Samsung LN40A650A1F Connection Manual

Network Connection - Wireless
You can connect to the Samsung's Infolink network wirelessly through a wireless IP sharer.
The LAN Port on
Wireless IP sharer
the Wall
LAN Cable
You must use the Samsung Wireless LAN Adapter for InfoLink(WIS-08BG) to use a wireless network.
➣
The Samsung Wireless LAN Adapter for InfoLink is sold separately. Contact a Samsung Electronics agent or service
➣
center for purchasing.
To use a wireless network, your TV must be connected to a wireless IP sharer.
➣
If the wireless IP sharer supports DHCP, you TV can use a DHCP or static IP address to connect to the wireless
➣
network.
You must use a wireless IP sharer that supports IEEE 802.11 B or IEEE 802.11G.
➣
If the wireless IP sharer allows you to turn on/off the Ping connection function, turn it on.
➣
Set the wireless IP sharer to Infrastructure mode. Ad-hoc mode is not supported.
➣
Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer
➣
is currently being used by another device nearby, this will result in interference and communications may fail.
When applying the security key for the AP (wireless IP sharer), only the following is supported.
➣
• 1) Authentication Mode : WEP, WPAPSK, WPA2PSK
• 2) Encryption Type : WEP, TKIP, AES
If you apply a security system other than the systems listed above, it will not work with the TV.

Network selection

Select Cable or Wireless as the method to connect to the Samsung's Infolink
network.
1.
Press the MENU button to display the menu.
Press the ▲ or ▼ button to select "Setup", then press the ENTER
2.
Press the ▲ or ▼ button to select "Network selection", then press the
ENTER button.
3.
Press the ▲ or ▼ button to select "Cable" or "Wireless", then press the
ENTER button.
• Cable: Connect to Samsung's Infolink network using a cable.
• Wireless: Connect to Samsung's Infolink network wirelessly.
The menu is activated only if the Samsung Wireless LAN Adapter for
➣
InfoLink is connected. (See page 107)
TV Side Panel
Wireless LAN Adapter
for InfoLink
button.
1.
Connect the Samsung
Infolink Wireless adapter
into the Wiselink terminal
of the TV.
Language : English
Time
Network selection : Cable
Cable Network Setup
Wireless Network Setup
V-Chip
Caption
External Settings
Entertainment : Off
Energy Saving : Off
Language : English
Time
Network selection : Cable Cable
Wireless
Cable Network Setup
Wireless Network Setup
V-Chip
Caption
External Settings
Entertainment : Off
Energy Saving : Off
►
►
