Sony PRS-600 - Electronic Book Reader Service Manual

SERVICE MANUAL
Ver. 1.0 2009.07
Note:
Be sure to keep your PC used for service and
checking of this unit always updated with the
latest version of your anti-virus software.
In case a virus affected unit was found during
service, contact your Service Headquarters.
SONY and the SONY logo are registered trademarks of
Sony Corporation.
BBeB, BBeB Book, and their logos are trademarks of
Sony Corporation.
"Memory Stick," "Memory Stick Duo," "Memory Stick PRO
Duo," and their logos are trademarks of Sony Corporation.
Bitstream is a registered trademark, and Dutch, Font
Fusion, and Swiss are trademarks, of Bitstream Inc.
Microsoft, Windows, Windows Vista and Windows Media
are trademarks or registered trademarks of Microsoft
Corporation in the United States and / or other countries.
Macintosh and Mac OS are trademarks of Apple Inc.,
registered in the U.S. and other countries.
Adobe, the Adobe logo, Reader and PDF are either
registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
MPEG Layer-3 audio coding technology and patents
licensed from Fraunhofer IIS and Thomson.
This product includes software developed by the
OpenSSL Project for use in the OpenSSL Toolkit.
(<http://www.openssl.org/>) Copyright © 1998-2006 The
OpenSSL Project. All rights reserved. This product
includes cryptographic software written by Eric Young
(eay@cryptsoft.com). This product includes software
written by Tim Hudson (tjh@cryptsoft.com). For details on
OpenSSL License, refer to "openssl.txt" on the Reader.
All other system names and product names appearing in this
document are generally the registered trademarks or
of their respective manufacturers. Further, the trademark
trademarks TM
and registered trademark ® symbols are not
indicated throughout this document.
Program ©2009 Sony Corporation
Documentation ©2009 Sony Corporation
Sony Corporation
9-889-602-01
2009G05-1 New Mobile Division
©
2009.07 Published by Sony Techno Create Corporation
PRS-600
SPECIFICATIONS
Power source
Built-in rechargeable battery: DC 3.7 V
AC adapter: DC 5.2 V
USB
Battery life (continuous playback)
Maximum Battery: Approx. 7,500 continuous page turns when reading only *
* Measured using a fully charged battery and counting consecutive BBeB
Book and ePub format page-turns at approx 1 page per sec.
Actual battery life may vary based on usage patterns and specific device.
User available capacity
Approx. 380MB
Available memory capacity of the Reader may vary.
Operating temperature
41 to 95 °F (5 to 35 °C)
Dimensions (w/h/d)
Approx. 4 7 / × 6 7 / × 12 / inches (121 × 174.3 × 9.8 mm)
8 8 32
Mass
Approx. 10.1 oz (286 g)
Design and specifications are subject to change without notice.
FLEXIBLE CIRCUIT BOARD REPAIRING
• Keep the temperature of soldering iron around 270 °C during
repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
DIGITAL BOOK READER
US Model
Canadian Model
UK Model
French Model
German Model
Netherlands Model
