  • Page 1 P5L-VM 1394...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Welcome! ................1-2 Package contents ..............1-2 Special features ..............1-2 1.3.1 Product highlights ........... 1-2 1.3.2 Innovative ASUS features ........1-4 Before you proceed .............. 1-5 Motherboard overview ............1-6 1.5.1 Placement direction ..........1-6 1.5.2 Screw holes ............. 1-6 1.5.3...
  • Page 4 Chapter 2: BIOS setup Managing and updating your BIOS ........2-2 2.1.1 Creating a bootable floppy disk ......2-2 2.1.2 ASUS EZ Flash 2 utility ..........2-3 2.1.3 AFUDOS utility ............2-4 2.1.4 ASUS CrashFree BIOS 2 utility ........ 2-6 2.1.5...
  • Page 5 Boot Settings Configuration ......... 2-33 2.6.3 Security ..............2-34 Tools menu ................. 2-36 2.7.1 ASUS EZ Flash 2 ............ 2-36 2.7.2 ASUS O.C. Profile ..........2-37 Exit menu ................2-38 Chapter 3: Software support Installing an operating system ..........3-2 Support CD information ............

  • Page 6: Notices

    Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.

  • Page 7: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 8: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 9: Typography

    Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 10: P5L-Vm 1394 Specifications Summary

    P5L-VM 1394 specifications summary LGA775 socket for Intel Core™2 Extreme / Core™2 Duo / ® Pentium D / Pentium 4 / Celeron D Processors ® ® ® Compatible with Intel PCG 06/05B/05A processors ® Supports Intel Enhanced Memory 64 Technology (EM64T), ®...
  • Page 11 Special features ASUS EZ Flash 2 ASUS CrashFree BIOS 2 ASUS MyLogo™ ASUS CPR (CPU Parameter Recall) ASUS O.C. Profile: overclocking configuration-sharing tool Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, Chassis Intrussion Internal 2 x USB 2.0 connectors for 4 additional USB 2.0 ports...

  • Page 13: Chapter 1: Product Introduction

    This chapter describes the motherboard features and the new technologies it supports. Product introduction...

  • Page 14: Welcome

    ® The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of ASUS quality motherboards! Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.
  • Page 15 300 MB/s data transfer rate. IEEE 1394a support The IEEE 1394a interface provides high speed digital interface for audio/ video appliances such as digital television, digital video camcorders, storage peripherals & other PC portable devices. ASUS P5L-VM 1394...

  • Page 16: 1.3.2 Innovative Asus Features

    You can now talk to your partners on the headphone while playing multi-channel network games. 1.3.2 Innovative ASUS features CrashFree BIOS 2 This feature allows you to restore the original BIOS data from the support CD in case when the BIOS codes and data are corrupted.

  • Page 17: Before You Proceed

    This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. SB_PWR Standby Powered Power P5L-VM 1394 Onboard LED ASUS P5L-VM 1394...

  • Page 18: Motherboard Overview

    Motherboard overview Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.

  • Page 19: Motherboard Layout

    LAN_USB34 Intel GMCH945G AUDIO USB78 PCIEX16 PCI1 Attansic L1 SB_PWR Intel ICH7 PCI2 SATA4 SATA3 CR2032 3V Lithium Cell CMOS Power ALC883 PCIEX1_1 SATA2 VT6308P SATA1 CHASSIS BIOS SPDIF_OUT COM1 PANEL IE1394_2 SPI_J1 USB56 AAFP USBPW56 CLRTC ASUS P5L-VM 1394...

  • Page 20: Central Processing Unit (Cpu)

    Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket pins/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. •...
  • Page 21 Load plate Position the CPU over the socket, making sure that the gold triangle is on the bottom-left corner of the socket. The socket alignment key should fit Alignment key into the CPU notch. Gold triangle mark ASUS P5L-VM 1394...
  • Page 22 Close the load plate (A), then push the load lever (B) until it snaps into the retention tab. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! The motherboard supports Intel LGA775 processors with the Intel...

  • Page 23: Installling The Cpu Heatsink And Fan

    Place the heatsink on top of the installed CPU, making sure that the four fasteners match the holes on the motherboard. Fastener Motherboard hole Make sure each fastener is oriented as shown, with the narrow groove directed outward. ASUS P5L-VM 1394 1-11...
  • Page 24 Push down two fasteners at a time in a diagonal sequence to secure the heatsink and fan assembly in place. When the fan and heatsink assembly is in place, connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN. CPU_FAN CPU FAN PWM CPU FAN IN...

  • Page 25: Uninstalling The Cpu Heatsink And Fan

    Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard. ASUS P5L-VM 1394 1-13...
  • Page 26 Remove the heatsink and fan assembly from the motherboard. Rotate each fastener clockwise to reset the orientation. Narrow end of the groove The narrow end of the groove should point outward after resetting. (The photo shows the groove shaded for emphasis.) 1-14 Chapter 1: Product introduction...

  • Page 27: System Memory

    Some odd version DDR2-667 DIMMs may not match Intel On-Die- Temination (0DT) requirement and may downgrade to run at DDR2-533. If this happen, contact your retailer for the ODT value. • This motherboard does not support memory modules made up of 128 Mb chips. ASUS P5L-VM 1394 1-15...
  • Page 28 32-bit version OS. The excess memory installation will not cause any usage problem, but it will not give users the benefit of manipulating this excess memory space. Visit the ASUS FAQ site for further explanation: http://support.asus.com/faq/faq.aspx?SLanguage=en-us Under General Search, make the selections as shown, then click Search.

  • Page 29: Ddr2 Qualified Vendors List

    DDR2 Qualified Vendors List The following table lists the memory modules that have been tested and qualified for use with this motherboard. Visit the ASUS website (www.asus. com) for the latest DDR2 DIMM modules for this motherboard. DDR2 667 Qualified Vendors List...

  • Page 30: Installing A Dimm

    1.7.4 Installing a DIMM Unplug the power supply before adding or removing DIMMs or other system components. Failure to do so can cause severe damage to both the motherboard and the components. To install a DIMM: DDR2 DIMM notch Unlock a DIMM socket by pressing the retaining clips outward.

  • Page 31: Expansion Slots

    Turn on the system and change the necessary BIOS settings, if any. See Chapter 2 for information on BIOS setup. Assign an IRQ to the card. Refer to the tables on the next page. Install the software drivers for the expansion card. ASUS P5L-VM 1394 1-19...

  • Page 32: Interrupt Assignments

    1.8.3 Interrupt assignments Standard interrupt assignments Standard Function System Timer Keyboard Controller Re-direct to IRQ#9 Communications Port (COM1)* IRQ holder for PCI steering* Floppy Disk Controller Printer Port (LPT1)* System CMOS/Real Time Clock IRQ holder for PCI steering* IRQ holder for PCI steering* IRQ holder for PCI steering* PS/2 Compatible Mouse Port* Numeric Data Processor...

  • Page 33: Pci Slots

    PCI Express x1 This motherboard supports PCI Express x1 network cards, SCSI cards and other cards that comply with the PCI Express specifications. The figure shows a network card installed on the PCI Express x1 slot. ASUS P5L-VM 1394 1-21...

  • Page 34: Jumpers

    Jumpers Clear RTC RAM (CLRTC) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords.
  • Page 35 500 mA on the +5VSB lead for each USB port; otherwise, the system would not power up. • The total current consumed must NOT exceed the power supply capability (+5VSB) whether under normal condition or in sleep mode. ASUS P5L-VM 1394 1-23...

  • Page 36: 1.10 Connectors

    1.10 Connectors 1.10.1 Rear panel connectors PS/2 mouse port (green). This port is for a PS/2 mouse. Parallel port. This 25-pin port connects a parallel printer, a scanner, or other devices. IEEE 1394a port. This 6-pin IEEE 1394a port provides high-speed connectivity for audio/video devices, storage peripherals, PCs, or portable devices.

  • Page 37: 1.10.2 Internal Connectors

    Pin 5 on the connector is removed to prevent incorrect cable connection when using an FDD cable with a covered Pin 5. FLOPPY NOTE: Orient the red markings on the floppy ribbon cable to PIN 1. Floppy Disk Drive Connector P5L-VM 1394 ASUS P5L-VM 1394 1-25...
  • Page 38 IDE connectors (40-1 pin PRI_IDE) The onboard IDE connectors are for Ultra DMA 100/66/33 signal cables. There are three connectors on each Ultra DMA 100/66/33 signal cable: blue, black, and gray. Connect the blue connector to the motherboard’s IDE connector, then select one of the following modes to configure your device(s).

  • Page 39: Serial Ata Connectors

    Connect the right-angle side of SATA signal cable to SATA device. Or you may connect the right-angle side of SATA cable to the onboard SATA port to avoid mechanical conflict with a long card in PCI2 slot. ASUS P5L-VM 1394 1-27...
  • Page 40 CPU, Power and Chassis fan connectors (4-pin CPU_FAN, 3-pin CHA_FAN) The fan connectors support cooling fans of a total of 1A~2.2A (26.4W max.) at +12V. Connect the fan cables to the fan connectors on the motherboard, making sure that the black wire of each cable matches the ground pin of the connector.
  • Page 41 This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis. COM1 PIN 1 P5L-VM 1394 COM Port Connector The COM module is purchased separately. ASUS P5L-VM 1394 1-29...

  • Page 42: Atx Power Connectors

    ATX power connectors (24-pin EATXPWR and 4-pin ATX12V) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit.
  • Page 43 USB 2.0 specification that supports up to 480 Mbps connection speed. USB78 USB56 P5L-VM 1394 USB 2.0 Connectors Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module is purchased separately. ASUS P5L-VM 1394 1-31...

  • Page 44: Front Panel Audio Connector

    11. Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC’97 audio standard. AAFP HD-audio-compliant Legacy AC’97 compliant definition pin definition P5L-VM 1394 Front Panel Audio Connector •...

  • Page 45: System Panel Connector

    ON turns the system OFF. • Reset button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. ASUS P5L-VM 1394 1-33...
  • Page 46 1-34 Chapter 1: Product introduction...

  • Page 47: Chapter 2: Bios Setup

    This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. BIOS setup...

  • Page 48: Managing And Updating Your Bios

    The following utilities allow you to manage and update the motherboard Basic Input/Output System (BIOS) setup. ASUS EZ Flash 2 (Updates the BIOS using a floppy disk, USB Flash, or the motherboard support CD during POST.) ASUS AFUDOS (Updates the BIOS in DOS mode using a bootable floppy disk.)

  • Page 49: Asus Ez Flash 2 Utility

    2.1.2 ASUS EZ Flash 2 utility The ASUS EZ Flash 2 feature allows you to update the BIOS without having to go through the long process of booting from a floppy disk and using a DOS-based utility. The EZ Flash 2 utility is built-in the BIOS chip so it is accessible by pressing <Alt>...

  • Page 50: Afudos Utility

    Press <Enter>. The utility copies the current BIOS file to the floppy disk. A:\>afudos /oOLDBIOS1.rom AMI Firmware Update Utility - Version 1.19(ASUS V2.07(03.11.24BB)) Copyright (C) 2002 American Megatrends, Inc. All rights reserved. Reading flash ..done Write to file..ok A:\>...

  • Page 51: Updating The Bios File

    Updating the BIOS file To update the BIOS file using the AFUDOS utility: Visit the ASUS website (www.asus.com) and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable floppy disk. Write the BIOS filename on a piece of paper. You need to type the exact BIOS filename at the DOS prompt.

  • Page 52: Asus Crashfree Bios 2 Utility

    2.1.4 ASUS CrashFree BIOS 2 utility The ASUS CrashFree BIOS 2 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using the motherboard support CD, or the floppy disk that contains the updated BIOS file.

  • Page 53: Recovering The Bios From The Support Cd

    Restart the system after the utility completes the updating process. The recovered BIOS may not be the latest BIOS version for this motherboard. Visit the ASUS website (www.asus.com) to download the latest BIOS file. ASUS P5L-VM 1394...

  • Page 54: Asus Update Utility

    2.1.5 ASUS Update utility The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows environment. The ASUS Update utility ® allows you to: • Save the current BIOS file • Download the latest BIOS file from the Internet •...

  • Page 55: Updating The Bios Through The Internet

    To update the BIOS through the Internet: Launch the ASUS Update utility from the Windows desktop by clicking ® Start > Programs > ASUS > ASUSUpdate > ASUSUpdate. The ASUS Update main window appears. Select Update BIOS from Select the ASUS FTP site...

  • Page 56: Updating The Bios Through A Bios File

    To update the BIOS through a BIOS file: Launch the ASUS Update utility from the Windows desktop by ® clicking Start > Programs > ASUS > ASUSUpdate > ASUSUpdate. The ASUS Update main window appears. Select Update BIOS from a file option from the drop-down menu, then click Next.

  • Page 57: Bios Setup Program

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard and . ASUS P5L-VM 1394 2-11...

  • Page 58: Bios Menu Screen

    2.2.1 BIOS menu screen Menu items Menu bar Configuration fields General help Use [ENTER], [TAB] System Time [11:51:19] or [SHIFT-TAB] to System Date [Thu 05/07/2004] select a field. Legacy Diskette A [1.44M, 3.5 in] Use [+] or [-] to Primary IDE Master :[ST320413A] configure system time.

  • Page 59: Menu Items

    /<Page Down> keys to display the Exit other items on the screen. Pop-up window 2.2.9 General help Scroll bar At the top right corner of the menu screen is a brief description of the selected item. ASUS P5L-VM 1394 2-13...

  • Page 60: Main Menu

    Main menu When you enter the BIOS Setup program, the Main menu screen appears, giving you an overview of the basic system information. Refer to section “2.2.1 BIOS menu screen” for information on the menu screen items and how to navigate through them. System Time [11:51:19] Use [ENTER], [TAB]...

  • Page 61: Primary, Third And Fourth Ide Master/Slave

    When set to [Disabled], the data transfer from and to the device occurs one sector at a time. Configuration options: [Disabled] [Auto] ASUS P5L-VM 1394 2-15...

  • Page 62: Ide Configuration

    PIO Mode [Auto] Selects the PIO mode. Configuration options: [Auto] [0] [1] [2] [3] [4] DMA Mode [Auto] Selects the DMA mode. Configuration options: [Auto] [SWDMA0] [SWDMA1] [SWDMA2] [MWDMA0] [MWDMA1] [MWDMA2] [UDMA0] [UDMA1] [UDMA2] [UDMA3] [UDMA4] [UDMA5] SMART Monitoring [Auto] Sets the Smart Monitoring, Analysis, and Reporting Technology.
  • Page 63 S-ATA. Configuration options: [S-ATA+P-ATA] [S-ATA] [P-ATA] IDE Detect Time Out [35] Selects the time out value for detecting ATA/ATAPI devices. Configuration options: [0] [5] [10] [15] [20] [25] [30] [35] ASUS P5L-VM 1394 2-17...

  • Page 64: System Information

    2.3.6 System Information This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. AMIBIOS Version : 0106 Build Date : 07/26/06 Processor Type : Genuine Intel(R) CPU 3.20GHz Speed : 3200 MHz Count System Memory Size...

  • Page 65: Advanced Menu

    CPU internal frequency. Select either one of the preset overclocking configuration options: Manual - allows you to individually set overclocking parameters. Auto - loads the optimal settings for the system. Standard - loads the standard settings for the system. ASUS P5L-VM 1394 2-19...
  • Page 66 The following item appears only when you set the AI Overclocking item to [Manual]. CPU Frequency [200] Displays the frequency sent by the clock generator to the system bus. The value of this item is auto-detected by the BIOS. The values range from 200 to 450.

  • Page 67: Usb Configuration

    Allows you to enable support for operating systems without an EHCI hand-off feature. Configuration options: [Enabled] [Disabled] Do not disable the BIOS EHCI Hand-Off option if you are running a Windows operating system with USB device. ® ASUS P5L-VM 1394 2-21...

  • Page 68: Cpu Configuration

    2.4.3 CPU Configuration The items in this menu show the CPU-related information that the BIOS automatically detects. Configure Advanced CPU settings Sets the ratio between CPU Core Clock and the Manufacturer: Intel FSB Frequency. Brand String: Genuine Intel(R) CPU 3.20GHz NOTE: If an invalid Frequency : 3200 MHz...
  • Page 69 The CPU constantly operates at a lower internal frequency when you set this item to [Minimum]. Configuration options: [Maximum] [Minimum] [Automatic] [Disabled] • Refer to the Appendix for details on how to use the EIST feature. • The motherboard comes with a BIOS file that supports EIST. ASUS P5L-VM 1394 2-23...

  • Page 70: Chipset

    2.4.4 Chipset The Chipset menu allows you to change the advanced chipset settings. Select an item then press <Enter> to display the sub-menu. Advanced Chipset Settings Configure DRAM Timing by SPD [Enabled] Graphic Adapter Priori [PCI Express/Int-VG] Internal Graphics Mode Select [Enabled, 8MB] Graphics memory type [Auto]...

  • Page 71: Onboard Devices Configuration

    Allows you to enable or disable the onboard 1394 controller. Configuration options: [Disabled] [Enabled] OnBoard PCIEX GbE LAN [Enabled] Allows you to enable or disable the onboard PCI Express Gigabit LAN controller. Configuration options: [Disabled] [Enabled] ASUS P5L-VM 1394 2-25...
  • Page 72 LAN Option ROM [Disabled] Allows you to enable or disable the option ROM in the onboard LAN controller. This item appears only when the Onboard LAN item is set to Enabled. Configuration options: [Disabled] [Enabled] Serial Port1 Address [3F8/IRQ4] Allows you to select the Serial Port1 base address. Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3] Parallel Port Address [378]...

  • Page 73: Pci Pnp

    Palette Snooping [Disabled] When set to [Enabled], the pallete snooping feature informs the PCI devices that an ISA graphics device is installed in the system so that the latter can function correctly. Configuration options: [Disabled] [Enabled] ASUS P5L-VM 1394 2-27...

  • Page 74: Power Menu

    IRQ-xx assigned to [PCI Device] When set to [PCI Device], the specific IRQ is free for use of PCI/PnP devices. When set to [Reserved], the IRQ is reserved for legacy ISA devices. Configuration options: [PCI Device] [Reserved] Power menu The Power menu items allow you to change the settings for the Advanced Configuration and Power Interface (ACPI) and the Advanced Power Management (APM).

  • Page 75: Apm Configuration

    When set to [Enabled], this parameter allows you to turn on the system through a PCI LAN or modem card. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled] ASUS P5L-VM 1394 2-29...
  • Page 76 Power On By PCIE Devices [Disabled] When set to [Enabled], this parameter allows you to turn on the system through a PCI Express LAN card. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled] Power On By PS/2 Keyboard [Disabled] Allows you to use specific keys on the keyboard to turn on the system.

  • Page 77: Hardware Monitor

    N/A. Configuration options: [Ignored] [xxxRPM] CPU Q-Fan Control [Disabled] Allows you to enable or disable the ASUS Q-Fan feature that smartly adjusts the fan speeds for more efficient system operation. Configuration options: [Disabled] [Enabled] Chassis Fan Speed [xxxxRPM] or [N/A] or [Ignored] The onboard hardware monitor automatically detects and displays the chassis fan speed in rotations per minute (RPM).

  • Page 78: Boot Menu

    2nd Boot Device [PM-ST330620A] 3rd Boot Device [PS-ASUS CD-S360] 1st ~ xxth Boot Device [1st Floppy Drive] These items specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system.

  • Page 79: Boot Settings Configuration

    This allows you to enable or disable the full screen logo display feature. Configuration options: [Disabled] [Enabled] Set this item to [Enabled] to use the ASUS MyLogo™ feature. Add On ROM Display Mode [Force BIOS] Sets the display mode for option ROM.

  • Page 80: Security

    Interrupt 19 Capture [Disabled] When set to [Enabled], this function allows the option ROMs to trap Interrupt 19. Configuration options: [Disabled] [Enabled] 2.6.3 Security The Security menu items allow you to change the system security settings. Select an item then press <Enter> to display the configuration options. Security Settings <Enter>...

  • Page 81: Change User Password

    The message “Password Installed” appears after you set your password successfully. To change the user password, follow the same steps as in setting a user password. Clear User Password Select this item to clear the user password. ASUS P5L-VM 1394 2-35...

  • Page 82: Tools Menu

    2.7.1 ASUS EZ Flash 2 Allows you to run ASUS EZ Flash 2. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice. Please see page 2-3, section 2.1.2 for details.

  • Page 83: Asus O.c. Profile

    2.7.2 ASUS O.C. Profile This item allows you to store or load multiple BIOS settings. BIOS SETUP UTILITY Tools O.C. PROFILE Configuration Save to Profile 1 O.C. Profile 1 Status : Not Installed O.C. Profile 2 Status : Not Installed...

  • Page 84: Exit Menu

    • This function can support devices such as USB flash disk or floppy disk with FAT 32/16/12 format only. • When loading multiple BIOS setting, only the xxx.CMO file can be loaded. • When storing multiple BIOS setting, the system will automatically save the BIOS file to xxx.CMO format.

  • Page 85: Discard Changes

    Setup menus. When you select this option or if you press <F5>, a confirmation window appears. Select Ok to load default values. Select Exit & Save Changes or make other changes before saving the values to the non-volatile RAM. ASUS P5L-VM 1394 2-39...
  • Page 86 2-40 Chapter 2: BIOS setup...

  • Page 87: Chapter 3: Software Support

    This chapter describes the contents of the support CD that comes with the motherboard package. Software support...

  • Page 88: Installing An Operating System

    The contents of the support CD are subject to change at any time without notice. Visit the ASUS website(www.asus.com) for updates. 3.2.1 Running the support CD Place the support CD to the optical drive.

  • Page 89: Drivers Menu

    The drivers menu shows the available device drivers if the system detects installed devices. Install the necessary drivers to activate the devices. ASUS InstAll-Drivers Installation Wizard Installs the ASUS InstAll-Drivers Installation Wizard for all drivers. Intel(R) Chipset Inf Update Program This item installs the Intel Chipset INF Update Program.

  • Page 90: Utilities Menu

    ® ® print documents in Portable Document Format (PDF). ASUS Update The ASUS Update utility allows you to update the motherboard BIOS in a Windows environment. This utility requires an Internet connection either ® through a network or an Internet Service Provider (ISP).

  • Page 91: Manuals Menu

    Reader from the Utilities menu before opening a ® ® user manual file. 3.2.5 ASUS Contact information Click the Contact tab to display the ASUS contact information. You can also find this information on the inside front cover of this user guide. ASUS P5L-MX...
  • Page 92 Chapter 3: Software support...

  • Page 93: Cpu Features

    The Appendix describes the CPU features that the motherboard supports. CPU features...

  • Page 94: Appendix: Cpu Features

    32-bit operating systems. • The motherboard comes with a BIOS file that supports EM64T. You can download the latest BIOS file from the ASUS website (www.asus. com/support/download/) if you need to update the BIOS file. See Chapter 2 for details.

  • Page 95: Using The Eist

    Click Apply, then click OK. 10. Close the Display Properties window. After you adjust the power scheme, the CPU internal frequency slightly decreases when the CPU loading is low. The screen displays and procedures may vary depending on the operating system. ASUS P5L-VM 1394...

  • Page 96: Intel ® Hyper-Threading Technology

    Intel Hyper-Threading Technology ® • The motherboard supports Intel Pentium 4 LGA775 processors ® ® with Hyper-Threading Technology. • Hyper-Threading Technology is supported under Windows XP and ® Linux 2.4.x (kernel) and later versions only. Under Linux, use the Hyper-Threading compiler to compile the code. If you are using any other operating systems, disable the Hyper-Threading Techonology item in the BIOS to ensure system stability and performance.
