Top View

# Item
1 Headset Jack

Bottom View

# Item
1 Micro-B USB Port
2 Card Slot Cover
Hardware Specifications and Configurations
Figure 1-3. Top View
Table 1-3. Top View
Connects to stereo headphones.
1
2
Figure 1-4. Bottom View
Table 1-4. Bottom View
Connects to a computer or power adapter with a USB
cable.
Insert a micro SD card into the slot under this cover.
1
Description
Description
1-7
