Install the gimp fonts

The Command View SDM software has a dependency on availability of certain fonts. We needed to
install the fonts in: urw-fonts.tar.gz downloaded from: www.gimp.org/fonts.html. If you intend to
run the Command View GUI client on the array host, the presence of these fonts will prevent a series
of error messages when the Java Run-Time starts. Alternatively, if you access the host via a web
browser this step is optional.
Extract and install the URW fonts into
Edit /usr/X11R6/lib/X11/XF86Config to include FontPath for the installed directory. The "Files"
section of our XF86Config looks like this:
Section "Files"
# The location of the RGB database.
# file minus the extension (like ".txt" or ".db").
# no need to change the default.
RgbPath "/usr/X11R6/lib/X11/rgb"
# Multiple FontPath entries are allowed (they are concatenated together)
# By default, Red Hat 6.0 and later now use a font server independent of
# the X server to render fonts.
FontPath "/usr/X11R6/lib/X11/fonts/misc:unscaled"
FontPath "/usr/X11R6/lib/X11/fonts/75dpi:unscaled"
FontPath "/usr/X11R6/lib/X11/fonts/100dpi:unscaled"
FontPath "/usr/X11R6/lib/X11/fonts/URW"
FontPath "/usr/X11R6/lib/X11/fonts/Type1"
FontPath "/usr/X11R6/lib/X11/fonts/Speedo"
FontPath "/usr/X11R6/lib/X11/fonts/misc"
FontPath "/usr/X11R6/lib/X11/fonts/75dpi"
FontPath "/usr/X11R6/lib/X11/fonts/100dpi"
FontPath "/usr/X11R6/lib/X11/fonts/TrueType"
FontPath "unix/:-1"
EndSection
Re-start X after installing the fonts.
Rev 2002-01-23
Linux Configuration
HP VA 7100/7400
/usr/X11R6/lib/X11/fonts/URW
Note, this is the name of the
There is normally
Page 14
