Chronograph stopwatch instructions

Advertisement

ENGLISH
ANALOG INSTRUCTIONS

Time Setting

1. Pull the crown out to position 2.
2. Turn the crown to set the hour and minute hands
to the desired time.
3. Return the crown to position 1.
DATE MODELS
Do not change the date between
the hours of 10pm and 2am. This is
the time when the movement is in
position to carry out the automatic
date change, and any interference
may cause damage to the movement.

Date Setting

1. Pull the crown out to position 1.
2. Turn the crown either clockwise or counter-clockwise and set the date
for the previous day. The direction that moves the date varies on different
watch models.
Time Setting
1. Pull crown out to position 2.
2. Turn counter-clockwise to advance the time and continue until the day changes
to the present day.
3. Set to the correct time.
2
CLOSED
Rotate to set hour &
0 1
2
minute hands. Date
advances with each
24 hour rotation of
hour hand.
RAPID CORRECTION
OF DATE

Advertisement

Table of Contents
loading

Summary of Contents for Michael Kors MK8293

  • Page 1: Time Setting

    ENGLISH ANALOG INSTRUCTIONS Time Setting 1. Pull the crown out to position 2. 2. Turn the crown to set the hour and minute hands to the desired time. 3. Return the crown to position 1. DATE MODELS CLOSED Do not change the date between Rotate to set hour &...
  • Page 2: Caseback Time Setting

    CASEBACK TIME SETTING PUSHER BUTTON FOR TIME ADJUSTMENT FRONT BACK Time Setting 1. Push button to move hands. 2. Set to correct time. 2 EYE DAY/DATE MULTI-FUNCTION VX36 (1 crown) DATE 1 2 3 Date Setting 1. Pull crown out to position 2. 2.
  • Page 3: Three Eye Multi-Function 6P29/6P79

    THREE EYE MULTI-FUNCTION 6P29/6P79 (1 crown) DATE 24-HOUR Date Setting 1. Pull crown out to position 2. 2. Turn clockwise to advance the date hand. 3. Push crown back to position 1. Day and Time Setting 1. Pull crown out to position 3. 2.
  • Page 4: Chronograph Stopwatch Js25/Vd54

    CHRONOGRAPH STOPwATCH JS25/VD54 (with date-VD53) (1 crown/2 pushers) 24-HOUR HAND MINUTE HAND SECOND HAND Time and Date Setting 1. Before setting the time, make sure the chronograph is stopped and set to zero (12:00) position. 2. Pull crown out to position 2. 3.
  • Page 5: Chronograph Stopwatch Os20/Os21

    Chronograph Zero Reset 1. If either of the chronograph hands is not at the zero (12:00) position, pull crown out to position 3. 2. Press A to move hands clockwise; press B to move hands counter-clockwise. 3. Return crown to position 1. CHRONOGRAPH STOPwATCH OS20/OS21 (1 crown/2 pushers) CHRONOGRAPH SECOND HAND...
  • Page 6: Chronograph Operation

    Date Setting 1. Pull crown out to position 2. 2. Turn crown counter-clockwise until the correct date is shown in the date window. 3. Return crown to position 1. Chronograph Zero Reset This procedure should be performed when the chronograph second hand does not return to the “0”...
  • Page 7: Ana-Digi 1 - Qx4-Ap Dms

    ANA-DIGI 1 – QX4-AP DMS General Description / Features: TIME with 24-Hour Feature DUAL TIME ANA-DIGI ALARM with 2 alarms CHRONOGRAPH with stored data TIMER EL light operation Analog Time Setting 1. Pull the crown out to position 2. 2. Turn the crown to set the hour and minute hands to the desired time. 3.
  • Page 8: Time And Calendar Setting

    • Press when in setting modes to advance digits backwards. • In Chronograph Mode, press to stop chronograph; Press and hold for 3 seconds to reset to zero. NoTe: In any setting mode, if there is no activity for 30 seconds, all changes will be saved and the display will automatically return to display mode. Time and Calendar Setting 1. In Normal Time Display, press and hold A button for 3 seconds to enter setting mode.
  • Page 9: Alarm Mode

    lap (up to 100 laps). 3. Press D to display current set; press D again to switch to the next set. 4. Press and hold D 3 seconds to delete all stored data in the current set displayed. Alarm Mode 1.
  • Page 10: Ana-Digi 2 - Bj3255

    ANA-DIGI 2 – BJ3255 General Description / Features: ANA-DIGI TIME ALARM LIGHT Analog Time Setting 1. Pull the crown out to position 2. 2. Turn the crown to set the hour and minute hands to the desired time. 3. Return the crown to position 1. Digital Function/Setting A –...
  • Page 11 2. Press B button to adjust hour digit. Press A to set and advance to minute setting. 3. Press B button to adjust minute digit. Press A to set and advance to alarm on/ off selection. 4. Press B button to adjust alarm on/off. Press A to set and advance to chime on/ off selection.
  • Page 12: Chronograph Mode

    Chronograph Mode 1. Press D to change to chronograph mode. 2. Press D and hold 2 seconds to reset chronograph to zero. 3. Press C to start/stop the chronograph. 4. Press D to reset to zero. Alarm Mode 1. Press D to change to alarm mode. 2.
  • Page 13: Operation Description

    DIGITAL LCD 1 – QBJ-3071 General Description / Features: TIME with 24-Hour Feature DUAL TIME ALARM with 4 alarms CHRONOGRAPH TIMER with free set value EL light operation LCD Display Operation Description A - EL / SETTING BUTTON • Press to illuminate the display. • Press and hold to turn on/off EL LIGHT function and enter time setting mode.
  • Page 14 • Press to advance to the next adjustable set of digits when setting the time, date alarm, and countdown timer C - ADJUST / RESET BUTTON • In Normal Time Mode, press C button to turn on/off key tone function (KEY icon will appear/disappear). • Press to reset the countdown in the chronograph or timer modes. • Press when in setting modes to advance digits forward. D - ADJUST/START/STOP BUTTON • Press to start/stop the chronograph or timer modes. • Press to reset the countdown in the chronograph or timer modes. • Press when in setting modes to advance digits backwards. Time / Calendar 1. In Normal Time Display, press and hold A button for 3 seconds to enter setting mode.
  • Page 15: Dual Time

    8. Press C or D button to advance month display. Press B button to advance to day setting. 9. Press C or D button to advance day display. 10. Press A button to exit setting mode at any time. If no button is pressed within 30 seconds, display will automatically return to Normal Time Display.
  • Page 16: Time/Calendar Setting

    3. Press C or D to advance the timer value up or down. 4. Press A to exit Timer setting mode. Alarm There are four possible alarms that can run simultaneously. 1. In Alarm Mode, press D to select Alarm 1-4. In each alarm, press C button to turn on/off the alarm chime.
  • Page 17: Timer Mode

    4. Setting sequence is chime, 12/24-hour time, hour, minute, second, year, month, date, Auto EL. 5. Press A to save data and exit setting mode. Chronograph Mode 1. Press B to change to chronograph mode. 2. Press C to start chronograph; press D for lap when the chronograph is running. 3.
  • Page 18 Alarm Mode 1. Press B to change to alarm mode. 2. Press C to toggle between alarms 1, 2, 3, 4. 3. Press D to enable the alarm; press D again to disable the alarm. 4. Press B to exit alarm mode. Alarm Setting 1.
  • Page 19 PIN LINK DIAGRAM CHAIN NOSE PIN PUSHER PLIERS BRACELET HOLDER ARROWS Link Removal To remove a link from a pin link bracelet, you will need the bracelet holder, pin pusher, and chain nose pliers (see pin link diagram). 1. Open the clasp on the bracelet. 2.
  • Page 20 USE PRECAUTIONS - RESISTANCE TO wATER All Armani exchange timepieces are designed to withstand use as indicated on line 1 of the following chart. Indication water-related Use Skin diving Water- Light spray Bathing, Swimming, (Diving without resistant perspiration, etc. etc. oxygen characteristics light rain, etc.
