No.
Item
3
Acer FineTrack
pointing device
4
Latch
5
Left and right buttons Function like the left and right mouse buttons.
Front view
No. Item
1
Latch
Left view
No. Icon
Item
1
Ethernet (RJ-45)
port
2
USB 2.0 port
Description
Pointing device to control cursor movement.
Secures the tablet to the keyboard dock when
closed.
1
Description
Secures the tablet to the keyboard dock when closed.
1
2
Description
Connects to an Ethernet 10/100/1000-
based network.
Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
Keyboard dock
7
