Compaq Armada M300
Series of Personal Computers
Maintenance and Service Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M300 - Armada - PII 333 MHz and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compaq M300 - Armada - PII 333 MHz

Summary of Contents for Compaq M300 - Armada - PII 333 MHz

  • Page 1 Compaq Armada M300 Series of Personal Computers Maintenance and Service Guide...
  • Page 2 In what form would you prefer to receive information? (Rank 1 to 5, with 1 representing the most preferred.) Maintenance and Service Guide on CD-ROM Maintenance and Service Guide on Compaq Web site Maintenance and Service Guide on QuickFind Printed Maintenance and Service Guide...
  • Page 3 “as is” without warranty of any kind. The entire risk arising out of the use of this information remains with the recipient. In no event shall Compaq be liable for any direct, consequential, incidental, special, punitive, or other damages...

  • Page 4: Table Of Contents

    ROUBLESHOOTING 2.1 Preliminary Steps ..........................2-2 2.2 Clearing Passwords.........................2-3 2.3 Power-On Self-Test (POST)......................2-3 2.4 POST Error Messages........................2-4 2.5 Compaq Utilities ..........................2-6 2.6 Troubleshooting Without Diagnostics ..................2-12 Before Replacing Parts........................2-12 Obtaining Update Information with Info messenger..............2-12 Checklist for Solving Problems ....................2-13 chapter 3...
  • Page 5 chapter 4 EMOVAL AND EPLACEMENT RELIMINARIES 4.1 Tools Required..........................1-1 4.2 Service Considerations........................1-1 Plastic Parts ...........................4-1 Cables and Connectors........................4-2 4.3 Preventing Damage to Removable Drives ..................1-2 4.4 Preventing Electrostatic Damage....................1-3 Packaging and Transporting Precautions..................4-3 Workstation Precautions .......................4-4 Grounding Equipmemt amd Methods ..................4-5 Electrostatic Voltage Levels and Protective Matherials...............4-6 chapter 5 EMOVAL AND...
  • Page 6 chapter 6 PECIFICATIONS 6.1 Physical and Environmental ......................6-1 6.2 Display ............................6-2 6.3 Hard Drive............................6-3 6.4 Diskette Drive ..........................6-4 6.5 Li-Ion Battery Pack.........................6-4 6.6 CD-ROM Drive ..........................6-5 6.7 DVD-ROM Drive ...........................6-6 6.8 System Interrupts ..........................6-7 6.9 System DMA...........................6-7 6.10 System I/O Addresses........................6-8 6.11 System Memory Map........................6-9 appendix A ........................A-1...

  • Page 7: Using This Guide

    This Maintenance and Service Guide is a troubleshooting reference that can be used when servicing the Compaq Armada M300 Series of Personal Computers. Compaq Computer Corporation reserves the right to make changes to the Compaq Armada M300 Series of Personal Computers without notice.

  • Page 8: Serial Number

    The serial number is on the bottom of the computer. Locating Additional Information In addition to this guide, the following documentation provides information for the computer: Compaq Armada M300 Series of Personal Computers documentation set Microsoft Operating System Manual Compaq Service Training Guides Compaq Service Advisories and Bulletins...

  • Page 9: Product Description

    ESCRIPTION 1.1 Computer Features and Models The Compaq Armada M300 Series of Personal Computers is an ultralight 3.1 to 3.3 pound (1.4 to 1.5 kg) computer (depending on configuration). It allows users high mobility, provides a full set of system ports, and when paired with the optional Mobile Expansion Unit (MEU), transforms into a full-function portable with enterprise docking capability.

  • Page 10: Models

    The Armada M300 models are shown in Table 1-1. The computer model designation is composed of a group of characters that define each model’s features. Table 1-1 Models and Model Naming Convention Compaq Armada M300 Series of Personal Computers 13-14 17-19 20-21...
  • Page 11 Table 1-2 Models and Model Naming Convention Compaq Armada M700 Series of Personal Computers 1 2 3 4 10 11 12 13-14 15 16 17-19 20-21 22 23 24 SKU# A M 3 T 1 X 165288-XX2 A M 3...

  • Page 12: Features

    Additional ports: parallel, serial, audio in/out, VGA, USB, PS/2 (2), AC power in, CPU connector, docking connector Stereo speakers providing Compaq PremierSound 16-bit stereo sound Robust, common enterprise docking solution End user must make a one-time selection between Windows 95 and Windows 98. If end user desires rejected product(s) after selection is made, end user must acquire and pay for rejected product(s) separately.

  • Page 13: Intelligent Manageability

    Inventory information—The network administrator can retrieve information about the computer over the network by using Compaq Insight Manager or any PC management tool provided by Compaq Solution Partners. Asset control information retrieved from the computer includes:...

  • Page 14: Fault Management

    Fault Management Fault Management features minimize downtime and data loss by monitoring system performance and generating the following alerts: Hard drive alert—provides 72-hour advance warning of impending hard drive problems and can automatically start optional backup software. System temperature alert—reports overheating. As the system temperature rises, this feature first adjusts fan speed and other cooling components, then displays an alert, then shuts down the system.

  • Page 15: Configuration Management

    Configuration Management optimizes software upgrade and customer support procedures. Compaq provides support software to optimize the performance of the computer. This support software is accessible through a monthly CD-ROM subscription. Support software can also be downloaded from the Compaq Web site at www.compaq.com/support/ portables. Managing Power The computer comes with a collection of power management features that allow battery operating time to be extended and power to be conserved.

  • Page 16: Computer External Components

    1.2 Computer External Components The external components on the top of the computer are shown in Figure 1-2 and described in Table 1-2. Figure 1-2. Top Components Product Description...

  • Page 17: Top Components

    Table 1-3 Top Components Item Component Function Display switch Turns off the computer display if the computer is closed while Scroll lock light On: Scroll lock is on. Caps lock light On: Caps lock is on. Num lock light On: Num lock is on and the embedded numeric keypad is enabled.
  • Page 18 The external components on the left side of the computer are shown in Figure 1-3 and are described in Table 1-3. Figure 1-3. Left Side Components Table 1-4 Left Side Components Item Component Function Connects the network cable. RJ-45 jack* NOTE: A network cable is included with network models.
  • Page 19 The external components on the right side of the computer are shown in Figure 1-4 and are described in Table 1-4. Figure 1-4. Right Side Components Table 1-5 Right Side Components Item Component Function PC Card slot Supports 32-bit (CardBus) and 16-bit PC Cards. Air intake vents Cool internal components.
  • Page 20 The external components of the front of the computer are shown in Figure 1-5 and described in Table 1-5. Figure 1-5. Front Components Table 1-6 Front Components Component Function Display release latch Opens the computer. Stereo speaker/headphone jack Connects stereo speakers, headphones, or headset audio. Microphone jack Connects a single sound channel microphone.
  • Page 21 The external components on the rear of the computer are shown in Figure 1-6 and described in Table 1-6. Figure 1-6. Rear Components Table 1-7 Rear Components Item Component Function USB connector Connects USB devices Serial connector Connects a serial device Parallel connector Connects a parallel device External monitor connector...
  • Page 22 The external components on the bottom of the computer are shown in Figure 1-7 and are described in Table 1-7 Figure 1-7. Bottom Components Table 1-8 Bottom Components Item Component Function Battery latches Release the primary battery pack. Real-time clock battery Provides battery power to automatically display the date and time.

  • Page 23: Design Overview

    1.3 Design Overview This section presents a design overview of key parts and features of the computer. Refer to Chapter 3 for the illustrated parts catalog and Chapter 5 for removal and replacement procedures. System Board The system board provides the following device connections: Memory expansion board Hard drive Display...

  • Page 24: Troubleshooting

    chapter Follow these basic steps when beginning the troubleshooting process: 1. Complete the preliminary steps listed in Section 2.1. 2. Run the Power-On Self-Test (POST) as described in Section 2.3. 3. Run Computer Setup as described in Section 2.5. 4. If you are unable to run POST or if the problem persists after running POST, perform the recommended actions described in the diagnostic tables in Section 2.5.
  • Page 25 Follow these steps to run Compaq Utilities: a. If you are running Compaq Utilities from the hard drive, turn on or restart the computer. Press when the cursor appears in the upper-right corner of the screen.
  • Page 26 1. Turn off the computer. 2. Disconnect the computer (Section 5.4). 3. Remove the battery pack (Section 5.6). 4. Disconnect and remove the Real Time Clock (RTC) battery (Section 5.10). 5. Wait five minutes. 6. Reconnect the RTC battery. 7. Reconnect the AC Adapter. Do not reinstall the battery pack yet. 8.

  • Page 27: Post Error Messages

    If the system is not functioning well enough to run POST, or if the display is not functioning well enough to show POST error messages, refer to the Troubleshooting tables in Section 2.6. If POST detects an error, one of the following events occurs: A message with the prefix "WARNING"...
  • Page 28 Continued Fatal errors emit a beep and may display a FATAL message. Fatal errors indicate severe problems, such as a hardware failure. Fatal errors do not allow the system to resume. Some of the Fatal error beep codes are listed at the end of this section. Troubleshooting...

  • Page 29: Compaq Utilities

    Compaq Utilities contain several functions that Determine if various computer devices are recognized by the system and are operating properly. Provide information about the system once it is configured. Compaq Utilities include the following programs: Computer Setup Compaq Diagnostics To access Compaq Utilities: 1.
  • Page 30 To configure a device in Windows NT 4.0, you must use Computer Setup. Compaq Diagnostics for Windows is a system information and diagnostic utility that is used within the Windows operating system. Use Compaq Diagnostics for Windows to test system components and to display system information whenever possible.
  • Page 31 Troubleshooting...
  • Page 32 Troubleshooting...
  • Page 33 1. Access Compaq Diagnostics for Windows by selecting Start Æ Settings Æ Control Panel Æ Compaq Diagnostics. 2. To select a category, choose one of two methods: Select the Categories menu, then select a category from the drop-down list. Select a category icon on the toolbar.
  • Page 34 Troubleshooting...

  • Page 35: Before Replacing Parts

    Verify that all printer drivers have been installed for each application. Compaq Info Messenger allows you to set a customized search of the Compaq Web site. By registering for this utility, you can stay up to date with software and hardware information specific to your system.
  • Page 36 If you encounter a minor problem with the computer or software applications, go through the following checklist for possible solutions: Is the computer connected to an external power source, or does it have a fully charged battery pack installed? Are all cables connected properly and securely? Did the diskette drive contain a nonbootable diskette when you turned on the computer? Are all the needed device drivers installed?
  • Page 37 Continued Æ Æ Continued Troubleshooting...
  • Page 38 Continued Troubleshooting...
  • Page 39 Continued Troubleshooting...
  • Page 40 Continued Troubleshooting...
  • Page 41 Continued Troubleshooting...
  • Page 42 Continued Æ Æ Æ Continued Troubleshooting...
  • Page 43 Continued Æ Æ Æ Æ Æ Æ Continued Troubleshooting...
  • Page 44 Continued Æ Æ Æ Continued Troubleshooting...
  • Page 45 Continued Troubleshooting...
  • Page 46 Troubleshooting...
  • Page 47 Troubleshooting...

  • Page 48: Illustrated Parts Catalog

    ARTS ATALOG This chapter provides an illustrated parts breakdown and a reference for spare part numbers for components of the Compaq Armada M300. 3.1 Serial Number Location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer (Figure 3-1).

  • Page 49: Computer Major System Components

    3.2 Computer Major System Components Figure 3-2. Major System Components 3-2 Illustrated Parts Catalog...
  • Page 50 Table 3-1 Spare Parts: Computer System Major Components Item Description Spare Part Number Display assembly 11.3-inch, XGA, CTFT (SKU#’s 165288-XXX only) 171969-001 11.3-inch, SVGA, CTFT 178654-001 Keyboard 140375-XXX Belgian -181 Italian -061 Portuguese -131 Brazilian -201 International -003 Spanish -071 Danish -081 Japanese...

  • Page 51: Miscellaneous Plastic Kit Components

    3.3 Miscellaneous Plastic Kit Components Figure 3-3. Miscellaneous Plastic Kit Components Table 3-2 Spare Parts: Miscellaneous Plastic Kit Components Spare Part Number 136254-001 Item Description Back rubber feet Infrared lens RTC (Real Time Clock) battery RTC (Real Time Clock) battery cover Front rubber feet Display screw covers PC Card door...

  • Page 52: Mass Storage Devices

    3.4 Mass Storage Devices Figure 3-4. Mass Storage Devices Table 3-3 Spare Parts: Mass Storage Devices Item Description Spare Part Number Hard drive 12.0 GB 171971-001 6.4 GB 136246-001 4.3 GB 136245-001 External diskette drive, 1.44-megabyte, 3.5 inch/8.89 cm 136256-001 External diskette drive cable 140383-001 4X DVD-ROM drive (for use with Mobile Expansion Unit)

  • Page 53: Miscellaneous

    3.5 Miscellaneous Table 3-4 Spare Parts: Miscellaneous (not illustrated) Description Spare Part Number Mobile Expansion Unit 140382-001 Armada M300 Maintenance & Service Guide 158340-001 PC Card modem 105993-001 Battery Charger 277734-001 AC Power Cord 246959-XXX Australian 246959-011 Japanese 246959-291 Danish 246959-081 Korean 246959-AD1...

  • Page 54: Removal And Replacement Preliminaries

    chapter EMOVAL AND EPLACEMENT RELIMINARIES This chapter provides essential information for proper and safe removal and replacement service. 4.1 Tools Required You will need the following tools to complete the removal and replacement procedures: Magnetic Torx T-8 screwdriver (for all screws unless otherwise specified) 9/32-inch socket for bushing guides 4.2 Service Considerations Listed below are some of the considerations that you should keep in mind during...

  • Page 55: Cables And Connectors

    Cables and Connectors Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Ensure that cables are routed in such a way that they cannot be caught or snagged by parts being removed or replaced.

  • Page 56: Preventing Electrostatic Damage

    4.4 Preventing Electrostatic Damage Many electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases the discharge contains enough power to alter device parameters or melt silicon junctions. A sudden discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.

  • Page 57: Workstation Precautions

    Workstation Precautions Use the following grounding precautions at workstations: Cover the workstation with approved static-dissipative material (refer to Table 4-2 later in this chapter). Use a wrist strap connected to a properly grounded work surface and use properly grounded tools and equipment. Use field service tools, such as cutters, screwdrivers, and vacuums that are conductive.

  • Page 58: Grounding Equipmemt Amd Methods

    Grounding Equipment and Methods Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm 10% resistance in the ground cords.

  • Page 59: Electrostatic Voltage Levels And Protective Materials

    Electrostatic Voltage Levels and Protective Materials Table 4-1 shows how humidity affects the electrostatic voltage levels generated by different activities. Table 4-1 Typical Electrostatic Voltage Levels Relative Humidity Event Walking across carpet 35,000 V 15,000 V 7,500 V Walking across vinyl floor 12,000 V 5,000 V 3,000 V...

  • Page 60: Removal And Replacement Procedures

    EMOVAL AND EPLACEMENT ROCEDURES 5.1 Serial Number The computer serial number should be reported to Compaq when requesting information or ordering spare parts. The serial number is located on the bottom of the computer (Figure 5-1). Figure 5-1. Serial Number Location...

  • Page 61: Disassembly Reference Chart

    5.2 Disassembly Reference Chart Use the chart below to determine the section number to be referenced when removing components from the computer. 5.3 Disconnecting the Computer from the Mobile Expansion Unit 5.4 Disconnecting the Computer 5.5 Preparing the Computer for Disassembly 5.6 Battery Packs Removing the Battery Pack Replacing the Battery Pack...

  • Page 62: Disconnecting The Computer From The Mobile Expansion Unit

    5.3 Disconnecting the Computer from the Mobile Expansion Unit Turn off the computer. Close the display. Turn off and disconnect all external devices connected to the computer. On the mobile expansion unit, press the docking release button to release the expansion unit from the computer (Figure 5-3).

  • Page 63: Disconnecting The Computer

    5.4 Disconnecting the Computer 1. Disconnect the AC power cord from the AC adapter (Figure 5-4). 2. Unplug the power cord from the electrical outlet 3. Disconnect the AC adapter from the power connector on the left side of computer Figure 5-4.

  • Page 64: Preparing The Computer For Disassembly

    5.5 Preparing the Computer for Disassembly 1. Disconnect the computer from the mobile expansion unit. 2. Shut down the computer. 3. Disconnect the AC adapter and all external devices connected to the computer. 4. Remove the battery pack (Section 5.6). CAUTION: Failure to disconnect the AC Adapter from the computer and to remove the battery pack before removing and installing internal components can damage the equipment.

  • Page 65: Battery Packs

    5.6 Battery Packs WARNING: To reduce the risk of injury or damage to the battery pack, do not crush, puncture, or incinerate the battery pack or short the metal contacts. Do not attempt to open or service the battery pack. Removing the Battery Pack Shut down the computer.

  • Page 66: Replacing The Battery Pack

    Replacing the Battery Pack WARNING: To prevent damage to the computer, do not insert a battery pack until the computer is fully reassembled. Turn the computer upside down. Push the battery pack onto the computer until the contacts connect , and rotate the battery pack 90 degrees toward the back of the computer (Figure 5-6).

  • Page 67: Hard Drives

    5.7 Hard Drives Removing a Hard Drive Before removing a hard drive, back up all information on the hard drive. Shut down the computer. Turn the computer upside down. Remove the hard drive screw (Figure 5-7). Pull up on the front bezel Slide the hard drive out of the bay Figure 5-7.

  • Page 68: Inserting A Hard Drive

    Inserting a Hard Drive Shut down the computer. Turn the computer upside down. Pull the bottom half of the bezel down. Slide the hard drive into the bay until the connector is seated (Figure 5-8). Push the front bezel down Insert the hard drive screw Figure 5-8.

  • Page 69: Pc Cards

    When a PC Card is in the system, the PC Card icon displays on the taskbar. In Windows NT 4.0 with CardWare from Compaq— If you insert a PC Card while the computer is on, the computer beeps three times when the card is recognized.

  • Page 70: Removing A Pc Card

    PC Card you want to stop. A message displays when the PC Card can be safely removed. In Windows NT 4.0 with CardWare provided by Compaq—If the computer is on, you must shut it down before removing some PC Cards. Refer to the PC Card documentation for removal requirements.

  • Page 71: Inserting A Pc Card

    Inserting a PC Card CAUTION: To prevent damage to the connectors, use minimal pressure as you insert a PC Card into the PC Card slot. With the connector facing the computer and the label side up, insert the PC Card in the slot, aligning the card on the two guide rails inside the PC Card slot (Figure 5-10).

  • Page 72: Modem Or Modem/Nic Card

    5.9 Modem or Modem/NIC Card Prepare the computer for disassembly (Section 5.5). If attached, disconnect the RJ-11 and RJ-45 cables from the computer. Turn the computer upside down with the front facing forward. Remove the two screws that secure the modem or modem/NIC card cover to the base assembly (Figure 5-11).
  • Page 73 Lift up on the back of the modem or modem/NIC card , and swing it forward to disconnect it from the system board (Figure 5-12). Use the connector removal tool to disconnect all cables connected to the card Remove the card. Figure 5-12.

  • Page 74: Real Time Clock (Rtc) Battery

    5.10 Real Time Clock (RTC) Battery Prepare the computer for disassembly (Section 5.5). Turn the computer upside down with the rear panel facing forward. Remove the RTC battery cover by lifting it at the indentation (Figure 5-13). Remove the battery from the base enclosure Use the connector removal tool to disconnect the RTC battery cable from the system board Remove the battery.

  • Page 75: Keyboard

    5.11 Keyboard Prepare the computer for disassembly (Section 5.5). Press down on each of the three release tabs along the top edge of the keyboard (Figure 5-14). Swing the top edge of the keyboard up and forward Figure 5-14. Releasing the Keyboard 5-16 Removal and Replacement Procedures...
  • Page 76 Use the connector removal tool to release the keyboard cable from the ZIF connector (Figure 5-15). Use the connector removal tool to disconnect the keyboard cable Remove the keyboard. Figure 5-15. Disconnecting the Keyboard Cable Reverse the above procedure to install the keyboard. Removal and Replacement Procedures 5-17...

  • Page 77: Memory Expansion

    5.12 Memory Expansion Removing the Memory Expansion Board WARNING: Failure to unplug the power cord and to remove the battery pack before installing a memory expansion board can damage the equipment and expose you to the risk of electrical shock. CAUTION: Electrostatic discharge (ESD) can damage electronic components.

  • Page 78: Installing The Memory Expansion Board

    Installing the Memory Expansion Board To add a memory board, insert the memory expansion board into the empty memory expansion slot at a 45-degree angle . Then slide it gently into place until it is seated while tilted (Figure 5-17). NOTE: All memory expansion boards supported by the computer are keyed (notched) to ensure correct positioning.

  • Page 79: Switch Cover

    5.13 Switch Cover Prepare the computer for disassembly (Section 5.5). Remove the keyboard (Section 5.11). Position the computer so the rear panel faces forward. Remove the two screws from the rear panel of the computer that secure the switch cover to the base assembly (Figure 5-18). Figure 5-18.
  • Page 80 Position the computer so the front faces forward. Open the computer as far as it will open. Swing the back edge of the switch cover forward (Figure 5-19). When the switch cover disengages from the base assembly, remove the cover Figure 5-19.

  • Page 81: Display Assembly

    5.14 Display Assembly Prepare the computer for disassembly (Section 5.5). Remove the keyboard (Section 5.11). Remove the switch cover (Section 5.13). Use the connector removal tool to disconnect the inverter cable from the system board (Figure 5-20) Use the connector removal tool to disconnect the microphone cable and the video cable from the system board.

  • Page 82: Top Cover With Touchpad

    5.15 Top Cover with TouchPad NOTE: The power button and infrared lens are easily dislodged when the top cover is removed. Make note of their location and orientation before removing the top cover. Prepare the computer for disassembly (Figure 5.5). Remove the keyboard (Section 5.11).
  • Page 83 Turn the computer right side up with the front facing forward. Use the connector removal tool to disconnect the TouchPad cable from the system board (Figure 5-22). Press in on the front of the top cover at the highlighted area , and swing the front edge of the cover up and away from the base assembly Remove the top cover.

  • Page 84: Voltage Converter Board

    5.16 Voltage Converter Board NOTE: When removing the voltage converter board from the system board, be careful of the connectors on the right side of the voltage converter board. Prepare the computer for disassembly (Section 5.5). Remove the keyboard (Section 5.11). Remove the switch cover (Section 5.13).

  • Page 85: Modem Connector Board

    5.17 Modem Connector Board Prepare the computer for disassembly (Section 5.5). Remove the modem or modem/NIC card (Section 5.9). Remove the keyboard (Section 5.11). Remove the switch cover (Section 5.13). Remove the display assembly (Section 5.14). Remove the top cover (Section 5.15). Remove the two screws that secure the modem connector board to the system board (Figure 5-24).
  • Page 86 NOTE: When installing the modem connector board, make sure the fan cable is routed between the connector and the modem connector area (Figure 5-25). Do not route the cable next to the heat sink. Figure 5-25. Routing the Fan Cable Removal and Replacement Procedures 5-27...

  • Page 87: Pc Card Assembly

    5.18 PC Card Assembly IMPORTANT: There are different-sized screws securing the PC Card assembly to the system board. Make note of the location of these screws. Prepare the computer for disassembly (Section 5.5). Remove the modem or modem/NIC card (Section 5.9). Remove the keyboard (Section 5.11).

  • Page 88: System Board

    5.19 System Board IMPORTANT: There are different-sized screws securing the system board to the base enclosure. Make note of the location of these screws. Also, when the system board is removed, components of the base enclosure may come loose. Note the location and orientation of all base enclosure components.
  • Page 89 Remove the two screws from the back of the computer that secures the system board to the base enclosure (Figure 5-28). Remove the silver screw from the heat sink Remove the black screws from around the fan , around the USB port , and around the battery cable in the upper left of the board Lift up the rear edge of the system board.

  • Page 90: Specifications

    chapter PECIFICATIONS 6.1 Physical and Environmental Table 6-1 Computer U.S. Metric Dimensions Height 0.89 in 2.3 cm Depth 9.0 in 22.9 cm Width 10.4 in 26.4 cm Weight 3.06 - 3.26 lbs 1.39 - 1.48 kg Standalone (Battery) Power Requirements Nominal operating voltage (Li-Ion) 14.2 VDC Nominal Operating Voltage (NiMH)

  • Page 91: Display

    6.2 Display Table 6-2 11.3-inch Color TFT SVGA Display U.S. Metric Dimensions Height 7.50 in 19.00 cm Width 10.10 in 25.60 cm Diagonal 11.30 in 28.70 cm Mounting Internal Number of Colors Contrast Ratio 125:1 Brightness 120 to 150 nit AC only/80 on battery Pixel Resolution Pitch 0.264 x 0.264 mm...

  • Page 92: Hard Drive

    6.3 Hard Drive Table 6-4 Hard Drives 4.3 GB 6.4 GB 12.0 GB User capacity per drive 4.3 GB 6.4 GB 12.0 GB Drive type Drive height (with drive frame) .5 inches / 12.5 mm .5 inches / 12.5 mm .5 inches / 12.5 mm Drive width 2.75 inches / 70 mm...

  • Page 93: Diskette Drive

    6.4 Diskette Drive Table 6-6 Diskette Drive Diskette Size 3.5 in (8.87 cm) Light On drive Height 0.55 in (1.40 cm) Bytes per Sector Sectors per Track High Density 18 (1.44 MB)/15 (1.2 MB) Low Density Tracks per Side High Density 80 (1.44 MB)/80 (1.2 MB) Low Density Read/Write Heads...

  • Page 94: Cd-Rom Drive

    6.6 CD-ROM Drive Table 6-8 CD-ROM Drive Applicable Disc CD-ROM (Mode 1, 2, and 3) CD-XA ready (Mode 2, Form 1 and 2) CD-I ready (Mode 2, Form 1 and Form 2) CD-R (read only) CD Plus Photo CD (single/multisession) CD Extra Video CD CD-WO (fixed packets only)

  • Page 95: Dvd-Rom Drive

    6.7 DVD-ROM Drive Table 6-9 DVD-ROM Specifications Applicable Disc DVD-5, DVD-9, DVD-10 CD-ROM mode 1, mode 2 CD-Digital Audio CD-XA mode 2 (Form 1, Form 2) CD-I mode 2 (Form 1 and Form 2) CD-I Ready CD-Bridge CD-R Photo CD (single/multisession) Center Hole Diameter .59 in./15 mm Disc Diameter...

  • Page 96: System Interrupts

    6.8 System Interrupts Table 6-10 System Interrupts Hardware IRQ System Function IRQ1 Timer Interrupt IRQ2 Cascaded IRQ3 PCMCIA IRQ4 COM1 IRQ5 Audio (default)* IRQ6 Diskette drive IRQ7 Parallel IRQ8 IRQ9 Infrared IRQ10 PCMCIA IRQ12 Internal Point Stick or External Mouse IRQ13 Coprocessor (Not available to any peripheral) IRQ14...

  • Page 97: System I/O Addresses

    6.10 System I/O Addresses Table 6-12 System I/O Addresses I/O Address (Hex) System Function (Shipping Configuration) 000 - 00F DMA Controller no. 1 010 - 01F Unused 020 - 021 Interrupt Controller no. 1 022 - 024 Opti Chipset Configuration registers 025 - 03F Unused 02E - 02F...

  • Page 98: System Memory Map

    Table 6-12 Continued I/O Address (Hex) System Function (Shipping Configuration) 2E8 - 2EF Reserved Serial Port 2F0 - 2F7 Unused 2F8 - 2FF Infrared port 320 - 36F Unused 378 - 37F Parallel Port (LPT1/Default) 380 - 387 Unused 388 - 38B FM Synthesizer - OPL3 38C - 3AF Unused...
