Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Service
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 15-0201
STAMINA PRODUCTS
MADE IN CHINA
©
2011 Stamina Products, Inc.
2011, 06
Advertisement
Table of Contents
Related Manuals for Stamina 15-0201
Summary of Contents for Stamina 15-0201
- Page 1 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2011 Stamina Products, Inc. 1 (800) 375-7520 2011, 06 www.staminaproducts.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instructions ........2 Storage ............13 Before You Begin ........4 Conditioning Guidelines ......14 Equipment Warning, Caution & Notice Labels ... 5 Warm-Up and Cool-Down ......15 Hardware Identification Chart ....6 Product Parts Drawing ......16 Assembly Instructions ........ -
Page 3: Customer Service
Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. ONLINE TELEPHONE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. customerservice@staminaproducts.com Tel: 1 (800) 375-7520 Fax: (417) 889-8064 ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071... -
Page 4: Before You Begin
Be sure to have the name and model number of parts that are labeled. the product available when you contact us. Read this manual carefully before using the INTONE® Folding Cycle Pro Although Stamina constructs its products with Seat Back Cushion Main Frame Back Support Tension Knob... -
Page 5: Equipment Warning, Caution & Notice Labels
EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the INTONE® Folding . Please take a moment to familiarize yourself with all of the warning, caution, and Cycle Pro notice labels. -
Page 6: Hardware Identification Chart
HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed. - Page 8 ASSEMBLY INSTRUCTIONS STEP 4 Attach the SEAT(43) to the SEAT FRAME(5) with BUTTON HEAD BOLTS(M8x1.25x15mm)(58) and WASHERS(M8)(73). Pull the ADJUSTMENT KNOB(41), then insert the SEAT FRAME(5) into the MAIN FRAME(1) and secure with the ADJUSTMENT KNOB(41). NOTE: 1. It may be necessary to unscrew the ADJUSTMENT KNOB(41) slightly to insert the SEAT FRAME(5).
- Page 9 ASSEMBLY INSTRUCTIONS STEP 7 NOTE: The RIGHT PEDAL(40) has R stamped on the end of the pedal shaft. The RIGHT PEDAL(40) has right hand threads and is tightened by turning clockwise. The LEFT PEDAL(39) has L stamped on the end of the pedal shaft. The LEFT PEDAL(39) has left hand threads and is tightened by turning counter clockwise.
-
Page 10: Set Up Instructions
SET UP INSTRUCTIONS Place the INTONE® Folding in the area where it will be used. It is recommended that the Cycle Pro INTONE® Folding be placed on an equipment mat. The INTONE® Folding Cycle Pro Cycle Pro approximately 39 inches long x 26.2 inches wide x 44.5 inches tall. (These dimensions may vary up to one inch.) An area 4 feet wide x 6 feet long is required for safe operation of the INTONE®... -
Page 11: Operational Instructions
OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON : Pedal movement or press the button. POWER OFF : Automatic shut off after four minutes of inactivity. MODE/RESET BUTTON: Press to select display functions, include SCAN, TIME, SPEED, DISTANCE, and CALORIE. Press and hold for four seconds to reset all functions to zero. -
Page 12: Maintenance
2. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts. Tighten loose nuts and bolts. 3. Verify that the WARNING LABEL(75) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement WARNING LABEL(75) if it is missing or damaged. -
Page 13: Storage
STORAGE 1. To store the INTONE® Folding , simply keep it in a clean dry place. Cycle Pro 2. To avoid damage to the electronics, remove the battery before storing the INTONE® Folding Cycle for one year or more. 3. To move the INTONE® Folding , Hold the HANDRAIL(7) to move the INTONE®... -
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs. -
Page 15: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your... -
Page 16: Product Parts Drawing
PRODUCT PARTS DRAWING FRONT BACK... -
Page 17: Parts List
PARTS LIST PART# PART NAME Main Frame Rear Frame Rear Stabilizer Front Stabilizer Seat Frame Back Support Handrail Left Crank Right Crank C Ring (17mm) Bearing Housing Support Plate Ball Bearing (6003RS) Bolt, Round Head (M6 x 1 x 10mm) Magnet Pulley w/ Shaft V-Ribbed Belt... - Page 18 PARTS LIST PART# PART NAME Protection Pad Wheel Endcap (50mm) Endcap (50mm) Rectangular Plug (30mm x 60mm) Square Plug (25mm x 25mm) Round Plug (25mm) Oval Plug (20mm x 40mm) Rectangular Plug (20mm x 40mm) Washer (ø8.2 x ø20 x 2mm Thick) Bolt, Button Head (M8 x 1.25 x 15mm) Bolt, Button Head (M8 x 1.25 x 37mm) Bolt, Button Head (M8 x 1.25 x 45mm)
-
Page 19: Warranty
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520. -
Page 20: Notes
NOTES... - Page 21 NOTES...
-
Page 22: Fax/Mail Ordering Form
ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
