pro910 Series
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the proColor pro910 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Oki proColor pro910 Series

  • Page 1 Series User’s Guide...
  • Page 2: Copyright Information

    The most up-to-date drivers and manuals are available from the web site: http://www.okiprintingsolutions.com Trademark Information _______________________________ Oki and Oki Printing Solutions are registered trademarks of Oki Electric Industry Company Ltd. Adobe and PostScript are registered trademarks of Adobe Systems. Apple, Macintosh, Mac, and Mac OS are registered trademarks of Apple Computers Inc.
  • Page 3: Table Of Contents

    Checking current settings ....45 Interfaces and connection ....46 pro910 User’s Guide> 3...
  • Page 4 Check Finisher, Staple Jam ....94 Specifications ......100 pro910 User’s Guide> 4...
  • Page 5 System Adjust ......117 Menus example 1 – Tray 1 transparencies ..121 Menus example 2 – MP Tray paper size ..122 pro910 User’s Guide> 5...
  • Page 6: Notes, Cautions And Warnings

    Please be careful to read and understand the safety warnings on the following pages before operating the printer. Illustrations Illustrations and components are representative only. Your unit may differ slightly from those pictured in this document. pro910 User’s Guide> 6...
  • Page 7 If in any doubt consult your dealer or power provider to ensure no risk of fire or shock exists. Ensure both the printer and mains power switches are in the OFF position before connecting the AC power cable. pro910 User’s Guide> 7...
  • Page 8 Always hold the power plug to connect/ disconnect the power cable to/from the mains socket. Unplugging by pulling on the cable can cause fraying and may lead to fire or electric shock. pro910 User’s Guide> 8...
  • Page 9 Unplug the mains connector and contact your dealer. If the printer has been knocked over or damaged, there is a risk of electric shock, fire and/or injury. Unplug the mains connector and contact your dealer. pro910 User’s Guide> 9...
  • Page 10 Clean using a damp cloth. Do not use liquid or aerosol cleaners. Do not carry out any operations on the printer that are not specified in the User's Guide. This may result in electric shock, fire and/or injury. pro910 User’s Guide> 10...
  • Page 11 Do not throw toner cartridges or image drum cartridges into a fire as you may receive burns from a dust explosion. pro910 User’s Guide> 11...
  • Page 12: Introduction

    NTRODUCTION Congratulations on buying an Oki color printer. Your new printer is designed with advanced features to give you clear, vibrant color prints and crisp black and white pages at high speed on a range of print media for the office.
  • Page 13 > Hard disk drive enables spooled and verified printing NOTE This is an optional feature on the pro910 model and is standard on the pro930. > Additional paper trays for loading a further 530 sheets at a...
  • Page 14: About This Guide

    Support and Supplies Guide: for quick reference to product support resources and information on how to purchase supplies. This is a paper document that is packaged with the printer. > Online Help: online information accessible from the printer driver and utility software. pro910 User’s Guide> 14...
  • Page 15: Software Supplied

    OFTWARE SUPPLIED CDs: > Drivers and Utilities Contains drivers and application software for use by a general user. > Network and Administrator Utilities Contains software for use by system administrators. > Fiery® Drivers and Tools (pro930 only) pro910 User’s Guide> 15...
  • Page 16: Online Usage

    From the toolbar, select [File], then [Print] (or press the Ctrl + P keys). Choose which pages you wish to print: [All pages], (1), for the entire manual. [Current page], (2), for the page at which you are looking. pro910 User’s Guide> 16...
  • Page 17 [Pages from] and [to], (3), for the range of pages you specify by entering their page numbers. Click on [OK]. pro910 User’s Guide> 17...
  • Page 18: Printer And Paper Overview

    To gain access to the inside of the printer, ensure that the top cover is fully opened. To open the top cover, squeeze the top cover handle (1) to release the catch and raise the cover. pro910 User’s Guide> 18...
  • Page 19: Identifying Major Components

    The major components of your printer are identified in the graphics below. Paper holding arm Top cover (face-down stacker) MP Tray (multi-purpose tray) Tray 1 side cover Paper size label Paper gauge Tray 1 (paper tray) Control panel pro910 User’s Guide> 19...
  • Page 20 Top cover handle Face-down stacker Power (on/off) switch pro910 User’s Guide> 20...
  • Page 21 Face-up stacker Interface unit Network interface connector pro910 User’s Guide> 21...
  • Page 22 Parallel interface connector USB interface connector Power connector Ventilation openings Image drum cartridge and toner cartridge (Cyan) Image drum cartridge and toner cartridge (Magenta) pro910 User’s Guide> 22...
  • Page 23 Image drum cartridge and toner cartridge (Yellow) Image drum cartridge and toner cartridge (Black) Toner cartridge Image drum cartridge Fuser unit LED heads Belt unit Drum basket handle pro910 User’s Guide> 23...
  • Page 24 Drum basket pro910 User’s Guide> 24...
  • Page 25: Paper Recommendations

    90 g/m²) paper designed for use in copiers and laser printers. Print speed and feed paths can vary when using thick and specialty media. Suitable types for all media paths include: > OKI® Bright White, 32 lb US Bond > HammerMill® Laser Print Radiant, White, 24 lb US Bond >...
  • Page 26: Paper Input And Output Information

    12.76 x 9.02 in 9.02 x 6.38 in 8.66 x 4.33 in 8.88 x 3.88 in 9.5 x 4.13 in 7.5 x 3.88 in Labels A4, Letter, B5 0.004 – MP Tray 0.008 in Face-up Stacker pro910 User’s Guide> 26...
  • Page 27: Trays And Stackers

    1 in. Paper or transparencies should be loaded print side up and top edge into the printer. Do not use the duplex (two-sided printing) function for transparencies. pro910 User’s Guide> 27...
  • Page 28: Face-Down Stacker

    Legal 13.5 in, Legal 14 in, B4, Tabloid, Tabloid Extra, A3, A3 Wide, A3 Nobi, Custom size (3.9 – 12.9 in wide, 5.8 –18 in long), using paper stocks in the range 64 – 188 g/m². pro910 User’s Guide> 28...
  • Page 29: Tray And Stacker Examples

    Press the paper rear stopper tab (1) and adjust the tab to the required paper size. Fan the paper to be loaded then tap the edges of the stack on a flat surface to make it flush. pro910 User’s Guide> 29...
  • Page 30 • Do not leave space between the paper and the guides and rear stopper. • Do not overfill the paper tray. Capacity depends on the paper type. • Do not load damaged paper. • Do not load paper of different sizes or types at the same time. pro910 User’s Guide> 30...
  • Page 31: Using The Mp Tray

    Gently push the tray back into the printer. MP T SING THE Squeeze the handle (1) and open the multi-purpose tray. pro910 User’s Guide> 31...
  • Page 32 • For single-sided printing on letterhead, load the paper into the multi-purpose tray with pre-printed side up and top edge into the printer. • For two-sided (duplex) printing on letterhead, load the paper with pre-printed side down and top edge away from pro910 User’s Guide> 32...
  • Page 33 Do not select duplex printing on envelopes. • Do not leave space between the paper and the guides. • Do not exceed the paper capacity of approximately 230 sheets, 100 transparencies or 25 envelopes. Maximum stacking depth is 1 in. pro910 User’s Guide> 33...
  • Page 34: Using The Stackers

    (its normal position), paper is ejected to the face-down stacker on the top of the printer. Face-up stacker The face-up exit path is used for heavy paper (cardstock etc.), envelopes, transparencies, and labels. Open the stacker (1). pro910 User’s Guide> 34...
  • Page 35 Flip out the paper support (2). Swivel out the paper support extension (3). pro910 User’s Guide> 35...
  • Page 36: Control Panel

    The parts of the control panel are identified and briefly explained below: Shutdown/Restart button Hold down for more than 2 seconds for a soft shutdown. You can then press this button again for a restart or use the Power switch to turn off the printer completely. pro910 User’s Guide> 36...
  • Page 37: Ready Light

    Switches between online (printer ready to receive data) and offline (printer not ready to receive data) Cancel button Cancels current print job Help button Provides additional textual or image data to supplement what is displayed on the display panel pro910 User’s Guide> 37...
  • Page 38: Display Panel Messages

    Restricts the changes that general users can make via the user menus. System maintenance menu: accessed by pressing the Up- arrow and Down-arrow buttons together for more than 2 seconds while turning on the printer power supply (including pro910 User’s Guide> 38...
  • Page 39: Configuration Information

    Many of these menu settings can be, and often are, overridden by settings in the Windows printer drivers. However, several of the driver settings can be left at "Printer Setting," which will then default to the settings entered in these printer menus. pro910 User’s Guide> 39...
  • Page 40 Value.) Press the Online button to exit menu mode and return to the ready to print status. Refer to the section entitled “Getting started” “Appendix B – Menu system” for examples of using the menus. pro910 User’s Guide> 40...
  • Page 41: Getting Started

    ETTING STARTED This section provides information to help you get started with using your printer. RINTER LOCATION Check that you have sufficient space for access: > around your printer: 20cm 8in 60cm 60cm 24in 24in 100cm 40in pro910 User’s Guide> 41...
  • Page 42: Turning Off/On

    > above your printer: 70cm 28in URNING URNING No hard disk drive installed If a hard disk drive is NOT installed, use the On/Off switch. pro910 User’s Guide> 42...
  • Page 43 Shutdown/Restart button (1) on the control panel for more than 2 seconds to start the shutdown process. When the display panel shows that you can either turn off or restart the printer, use the On/Off switch to turn off the printer. pro910 User’s Guide> 43...
  • Page 44: Turning On

    The default language used by your printer for display messages and for report printing is English. If required, this can be changed using the Panel Language Download Utility located on the installation CD under Optional Utilities. pro910 User’s Guide> 44...
  • Page 45: Checking Current Settings

    You can use this document to check your printer configuration. System values and installed accessories are listed at the top of the first page while status values and settings follow. pro910 User’s Guide> 45...
  • Page 46: Interfaces And Connection

    *****, ***** (2), ***** (3), etc. These numbers depend on the order of connecting or turning on each printer. > Ethernet – For network cable connection. NOTE Interface cables are not supplied with your printer. pro910 User’s Guide> 46...
  • Page 47: Connecting The Parallel Interface

    Do not connect the USB cable at this time. You will be instructed when to connect the USB cable when you run the Drivers CD. If you are connecting your printer directly to a stand alone computer proceed to the section entitled “Printer Drivers”. pro910 User’s Guide> 47...
  • Page 48: Connecting The Network Interface

    ONNECTING THE NETWORK INTERFACE CAUTION! Do not connect a USB cable into the network interface connector as this may lead to malfunction. Turn off the printer and the computer. Install the Ferrite core to the Ethernet cable as shown. pro910 User’s Guide> 48...
  • Page 49: Using The Drivers Cd

    You are prompted to follow a set of basic steps to configure the display panel language, install drivers and other software and finally print a test page to check that your printer is operating correctly. pro910 User’s Guide> 49...
  • Page 50: Consumables And Maintenance

    The paper feed rollers and the multi-purpose (MP) tray feed rollers do not have any replacement warning messages. Recommended replacement: after approximately 120,000 Letter sheets. pro910 User’s Guide> 50...
  • Page 51: Replacing Consumables/Maintenance Items

    You are advised to follow these instructions carefully. CAUTION! Only use genuine Oki Original consumables to ensure the best quality and performance from your hardware. Non-Oki Original products may damage your printer’s performance and invalidate your warranty.
  • Page 52 With an LED lens cleaner or soft cloth, gently wipe each of the four heads (1). Move the cleaner as shown, using a clean section of the cleaner with each pass. Be careful not to damage the guards (2). Close the top cover. pro910 User’s Guide> 52...
  • Page 53: Cleaning The Paper Feed Rollers

    Remove items like a wrist watch or bracelet and follow the correct steps to turn the printer off depending on whether a hard disk drive is installed. Open Tray 1 side cover and pull out the paper guide plate (1). pro910 User’s Guide> 53...
  • Page 54 Remove Tray 1 completely from the printer. Gaining access through the gap left by Tray 1, wipe the 3 paper feed rollers (2) with a soft cloth lightly moistened with water. Replace Tray 1. pro910 User’s Guide> 54...
  • Page 55 Return the paper guide plate to its original position and close Tray 1 side cover. Turn on the printer. pro910 User’s Guide> 55...
  • Page 56: Cleaning The Printer Casing

    Follow the correct steps to turn the printer off depending on whether a hard disk drive is installed. Wipe the printer surface with a soft cloth moistened sparingly with water or neutral detergent. Use a soft dry cloth to dry the printer surface. pro910 User’s Guide> 56...
  • Page 57: Emptying The Punch Chip Box (Punch Unit Optional Accessory)

    MPTYING THE PUNCH CHIP BOX UNCH UNIT OPTIONAL ACCESSORY When the display panel indicates that the punch chip box is full, empty the box as follows: Operate the Finisher lever and move the Finisher away from the printer. pro910 User’s Guide> 57...
  • Page 58 Pull out the punch chip box, being careful to keep it level so as not to spill any chips. Discard the chips in an appropriate place. Replace the punch chip box carefully into the Finisher. pro910 User’s Guide> 58...
  • Page 59 Check that the punch chip box has been replaced correctly then move the Finisher back into position, being careful not to trap your fingers. pro910 User’s Guide> 59...
  • Page 60: Optional Accessories

    RAM memory > hard disk drive (required for verified and spooled printing, direct printing of PDFs, when collation errors appear, adding extra fonts) (pro910 only) > second, third paper tray (to increase paper input capacity) > high capacity feeder (equivalent to three paper trays)
  • Page 61: Installing Accessories

    The Finisher and Punch unit must be installed by an authorized engineer. For the following accessories, you have to make the appropriate setting in your printer driver(s): > duplex unit > paper tray(s) > Finisher Refer to the Printing Guide for driver setting details. pro910 User’s Guide> 61...
  • Page 62: Troubleshooting

    Tray 1, or any one of Tray 2 to Tray 5 (if installed), can appear in place of the tttttt characters in the display panel message. In this example Tray 1 is used, the procedure being similar for all other trays. pro910 User’s Guide> 62...
  • Page 63 Squeeze the catch (1) on Tray 1 side cover and open the cover. Holding it by the tab (2), turn the paper guide outward. Carefully remove the jammed paper. pro910 User’s Guide> 63...
  • Page 64: Open Cover, Paper Jam, Side Cover

    Put the paper guide back into position and close Tray 1 side cover. PEN COVER PAPER JAM SIDE COVER If the MP Tray is open, close it so that the side cover (1) is visible. pro910 User’s Guide> 64...
  • Page 65 Pull the release lever (2) and pull open the side cover. Carefully remove the jammed paper. pro910 User’s Guide> 65...
  • Page 66: Open Cover, Paper Jam, Top Cover

    Close the side cover. PEN COVER PAPER JAM TOP COVER Squeeze the top cover handle (1) and open the top cover. WARNING! Be careful not to touch the fuser unit which is hot after printing. pro910 User’s Guide> 66...
  • Page 67 WARNING! Be careful not to touch the fuser unit which may be hot after printing. If the fuser unit is hot, wait until it cools before attempting to remove any jammed paper. pro910 User’s Guide> 67...
  • Page 68 Holding the fuser unit (4) by the handle, lift it out of the printer and place it on a flat surface. Pull up the jam release levers (5) and remove the jammed paper. pro910 User’s Guide> 68...
  • Page 69 Carefully replace the fuser unit into the printer and turn the lock lever (6) in the direction shown to lock the fuser unit. If paper is jammed near the paper exit, open the face-up stacker (7). pro910 User’s Guide> 69...
  • Page 70 Open the side cover (paper exit) (8) and remove the jammed paper. Close the side cover (paper exit) and then the face-up stacker. pro910 User’s Guide> 70...
  • Page 71 Return the image drum basket (9) into position and check it is locked. Close the top cover and ensure it is latched. pro910 User’s Guide> 71...
  • Page 72: Paper Jams - Duplex Unit (If Installed)

    PAPER JAM If a Finisher unit is attached to your printer, operate the lever (1) of the Inverter unit to separate the Inverter from the printer. Operate the duplex cover release button (2) and open the cover. pro910 User’s Guide> 72...
  • Page 73 Carefully remove any jammed paper. Operate the levers (3) and pull out the duplex unit. pro910 User’s Guide> 73...
  • Page 74 Holding the front top cover by the grip (4), push it gently inwards and raise it. Remove any jammed paper. pro910 User’s Guide> 74...
  • Page 75 In similar manner, check for and clear any paper jammed under the rear top cover. Replace the two top covers. pro910 User’s Guide> 75...
  • Page 76 Raise the front cover of the duplex unit. Push the duplex unit back into position. pro910 User’s Guide> 76...
  • Page 77 If you detached a Finisher unit to gain access to the duplex unit, replace the Finisher unit. pro910 User’s Guide> 77...
  • Page 78: Paper Jams - Finisher (Optional Accessory)

    You will need this to be able to clear the paper jam. The following paragraphs explain what to do for each of the indicated numeric codes. 591, 592, 593, 599/ 643, 645 ( PAPER JAM AROUND INISHER Remove any paper at the Finisher paper exit. pro910 User’s Guide> 78...
  • Page 79 Operate the Finisher lever (1) and move the Finisher away from the Inverter. Open the Finisher top cover. pro910 User’s Guide> 79...
  • Page 80 Carefully remove any jammed paper. Close the Finisher top cover. Move the Finisher back into position and connect it to the Inverter. pro910 User’s Guide> 80...
  • Page 81 594, 597, 598/ 644, 646 ( PAPER JAM IN INISHER Operate the Finisher lever (1) and move the Finisher away from the Inverter. Open the Finisher front cover (2). pro910 User’s Guide> 81...
  • Page 82 Continue to turn the lower knob (3) clockwise until any jammed paper is completely ejected. Remove the ejected paper. Close the Finisher front cover. pro910 User’s Guide> 82...
  • Page 83 Open the Finisher right side cover. Carefully remove any jammed paper. Close the Finisher right side cover. pro910 User’s Guide> 83...
  • Page 84: Paper Jam In Finisher/Punch Unit)

    Move the Finisher back into position and connect it to the Inverter. 590 ( PAPER JAM IN INISHER UNCH UNIT Operate the Finisher lever (1) and move the Finisher away from the Inverter. pro910 User’s Guide> 84...
  • Page 85 Move the tab (2) on the right side of the Finisher to align it with the mark (3). Open the Finisher top cover. pro910 User’s Guide> 85...
  • Page 86 Carefully remove any jammed paper. Close the Finisher top cover. Move the Finisher back into position and connect it to the Inverter. pro910 User’s Guide> 86...
  • Page 87: Check Inverter, Paper Jam

    HECK NVERTER PAPER JAM Operate the Finisher lever (1) and move the Finisher away from the Inverter. Squeeze the recessed handle (2) and open the left side cover of the Inverter. pro910 User’s Guide> 87...
  • Page 88 Carefully remove any jammed paper. Close the Inverter left side cover. Move the Finisher back into position and connect it to the Inverter. pro910 User’s Guide> 88...
  • Page 89 Operate the Inverter lever (3) and separate the Inverter from the printer. Open the right side door (4) of the Inverter. pro910 User’s Guide> 89...
  • Page 90 Remove any jammed paper. Close the right side door. pro910 User’s Guide> 90...
  • Page 91: Avoiding Paper Jams

    Adjust the paper stop and paper guides of properly in the paper tray. the tray, or the manual feed guide on the MP Tray to align the media properly. Your envelopes to be printed Adjust the orientation as required. are not oriented properly. pro910 User’s Guide> 91...
  • Page 92: Dealing With Unsatisfactory Printing

    The LED head is dirty. Wipe the LED head with a fading vertically. LED lens cleaner or with a soft cloth. The toner is low. Replace the toner cartridge. The paper is not Use recommended paper. suitable for the printer. pro910 User’s Guide> 92...
  • Page 93 When the interval is Replace the fuser unit. about 87mm (3.5in), the fuser unit is damaged. The image drum Replace the image drum cartridge has been cartridge if the problem is exposed to light. not resolved. pro910 User’s Guide> 93...
  • Page 94: Staple Jams - Finisher (Optional Accessory)

    [Media Weight]. – F TAPLE JAMS INISHER OPTIONAL ACCESSORY HECK INISHER TAPLE When the display indicates a staple jam has occurred, clear the jam as follows: Open the Finisher front cover. pro910 User’s Guide> 94...
  • Page 95 Turn the knob in the direction indicated until the colored indicator appears. Remove any paper that awaits stapling in the paper ejection area. pro910 User’s Guide> 95...
  • Page 96 Pull out the staple unit. Turn the knob in the direction indicated to move the stapler to the front. pro910 User’s Guide> 96...
  • Page 97 Grip both sides of the staple cartridge, pull it up and remove Raise the staple cartridge gate. Remove all staples that are emerging from the staple case. pro910 User’s Guide> 97...
  • Page 98 Return the staple cartridge gate to its original position. Replace the staple cartridge. Ensure that the staple cartridge is securely installed back into the staple unit then push the staple unit fully home. pro910 User’s Guide> 98...
  • Page 99 Close the Finisher front cover, being careful not to trap your fingers. pro910 User’s Guide> 99...
  • Page 100: Specifications

    (20 – 28 lb paper) Resolution 1200 x 600 dpi (pro910) 1200 x 1200 (pro930) Emulations PCL 5c, PCL XL 2.1, PS w/PDF Direct (pro910) PCL 5c, PCL XL2.1, Fiery ® PS (pro930) First Print Time 9 sec (Mono), 10.5 sec (Color) Memory...
  • Page 101 Standby: 600 W maximum, 200 W typical Power save: 34 W Operating environment Operating: 50 – 90°F/20 – 80%RH Off: 32 – 110°F/10 – 90%RH Noise level Operating: 54dBA maximum Standby: 42dBA maximum Power save: 28dBA maximum after 30 mins background level pro910 User’s Guide> 101...
  • Page 102: Appendix A - Display Panel Messages

    Install Tray The printer has tried to take paper from a tray that tttttt has been removed. Ensure that tray tttttt is correctly located or put tray tttttt loaded with paper back into the printer. pro910 User’s Guide> 102...
  • Page 103 You can access help details by pressing the HELP details button. Check Image Drum Check that the image drum of color cccccc is cccccc correctly installed. Please see HELP for You can access help details by pressing the HELP details button. pro910 User’s Guide> 103...
  • Page 104: Appendixb - Menu System

    The remainder of the menus above are intended for more specialized usage and are not described further here. For full details of using all menus to configure and use the printer, refer to the Network and Configuration Guide. pro910 User’s Guide> 104...
  • Page 105: Configuration

    MP Tray nnnnnn Displays total printed pages from MP tray. INISHER OUNT ITEM VALUE DESCRIPTION Staple nnnnnn Displays total pages stapled. Punch nnnnnn Displays total pages punched. Finisher nnnnnn Displays total pages ejected into the Finisher. pro910 User’s Guide> 105...
  • Page 106: Supplies Life

    Displays subnet mask. Gateway Address xxx.xxx.xxx.xxx Displays gateway address. MAC Address xx.xx.xx.xx.xx.xx Displays the network MAC address. Network FW xx.xx Displays the network firmware version. Version Web Remote xx.xx Indicates the network web page version. Version pro910 User’s Guide> 106...
  • Page 107: Paper Size In Tray

    CU Version xx.xx Displays version no. of CU (Control Unit) firmware. Same as CU version of Menu Map. PU Version xx.xx.xx Displays version no. of PU (Print Unit) firmware. Same as PU version of Menu Map. pro910 User’s Guide> 107...
  • Page 108: Print Page Count

    Press the Up-arrow or Down-arrow buttons repeatedly until Monochrome Page is highlighted. Press the Enter button and the monochrome page count is displayed. Press the Online button to exit menu mode and return to the ready to print status. pro910 User’s Guide> 108...
  • Page 109: Print Information

    Font List list. Statistics Log Execute Prints Job records by print job. Usage Report Execute Prints all of Job Log. Error Log Execute Prints the error log. Color Profile Execute Prints a color profile list. List pro910 User’s Guide> 109...
  • Page 110: Print Information Example - Demonstration Page

    Press the Up-arrow or Down-arrow buttons repeatedly until Demo 1 is highlighted. Press the Enter button to select this Item and the demo page is printed. After printing, the printer returns to ready to print status. pro910 User’s Guide> 110...
  • Page 111: Print Secure Job

    Yes/No display, and selecting Yes deletes all jobs. After the job is printed, or the deletion of the job is instructed by the menu, the job is deleted in the manner specified in the printer driver. pro910 User’s Guide> 111...
  • Page 112: Menus

    Sets the automatic tray Switch switch function. Tray Sequence Down Specifies selection order priority for Paper feed tray automatic tray selection/automatic tray switch. Unit of Inch (L) Specifies units for Measure mm (A) custom paper size. pro910 User’s Guide> 112...
  • Page 113 A3 Nobi The printer detects A3 Paper A3 Wide Nobi, A3 Wide and Tabloid Extra Tabloid Extra sizes as the same. Use this setting to tell the printer which of the three sizes is loaded in Traym. pro910 User’s Guide> 113...
  • Page 114 Sets the length of the where m is in Paper Legal 13.5 legal paper in Traym. range 1 to 5 Change this to Legal 13.5 if that is the (similar standard legal size in arrangement your country. for all trays) pro910 User’s Guide> 114...
  • Page 115 Y Dimension 3.5 – 11.0 (L) Sets Custom paper – 11.7 (A) – length for MP Tray. 47.2 inch Sets for the same 90 – 279 (L) – direction as paper 297 (A) – 1200 movement. pro910 User’s Guide> 115...
  • Page 116 If a paper size or type Mismatching in a tray is not matched to that of the print data, use paper from this tray instead of the specified tray. Do Not Use Makes the MP tray unavailable in auto tray selection/switching. pro910 User’s Guide> 116...
  • Page 117: System Adjust

    30 sec For PS, printing is not 40 sec carried out and the 50 sec job is cancelled. 60 sec 90 sec 120 sec 150 sec 180 sec 210 sec 240 sec 270 sec 300 sec pro910 User’s Guide> 117...
  • Page 118 Y Adjust Adjusts the position +0.25 – +2.00 of the whole printing -2.00 – -0.25 image (0.25 mm, 0.01 in interval) parallel to the 0.00 direction of paper +0.01 – +0.08 movement (i.e. -0.08 – -0.01 vertically). pro910 User’s Guide> 118...
  • Page 119 Decrement setting when a white horizontal dotted line or a snowing image occurs in high- coverage print portions. Increment setting when a faded image occurs. pro910 User’s Guide> 119...
  • Page 120 Decrement setting when a white horizontal dotted line or a snowy image occurs in high- coverage print portions. Increment setting when a faded image occurs. pro910 User’s Guide> 120...
  • Page 121: Menus Example 1 - Tray 1 Transparencies

    Enter menu mode by pressing either the Up-arrow or Down-arrow button and press them repeatedly until the Menus menu is highlighted. Press the Enter button to select this menu. Press the Up-arrow or Down-arrow buttons repeatedly until Tray Configuration is highlighted. pro910 User’s Guide> 121...
  • Page 122: Menus Example 2 - Mp Tray Paper Size

    Press the Up-arrow or Down-arrow buttons repeatedly until MP Tray Config is highlighted. Press the Enter button to select this Item. Press the Up-arrow or Down-arrow buttons repeatedly until Paper Size is highlighted. Press the Enter button to select this Item. pro910 User’s Guide> 122...
  • Page 123 Press the Enter button to select this value. Check that an asterisk (*) appears beside the chosen size. Press the Online button to exit menu mode and return to the ready to print status. pro910 User’s Guide> 123...
