Laser Printer

Quick Reference

Loading paper and

specialty media

Loading the standard or
optional 500-sheet trays
The printer has two standard 500-sheet trays (Tray 1 and Tray 2),
and it may have one or more optional 500-sheet trays. All
500-sheet trays support the same paper sizes and types. Paper may
be loaded in the trays in either the long-edge or short-edge
orientation.
1
Pull the tray completely out.
2
Squeeze and slide the width and length guides to the correct
positions for the paper size being loaded.
3
Flex the sheets back and forth to loosen them, and then fan
them. Do not fold or crease the paper. Straighten the edges on
a level surface.
4
Load the paper stack with the recommended print side faceup.
Load the paper in either the long-edge or short-edge
orientation as shown.
Notes:
•
Load sizes larger than A4 in the short-edge orientation.
•
Make sure the paper is below the max fill line located on
the edge of the paper tray. Overloading the tray can cause
paper jams and possible printer damage.
1
5
Make sure the paper guides are secure against the edges of
the paper.
6
Insert the tray.
7
If the paper type you loaded differs from the type that was
previously loaded in the tray, then change the Paper Type
setting for the tray.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W850 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark W850

Summary of Contents for Lexmark W850

  • Page 1: Laser Printer

    Laser Printer Squeeze and slide the width and length guides to the correct positions for the paper size being loaded. Quick Reference Loading paper and specialty media Make sure the paper guides are secure against the edges of the paper. Loading the standard or Insert the tray.

  • Page 2: Clearing Jams

    202 paper jam Clearing Area B Clearing jams Open Door B. Clearing Area A 200–201 paper jams Open Door A by pushing the release latch up and lowering the door. Open Door A by pushing the release latch up and lowering the door.

  • Page 3: 203 Paper Jam

    203, 230–231 paper jams Pull the jam up. Remove the jam. 203 paper jam Open Door A by pushing the release latch up and lowering the door. Close Door E. Close Door A. Close Door D. Open Door A by pushing the release latch up and lowering the 230 paper jam CAUTION—HOT SURFACE: The inside of the printer door.

  • Page 4: 231 Paper Jam

    231 paper jam Open Door E by pushing the release latch and lowering the Open Door A by pushing the release latch up and lowering the door. door. Open Door D. CAUTION—HOT SURFACE: The inside of the printer Pull the jam up. might be hot.

  • Page 5: 24X Paper Jam

    24x paper jam Jam in the optional tray Clearing jam in Door A Pull the tray out. Open Door A by pushing the release latch up and lowering the Jam in Tray 1 door. Remove Tray 1 from the printer. CAUTION—HOT SURFACE: The inside of the printer might be hot.

  • Page 6: 241 Paper Jam

    Clearing jam in Door B 241 paper jam Open Tray 1, and then remove any crumpled paper from the tray. Open Door B. Open Door C. Insert Tray 1. 250 paper jam Remove the paper from the multipurpose feeder. Pull the jam up and toward you. Pull the jam up and toward you.

  • Page 7: 282 Paper Jam

    280–282 paper jams Open Door F. Remove the jam. 280-281 paper jams Open Door A by pushing the release latch up and lowering the door. Close Door F. 283, 289 staple jams 283 paper jam Remove the jam. Lift Door H. CAUTION—HOT SURFACE: The inside of the printer might be hot.
  • Page 8 289 staple error Firmly pull the colored tab to remove the staple cartridge. Press down on the staple guard until it snaps securely into place. Open Door G. Push the cartridge holder firmly into the stapler until the holder clicks into place. Use the metal tab to lift the staple guard, and then pull out the sheet of staples.
  • Page 9 28x paper jam Open Door G. Remove the jam. 284 paper jam Open Door F. Close Door H. 285–286 paper jams Lift Door H. Remove the jam. Remove the jam. Close Door G. Lift Door H. Close Door F. Remove the jam. Close Door H.
  • Page 10 287–288 paper jams Remove the jam. Close Door G. Open Door F. Remove the jam. Close Door F. Open Door G.
