Top view
No.
Item
1
Ventilation slot
Bottom view
1
2
No. Icon
Item
1
USB 2.0 port
2
Lock switch
3
Dock connector
4
SIM card slot
Note: Display orientation may be fixed when applications
designed for a specific orientation are running. These include
games and other full-screen applications.
When making video calls, you should always hold the tablet in
landscape orientation.
Description
Provides adequate air flow to maintain a safe
operating temperature.
3
Description
Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
Locks the screen orientation.
Connects to the supplied keyboard dock.
USB port may also be used as a standard
USB port.
Accepts a 3G SIM card (configuration may
vary depending on model).
Tablet PC
1
4
3
