycles in conjunction with these concentrated deter gents reduces pollution and is good for your dishes, as these dishwashing cycles are specially matched to the dirt dissolving properties of the enzymes in con centrated detergents.
Depending upon the soiling, the temperature of the water will be automatically adjusted to between 45°C and 70°C. 4) When using this cycle, only load the dishwasher half full. 5) Test programme for Test Institutes 6) This cycle does not need any detergent.
In daily use Selecting a programme When your dishes look like this, select: an intensive programme. a normal or energy saving programme. a short programme (e.g. 30 minute pro gramme).
5. Close the door. The dishwashing cycle will begin. A light signal in the form of a dot appears at floor level. If the dishwasher is built in at high level with flush fitting cupboard doors around it, the light signal cannot be seen.
If the acoustic signal has been enabled, a continuous tone will sound for 15 sec onds at the end of the dishwashing cycle. If the dishwasher door is not opened, the acoustic signal sounds again after 3 and 6 minutes.
Care and cleaning Do not use furniture care products or aggressive cleaners. • When necessary, clean the dishwasher’s controls with a soft cloth. • Occasionally check the internal dispensers, door seal and water inlet filter (if fitted) for dirt and clean them, if necessary.
Page 25
Ensure that the flat filter does not pro trude above the base of the washing com partment. Under no circumstances may the dishwasher be used without its filters. Care and cleaning...
What to do if… What to do if… Remedying small malfunctions Before you call the Customer Care Department, please check whether – you cannot remedy the fault yourself with the help of the following fault ta – whether it is caused by faulty, electrical connections and/or faulty water con nections.
Page 27
The anti flood system has been triggered. The mains plug is not plugged A fuse in the house’s wiring system is defective. For dishwasher models with a delay start timer: A start time has been selected. What to do if… Remedy Check the tap and have it re paired, if necessary.
Page 28
What to do if… Malfunction Rust spots are visible in the dishwashing compartment. A whistling noise can be heard when washing dishes. Possible cause The dishwashing compart ment is made from rust free stainless steel. Rust spots in the dishwashing compartment are due to rust particles from external sources (rust particles from water pipes, pans, cutlery,...
The baskets for the dishes must not be overloaded. The spray arms must be free to turn. • Filters in the floor of the dishwasher are not clean or incorrectly inserted. • Good quality detergent was not used, or too little was used.
12 place settings including serving dishes 0.1 1.0 MPa (= 10 100 N/cm Also see the rating plate on the right hand side of the dishwasher’s interior door . 820 880 x 596 x 555 (H x W x D in mm)
Notes for Test Institutes Testing in accordance with EN 60704 must be carried out with the appliance fully loaded and using the test cycle (see “Cycle Table”). Tests in accordance with EN 50242 must be carried out when the salt dis penser in the water softener and the rinse aid dispenser have been filled with salt and rinse aid respectively, and using the test cycle (see “Cycle Table”).
Engineer. Installing the Dishwasher • The dishwasher must be installed on a firm floor and adjusted to ensure that it is stable and level in all directions. • To compensate for unevenness in the floor and to match the height of the ap pliance to that of surrounding units, extend the threaded feet using a screw driver.
Connecting the dishwasher Connecting to the water supply • The dishwasher can be connected to cold or hot water supplies up to max. 60°C. • The dishwasher must not be connected to open hot water appliances or in stantaneous water heaters.
• The drain hose must be fixed to the sink outlet connection using the hose clamp sup plied. Anti flood system For protection from water damage, the dishwasher is equipped with a anti flood sys tem. In the event of a fault, the safety valve in the water inlet hose immediately interrupts...
Before switching on make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. To isolate the dishwasher from the mains, remove the mains plug. Important: The plug must still be accessible after the appliance has been in stalled.
Guarantee/Customer Service Standard guarantee conditions We, AEG Electrolux, undertake that if within 12 months of the date of the pur chase this AEG Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair...
European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these coun...
Page 38
Str. Garii Progresului 2, S4, 040671 RO Industriestrasse 10, CH 5506 Mägenwil Electrolux Ljubljana d.o.o. Gerbiceva 98, 1000 Ljubljana Electrolux Slovakia s.r.o., Electrolux Domáce spot rebièe SK, Seberíniho 1, 821 03 Bratislava Electrolux Service, S:t Göransgatan 143, S 105 45 Stockholm Tarlabaþý...
Customer Care For general enquiries concerning your AEG Electrolux appliance, or for further informa tion on AEG Electrolux products please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.aeg.co.uk.
