- Page 2 PREFACE EVGA created the InterView Dual Monitor System in order to make dual monitors an easier solution. InterView allows you to work on multiple documents at once. It even allows video conferencing with the built in webcam. It also allows you to flip either display...
-
Page 3: Table Of Contents
TABLE of CONTENTS PRODUCT OVERVIEW ................................5 What’s Included ..............................5 Safety Instructions ..............................6 Product Views ................................ 7 INTERVIEW SPECIFICATIONS ..............................10 InterView Technical Specifications ........................10 Preset Timing Modes ............................11 Power Management Modes ..........................11 SETTING UP INTERVIEW ................................12 Steps to Assemble InterView .......................... - Page 4 Warranty Terms and Conditions.......................... 32 COMPLIANCE INFORMATION ..............................33 FCC Notice................................33 LEGAL INFORMATION ................................34 Trademark Information ............................34 Software License Agreement ..........................34 Rights ................................... 34 Patent Protection ..............................34...
-
Page 5: Product Overview
1. PRODUCT OVERVIEW What’s Included The following items are included with InterView: InterView Monitor: Dual 17” LCD Displays InterView Control Base DC Power Adapter Dual DVI-I to DMS Cable 2 VGA to DVI-I Adapters 2 DVI-D to DVI-D Adapters Microphone Audio Cable USB Male to Male Cable Visual Guide Software Installation CD... -
Page 6: Safety Instructions
Safety Instructions Safe Environment Do not store or use the InterView in locations that are exposed to heat, extreme cold, high humidity or dusty environment. Room temperature conditions are recommended. Do not subject InterView to severe vibrations or high impact conditions. Do not allow water or other liquids to spill on or into InterView. -
Page 7: Product Views
Product Views Front View 1. InterView Control Base 2. Balance Bar 3. Integrated 3-Port USB 2.0 Hub 4. Integrated Webcam 5. 17” LCD Monitors... - Page 8 Control Base Top View 1. Power Button 2. Power Light Indicators (Left Display) 3. Power Light Indicators (Right Display) 4. Display Selection Button 5. Brightness Decrease 6. Brightness Increase 7. Auto Adjust 8. Built-in Microphone...
- Page 9 Control Base Rear View 1. USB 2.0 to PC 2. Microphone out to PC Mic-In 3. DMS Port 4. DC Power in Connector...
-
Page 10: Interview Specifications
2. INTERVIEW SPECIFICATIONS InterView Technical Specifications General Model number EVGA InterView 1700 Screen type 17’’ Wide TFT Preset display area Horizontal 14.45” Vertical 9.03” Synchronization Horizontal 31.5 kHz to 81.1 kHz Vertical 56 Hz to 76 Hz Viewing angle Horizontal 20°... -
Page 11: Preset Timing Modes
Preset Timing Modes The screen will be adjusted automatically when the signal transferred from the computer is the same as the following Preset Timing Modes. If your display mode is not listed, it is not supported by this monitor; the screen may go blank while the power LED is on. -
Page 12: Setting Up Interview
3. SETTING UP INTERVIEW Read the safety instructions before setting up the InterView. Steps to Assemble InterView 1. Place the control base on a solid horizontal surface. Pull the balance bar out from the bottom of the base: 2. Remove the cap from the base:... - Page 13 3. Remove LCD Displays from packaging and remove the cap: 4. Slowly connect display panels to control base(Front view): 5. Slowly push in the knob and turn it clockwise to secure the base and the panel:...
- Page 14 6. Open up the panel: 7. Push the balance bar back into the base:...
-
Page 15: Connecting Interview To A Pc
3.2 Connecting InterView to a PC Before setting up InterView, you must power down your computer(s). Connect the monitor to a computer(s) using the Dual DVI-I to DMS cable. Note: If you see 4 monitors please use the DVI-D adapter. Know your computers display connections: DVI-I: You can plug the DVI-I to DMS VGA: You will need to use the supplied... - Page 16 Connect the monitor to the electrical outlet using the power cord: Optional: Connect InterView to the computer with the USB cable to enable the webcam and front USB 2.0 HUB located on the monitor base. Optional: Use the audio cable to connect InterView to the MIC or Line-in input of the computer. This is required to use the built-in microphone.
-
Page 17: Plug And Play Compatibility
Power on InterView and the computer(s): 3.3 Plug and Play Compatibility You can use InterView with any Plug and Play compatible system. The system configures itself and optimizes the display’s settings. In most cases, InterView‘s installation is automatically processed unless the user intervenes. -
Page 18: How To Adjust Interview
4. HOW TO ADJUST INTERVIEW Rotating/Folding Each panel can rotate 180 degrees. The display will automatically adjust to the correct orientation. To prevent scratching flip one panel at a time and make sure there are no objects in the way. Each panel can be opened and closed 90 degrees horizontally. -
Page 19: Control Buttons
Control Buttons 1. Power Button: Powers the InterView ON or OFF 2. Panel Selection Button: Selects the monitor to be adjusted 3. Brightness Decrease: Decreases brightness levels 4. Brightness Increase: Increases brightness levels 5. Auto Adjust: Adjusts vertical position, phase, horizontal position, and pixel clock automatically Brightness Adjustment Users can adjust the monitor brightness levels from the Brightness (Up/Down) buttons. -
Page 20: System Requirements And Software Installation
Others: - Microsoft DirectX 9.0C - USB 2.0 port (required for USB Hub and Webcam) - EVGA UV+ USB Display adapter ( if 2 display output is not available) Installing the Webcam Software Some functions provided in InterView Application may not work if the driver is not installed properly. - Page 21 (Step 2) Processing Installation - Click Webcam software installation to start the installation process - Click Next, select the application you would like to install, then click Next to continue Note: For users who select to install both webcam driver and application, the installation will start from the webcam software then to the webcam driver.
- Page 22 - Installation in process, the dialogue box will automatically close when the installation completes. Installing the Webcam Driver - Click Install - Click Install...
- Page 23 - Click Finish then select the option to restart your computer after the installation completes. If you wish to restart later select the option to restart later. Note: Depending on each user’s PC system and hardware performance, it may take 10 to 15 seconds before entering to the next step, please be patient.
-
Page 24: Using The Interview Camera Application
Using the InterView Camera Application Main Panel Layout Display screen Record Snapshot Color setting page Snapshot setting page Record setting page Misc setting page... - Page 25 Color Settings Page This panel allows users to adjust the color settings by dragging the track bars. 1. Brightness adjustment 2. Contrast adjustment 3. Hue adjustment 4. Saturation adjustment 5. Sharpness adjustment 6. White balance adjustment 7. Gamma adjustment 8. Color / Gray scale 9.
- Page 26 Snapshot Settings Page The InterView webcam application allows users to capture a single photo as well as continuous shooting. In this panel, the application allows users to set snapshot functions, such as time intervals and output formats. 1. Photo quantity for continuous shooting (1-30) 2.
- Page 27 Record Settings Page This panel allows adjustments to the recording function of the webcam. 1. Select the audio device to be captured 2. Select the audio recording source. Ex: Microphone 3. Select the audio encoder to encode the audio stream 4.
- Page 28 Misc Settings Page Within this panel, users can adjust settings that control different aspects of the image. 1. Video Flip: Flips the video horizontally/vertically 2. Exposure control - Low Light: avoid under-exposure in low light environment - High Light: avoid under-exposure in high light environment. 3.
-
Page 29: Troubleshooting
6. TROUBLESHOOTING Self-Test Feature Check Self-Test Feature Check (STFC) allows users to check if the monitor works properly. Turn off both your computer and the monitor Unplug the DMS cable from the back of the computer Turn on the monitor If the monitor is functioning properly, you will see a message similar to the illustration below This box appears during normal operation if the video cable becomes disconnected or damaged. - Page 30 Perform monitor reset on "Factory Reset" Auto Adjust via OSD (ON SCREEN DISPLAY) Picture is dim or bright Adjust brightness via OSD (ON SCREEN DISPLAY) Perform monitor reset on "Display Reset" Auto Adjust via OSD (ON SCREEN DISPLAY) Screen not centered correctly ...
-
Page 31: Service Information
As a valued EVGA customer, you’ll be sure to receive a warranty that will fit your needs. The EVGA Advanced RMA (EAR) Program is a program to protect yourself and your product in the case of product failure. For more details please visit: www.evga.com/EAR... -
Page 32: Warranty Terms And Conditions
Warranty Terms and Conditions EVGA monitors are covered by a 2 Year limited warranty support as stated on the terms and conditions herein. Please also note the model number, the serial number, the date of purchase, and the outlet from which you purchased this monitor on the form attached hereto. -
Page 33: Compliance Information
The following information is provided on the device or devices covered in this document in compliance with the FCC regulations: Product name: Dual Monitor System Model number: EVGA InterViewTM 1700 Company name: EVGA® Corporation 2900 Saturn Street, Suite B Brea, California, 92821 USA... -
Page 34: Legal Information
US and other countries. Other company, products and service names may be trademarks or service marks of others. EVGA reserves the right to terminate this license if there is a violation of its terms or default by the Original Purchaser.
