Control/Communicator
Installation Manual

Table of Contents

General Description.............................................................................................2
Ordering Information ...........................................................................................2
Feature Definitions .......................................................................................... 3-6
Programming the LED Keypads ........................................................................ 7
Programming the NX-8 .................................................................................. 9-11
Types of Programming Data ......................................................................... 9-11
Enrolling the Modules & Keypads....................................................................11
L
Quick Start Installations ............................................................................11
Communicator Formats ....................................................................................12
Reporting Events to Phone #1, #2, & #3 .................................................... 12-15
Default Zone Types............................................................................................18
Zone Doubling....................................................................................................21
Programming the Outputs .......................................................................... 23-24
Programming Worksheets .......................................................................... 37-50
SIA and Contact ID Formats ....................................................................... 51-52
Expander Trouble Reporting Information........................................................53
Wiring Diagram ..................................................................................................54
Terminal Description .........................................................................................55
Telephone Interface Information ......................................................................56
CE Notice / Declaration .....................................................................................57
Underwriters Laboratories Information ...........................................................58
Specifications................................................................................................ Back
GE Interlogix
Gladewater, Texas
1-800-727-2339

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX-8 - Security NetworX System and is the answer not in the manual?

Questions and answers

John L. Smith
March 10, 2025

Why is the service light illuminated on my GE Security Command Center panel?

0
1 comments:
Mr. Anderson
March 10, 2025

The service light on the GE Interlogix NX-8 Security NetworX System panel is illuminated for one of the following reasons:

1. Expander Trouble – If enabled, the system reports expander trouble to the central station and illuminates the service LED on the keypad. Keypads are considered expanders.
2. Fail to Communicate – If a report fails to reach the central station, the service LED is illuminated. If enabled, a Fail to Communicate code will be reported when the next report is successfully sent.

These conditions indicate a system issue that may require troubleshooting or maintenance.
