  • Page 1 User’s Manual U200...
  • Page 2 Copyright © 2006 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.
  • Page 3 Windows and Microsoft are registered trademarks of Microsoft Corporation. Photo CD is a trademark of Eastman Kodak. Sonic RecordNow! is a registered trademark of Sonic Solutions. Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license. i.LINK is a trademark of Sony Corporation.

  • Page 4: Working Environment

    Any consequences resulting from the use of this product in working environments that are not approved or the use is restricted are not the responsibility of TOSHIBA Corporation. The consequences of the use of this product in those working environments may be: ■...
  • Page 5 Modem warning notice Conformity Statement The equipment has been approved to [Commission Decision “CTR21”] for pan-European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.

  • Page 6: Optical Disc Drive Safety Instructions

    Optical disc drive safety instructions Be sure to check the international precautions at the end of this section. Panasonic Communications DVD-ROM & CD-R/RW drive UJDA765 ■ The DVD-ROM & CD-R/RW drive UJDA765 employs a laser system. To ensure proper use of this product, please read this instruction manual carefully and retain for future reference.
  • Page 7 DVD Super Multi with Double Layer Recording UJ-842 ■ The DVD Super Multi drive with Double Layer Recording model employs a laser system. To ensure proper use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.
  • Page 8 International precautions CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest “AUTHORIZED service station.”...
  • Page 9 OBS! Apparaten innehåller laserkomponent som avger laserstråining överstigande gränsen för laserklass 1. VAROITUS. Suojakoteloa si saa avata. Laite sisältää laserdiodin, joka lähetää näkymätöntä silmilie vaarallista lasersäteilyä. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER’S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
  • Page 10 User’s Manual...

  • Page 11: Table Of Contents

    Table of Contents Preface General Precautions Introduction Chapter 1 Equipment checklist........1-1 Features.
  • Page 12 Replacing the battery pack ....... . .6-12 TOSHIBA Password Utility ....... . .6-13 Power-up modes .
  • Page 13 TOSHIBA support ........
  • Page 14 User’s Manual...

  • Page 15: Preface

    Preface Congratulations on your purchase of the U200 computer. This powerful notebook computer provides excellent expansion capability, including multimedia devices, and it is designed to provide years of reliable, high-performance computing. This manual tells how to set up and begin using your U200 computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.
  • Page 16 Preface Chapter 7, Setup, explains how to configure the computer using the HW Setup program and TPM (optional). Chapter 8, Optional Devices, describes the optional hardware available. Chapter 9, Troubleshooting, provides helpful information on how to perform some diagnostic tests, and suggests courses of action if the computer doesn’t seem to be working properly.
  • Page 17 Preface Display Names of windows or icons or text generated by the computer that appear on its display screen are presented in the type face you see to the left. Messages Messages are used in this manual to bring important information to your attention.
  • Page 18 Preface xviii User’s Manual...

  • Page 19: General Precautions

    General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the general precautions below and to note the cautions included in the text of the manual.
  • Page 20 General Precautions PC card overheating Some PC cards can become hot with prolonged use. Overheating of a PC card can result in errors or instability in the PC card operation. Also be careful when you remove a PC card that has been used for a long time. Mobile phone Use of mobile phone can interfere with the audio system.

  • Page 21: Equipment Checklist

    Some of the features described in this manual may not function properly if you use an operating system that was not preinstalled by TOSHIBA. Equipment checklist Carefully unpack your computer. Save the box and packing materials for future use.
  • Page 22 ■ DVD Video Player ■ InterVideo WinDVD Creator ■ Fingerprint Utility (provided with some models) ■ RecordNow! Basic for TOSHIBA (preinstalled with some models) ■ DLA for TOSHIBA (preinstalled with some models) ■ TOSHIBA Power Saver ■ TOSHIBA ConfigFree ■...
  • Page 23 DVD Video Player ■ InterVideo WinDVD Creator ■ Fingerprint Utility (provided with some models) ■ TOSHIBA Disc Creator (preinstalled with some models) ■ TOSHIBA Direct Disc Writer (preinstalled with some models) ■ TOSHIBA Power Saver ■ TOSHIBA ConfigFree ■ TOSHIBA Assist ■...

  • Page 24: Features

    Introduction Features The computer uses TOSHIBA’s advanced Large Scale Integration (LSI), Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to provide compact size, minimum weight, low power usage, and high reliability. This computer incorporates the following features and benefits: Processor Built-in The computer is equipped with one of the ®...
  • Page 25 Introduction Memory Slots 256, 512, 1,024 or 2,048 MB memory modules can be installed in the two memory slots for a maximum of 4,096 MB (Intel ® 945GM model) or a ® maximum of 2,048 MB (Intel 940GML model) system memory. Legal Footnote (Memory (Main System)) For more information on the Legal Footnote regarding Memory (Main System), please refer to the Legal Footnotes section in Chapter 10.

  • Page 26: Optical Disc Drive

    Introduction Disks Hard disk drive Available in five sizes. ■ 40.0 billion bytes (37.26 GB) ■ 60.0 billion bytes (55.89 GB) ■ 80.0 billion bytes (74.53 GB) ■ 100.0 billion bytes (93.16 GB) ■ 120.0 billion bytes (111.79 GB) Part of the space on the hard disk drive is reserved as administration space.
  • Page 27 Introduction DVD Super Multi Some models are equipped with a full-size DVD drive Double Layer Super Multi drive module that lets you record data to rewritable CD/DVDs as well as run either 12cm (4.72") or 8cm (3.15") CD/DVDs without using an adaptor. It reads DVD-ROMs at maximum 8 speed and CD-ROMs at maximum 24 speed.

  • Page 28: Pointing Device

    Introduction Keyboard Built-in 84 keys or 85 keys, compatible with IBM ® enhanced keyboard, embedded numeric overlay, dedicated cursor control, keys. Refer to Chapter 5, Keyboard, for details. Pointing Device Built-in Touch Pad A Touch Pad and control buttons in the palm rest enable control of the on-screen pointer and scrolling of windows.
  • Page 29 Introduction Communications Modem An internal modem provides capability for data and fax communication supporting the V.90 (V.92) standards. The speed of data transfer and fax depends on analog telephone line conditions. It has a modem jack for connecting to a telephone line.
  • Page 30 Introduction Wireless LAN Some computers in this series are equipped with a Wireless LAN card that is compatible with other LAN systems based on Direct Sequence Spread Spectrum/Orthogonal Frequency Division Multiplexing radio technology that complies with the IEEE 802.11 Standard (Revision A, B or G). ■...

  • Page 31: Special Features

    Allows the connection of a security lock to anchor the computer to a desk or other large object. Special features The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use. Front operation...
  • Page 32 LCD display panel is opened. You can specify the setting in the When I close the lid item of the Setup Actions tab in TOSHIBA Power Saver. Low battery When battery power is exhausted to the point that...

  • Page 33: Utilities

    TOSHIBA Power To access the power management program, click Saver start, click Control Panel, click Performance and Maintenance and click the TOSHIBA Power Saver icon. HW Setup This program lets you customize your hardware settings according to the way you work with your computer and the peripherals you use.
  • Page 34 This utility lets you assign applications or functions to the built-in buttons. To access this utility, click start, point to Control Panel, choose Printers and Other Hardware and click the Toshiba Controls icon. Fingerprint Utility This product has a Fingerprint Utility installed for (provided with some...
  • Page 35 All Programs, point to TOSHIBA, point to Utilities and click PC Diagnostic Tool. TOSHIBA ConfigFree TOSHIBA ConfigFree is a suite of utilities to allow easy control of communication devices and network connections. TOSHIBA ConfigFree also allows you to find communication problems and create profiles for easy switching between locations and communication networks.
  • Page 36 On/Off Utility Pad using the Fn + F9 Hot key. TOSHIBA Mic Effect The TOSHIBA Mic Effect utility provides you with Echo Canceller and Microphone Array functions. The echo cancellation function removes or reduces any harsh echoes or howling sounds that occur when playing audio sounds recorded with a microphone through the speakers.

  • Page 37: Options

    A 256, 512, 1,024 or 2,048 MB memory module (DDR2-533/667) can easily be installed in the computer. Battery Pack An additional battery pack can be purchased from your TOSHIBA dealer. Use it as a spare or replacement. User’s Manual 1-17...
  • Page 38 When connected to one of the computer’s USB ports, the Bluetooth USB Adaptor allows wireless Adaptor communications to be carried out with Bluetooth-compatible equipment. You can buy this adaptor from your TOSHIBA dealer. Wireless Optical The Bluetooth Wireless Mouse is an optical Mouse with...

  • Page 39: Chapter 2 The Grand Tour

    Chapter 2 The Grand Tour This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer. Legal Footnote (Non-applicable Icons) For more information on the Legal Footnote regarding Non-applicable Icons, please refer to the Legal Footnotes section in Chapter 10. Click the *8.

  • Page 40: Left Side

    The Grand Tour i.LINK (IEEE1394) This port allows you to connect an external port device, such as a digital video camera for high-speed data transfer. Microphone A built-in microphone lets you record sound into your applications. Refer to the Sound system section in Chapter 4, Operating Basics.
  • Page 41 The Grand Tour ■ Do not connect any cable other than a LAN cable to the LAN jack. It could cause damage or malfunction. ■ Do not connect the LAN cable to a power supply. It could cause damage or malfunction. Link indicator This indicator glows green when the computer is (green)

  • Page 42: Right Side

    The Grand Tour ■ Connection to any communication line other than an analog phone line could cause a PC system failure. ■ Connect the built-in modem only to ordinary analog phone lines. ■ Never connect the built-in modem to a digital line (ISDN). ■...
  • Page 43 The Grand Tour Volume control Use this dial to adjust the volume of the stereo speakers and the stereo headphones. Move the Volume control to the right to increase the volume and to the left to decrease the volume. To mute the sound press the Fn + Esc keys. Refer to the Hot keys section in Chapter 5,...

  • Page 44: Back Side

    The Grand Tour Back side The following figure shows the computer’s back side. Battery pack The back side of the computer Battery pack The battery pack powers the computer when the AC adaptor is not connected. For detailed information on the battery pack, refer to Chapter 6, Power and Power-Up Modes.

  • Page 45: Front With The Display Open

    The Grand Tour Front with the display open This section shows the computer with the LCD display panel open. Refer to the appropriate illustration for details. To open the display, slide the display latch on the front of the LCD display panel and lift up. Position the LCD display panel at a comfortable viewing angle.
  • Page 46 Hibernation Mode. Use the TOSHIBA Power Saver Utility to enable or disable this feature. The default is “enabled”. Refer to the TOSHIBA Power Saver Utility and Panel Power Off/On items in Chapter 1, Special features, for details on settings.

  • Page 47: System Indicators

    The Grand Tour System indicators LEDs above the icons, light when various computer operations are in progress. System indicators DC IN The DC IN indicator glows blue when DC power is supplied from the AC power adaptor. If the adaptor’s output voltage is abnormal or if the power supply malfunctions, this indicator flashes orange.

  • Page 48: Keyboard Indicators

    The Grand Tour Keyboard indicators The figures below show the positions of the keypad overlay indicators and the Caps Lock indicator. When the Arrow mode indicator glows the keypad overlay lets you control the cursor. When the Numeric mode indicator glows the keypad overlay lets you enter numbers.

  • Page 49: Usb Floppy Disk Drive (Optional)

    The Grand Tour USB floppy disk drive (optional) The USB floppy disk drive accommodates 1.44-megabyte or 720-kilobyte floppy disks and connects to the USB port. It is supplied as standard with some models and as an option with others. USB connector Disk-In-Use Indicator Floppy disk slot...

  • Page 50: Optical Disc Drives

    Writable discs This section describes the types of writable CD/DVD discs. Check the specifications for your drive to for the type of discs it can write. Use TOSHIBA Disc Creator (optional) to write compact discs. Refer to Chapter Operating Basics.

  • Page 51: Dvd Super Multi Drive

    The Grand Tour Formats The drives support the following formats: ■ ■ CD-ROM DVD -Video ■ ■ DVD-ROM CD-Text ■ ■ CD-DA CD-ROM Mode 1, Mode 2 ■ ■ Photo CD™ Enhanced CD (CD-EXTRA) (single/multi-session) ■ Addressing Method 2 ■ CD-ROM XA Mode 2 ■...

  • Page 52: Ac Adaptor

    For use in other regions, please buy power cords that conform to safety rules and regulations in the particular region. Always use the Toshiba AC adaptor that was provided with your PC and the Toshiba Battery Charger (that may have been provided with your PC), or use Toshiba recommended alternate models to avoid any risk of fire or other damage to the PC.

  • Page 53: Chapter 3 Getting Started

    Chapter 3 Getting Started This chapter provides basic information to get you started using your computer. It covers the following topics: ■ Setting up your work space - for your health and safety Be sure also to read the Instruction Manual for Safety & Comfort. This guide, which is included with the computer, explains product liability.

  • Page 54: General Conditions

    PC, it could cause a system failure, malfunction or loss of data. If dust contaminates the PC, do not turn on the power. Take it to an authorized Toshiba service provider before you use it. ■ Never place your PC near an object that generates a magnetic field, such as a speaker or TV.

  • Page 55: Placement Of The Computer

    Getting Started ■ Leave ample ventilation room for the fan. Do not block the vents. ■ If the PC interferes with radio equipment, turn the PC power off immediately. Such interference could cause equipment malfunction. ■ Never place your PC on a shaky table, uneven, tilted surface or other unstable location.

  • Page 56: Seating And Posture

    Getting Started Seating and posture Maintain a comfortable working posture when using your PC where your body joints are naturally aligned to reduce stress on different parts of your body. Consider the following: Below eye level 90°angles Foot rest Posture and positioning of the computer ■...

  • Page 57: Work Habits

    Getting Started Lighting Select the right level of illumination and place your PC appropriately to minimize glare from overhead lights, desk lamps and windows. Glare on the LCD or monitor may cause eye strain, eye fatigue or headaches. Consider the following suggestions regarding lighting your work environment: ■...

  • Page 58: Connecting The Ac Adaptor

    Getting Started Strategic Rest Breaks Take short, strategically spaced rest breaks to avoid eye strain and body discomforts. For more specific recommendations on the safety and comfort of your computer environment, customers in the United States may visit the United States Department of Labor, Occupational Safety &...
  • Page 59 Getting Started ■ Always use the Toshiba AC adaptor that was provided with your PC and the Toshiba Battery Charger (that may have been provided with your PC), or use Toshiba recommended alternate models to avoid any risk of fire or other damage to the PC. Use of an incompatible AC adaptor or Battery Charger could cause fire or damage to the PC possibly resulting in serious injury.

  • Page 60: Opening The Display

    Getting Started Connecting the power cord to the AC adaptor (3-pin plug) Depending on the model, a 2-pin or 3-pin plug set of the above may be bundled. 2. Connect the AC adaptor’s DC output plug to the DC IN 15V jack on the left side of the computer.

  • Page 61: Turning On The Power

    Getting Started 2. While holding down the palm rest with one hand so that the main body is not raised, lift the panel slowly. Adjust the angle of the panel to provide optimal clarity. Be careful not to open the display panel too far as this could put stress on the display panel’s hinges and cause damage.

  • Page 62: Starting Up For The First Time

    Getting Started Starting up for the first time When you first turn on the power, the computer’s initial screen is the Microsoft Windows XP Startup Screen Logo. Follow the on-screen directions for each screen. During setup, you can click the Back button to return to the previous screen.
  • Page 63 Getting Started ■ When the AC adaptor is connected, the computer will go into Standby Mode according to the settings in the TOSHIBA Power Saver utility. ■ To restore operation from Standby Mode, press the power button or press any key. The latter action only works on the internal keyboard if the Wake-up on Keyboard option is enabled in HW Setup.

  • Page 64: Hibernation Mode

    Getting Started 3. Press the power button. This feature must be enabled. Refer to the Setup Actions tab in TOSHIBA Power Saver Utility described in the Control Panel. Open Performance and Maintenance and open TOSHIBA Power Saver. When you turn the power back on, you can continue where you left when you shut down the computer.

  • Page 65: Starting Hibernation Mode

    3. Select the Hibernate window in the Power Options Properties, select the Enable hibernation check box and click the Apply button. 4. Open TOSHIBA Power Saver. 5. Select the Setup Action window. 6. Enable the desired Hibernation settings for When I press the power button and When I close the lid.

  • Page 66: Restarting The Computer

    2. Switch on the computer and, when the In Touch with Tomorrow TOSHIBA prompt appears, press the F12 key to display the Boot Menu. 3. Use the up or down cursor key to select the CD-ROM/DVD drive in the display menu.

  • Page 67: Restoring Toshiba Utilities And Drivers

    Restoring TOSHIBA utilities and drivers If Windows is working properly, individual drivers or applications can be separately restored. The TOSHIBA Tools & Utilities folder (C:\TOOLSCD) contains drivers and applications, which are included with your computer system. If your system drivers or applications have become damaged in some way, you can reinstall most of the components from this folder.
  • Page 68 Getting Started 3-16 User’s Manual...

  • Page 69: Chapter 4 Operating Basics

    Chapter 4 Operating Basics This chapter describes the basic operations of your computer and precautions when using it, as well as the handling of CD/DVD. Using the Touch Pad To use the Touch Pad, simply touch and move your fingertip across it in the direction you want the on-screen pointer to go.

  • Page 70: Using The Fingerprint Sensor (Provided With Some Models)

    Operating Basics You can also tap the Touch Pad to perform functions similar to those of the left button. Click: Tap once Double-click: Tap twice Drag and drop: Tap to select the material you want to move. Leave your finger on the Touch Pad after the second tap and move the material.

  • Page 71: How To Delete The Fingerprint Data

    Operating Basics Observe the following before you place your finger on the sensor whether for fingerprint enrollment/registration or recognition. ■ Wash and dry your hands thoroughly. ■ Remove static electricity from your fingers by touching any metal surface. Static electricity is a common cause of sensor failures, especially when the weather is dry.

  • Page 72: Points To Note About The Fingerprint Utility

    Toshiba does not guarantee that the fingerprint sensor will recognize the enrolled user or accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of this fingerprint recognition software or utility.

  • Page 73: Set Up Procedure

    Operating Basics Set Up Procedure Please use the following procedure when first using fingerprint authentication. Fingerprint Registration Enroll the required authentication data using the User Enrollment Wizard. ■ The fingerprint authentication uses the same Windows logon ID and password. If the Windows logon password has not been setup, please do so before registration.

  • Page 74: Window Logon Via Fingerprint Authentication

    ■ It is necessary to register the User Password before using the Fingerprint Power-on Security and its extended function, the Fingerprint Single Sign-On Feature. Please use TOSHIBA Password Utility to register the User Password. ■ If you fail fingerprint authentication more than five times, you must enter the User Password or Supervisor Password manually to start the computer.

  • Page 75: How To Enable Fingerprint Power-On Security Settings

    User/BIOS Password and Windows Logon Password before using the Fingerprint Power-on Security and this Fingerprint Single Sign-On Feature. Please use TOSHIBA Password Utility to register your User/BIOS Password. If Windows Logon is not the default for your system, see Manual to register your Windows Logon Password.

  • Page 76: Front Operation Buttons

    TOSHIBA does not guarantee that the Fingerprint Utility will accurately screen out unauthorized users at all times. TOSHIBA is not liable for any failure or damage that might arise out of the use of the fingerprint software or utility.
  • Page 77 Operating Basics Internet button Press this button to launch an Internet browser. If the computer’s power is off, you can press this button to turn on the computer’s power and launch the browser automatically in one step. CD/DVD button Pressing this button will launch an application program that allows for watching CD/DVD.

  • Page 78: Using The Usb Floppy Disk Drive (Optional)

    Operating Basics Using the USB floppy disk drive (optional) An optional USB floppy disk drive accommodates 1.44-megabyte or 720-kilobyte floppy disks and connects to the USB port. Refer to Chapter 2, The Grand Tour, for more information. It is supplied as standard with some models and as an option with others.

  • Page 79: Using Optical Disc Drives

    Operating Basics Using optical disc drives The full-size drive provides high-performance execution of CD/DVD-ROM-based programs. You can run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs without an adaptor. An ATAPI interface controller is used for CD/DVD-ROM operation. When the computer is accessing a CD/DVD-ROM, an indicator on the drive glows.
  • Page 80 Operating Basics 3. Lay the CD/DVD, label side up, in the disc tray. Laser lens Inserting a CD/DVD When the disc tray is fully opened, the edge of the computer will extend slightly over the CD/DVD tray. Therefore, you will need to turn the CD/DVD at an angle when you place it in the disc tray.

  • Page 81: Removing Discs

    Operating Basics 5. Push the center of the disc tray to close it. Press gently until it locks into place. If the CD/DVD is not seated properly when the disc tray is closed, the CD/DVD might be damaged. Also, the disc tray might not open fully when you press the eject button.
  • Page 82 Operating Basics 2. The CD/DVD extends slightly over the sides of the disc tray so you can hold it. Hold the CD/DVD gently and lift it out. Removing a CD/DVD 3. Push the center of the disc tray to close it. Press gently until it locks into place.

  • Page 83: Writing Cds On Dvd-Rom&Cd-R/Rw Drive

    RICOH Co., Ltd. Ultra-Speed CD-RW: MITSUBISHI CHEMICAL CORPORATION TOSHIBA has confirmed the operation of CD-R and CD-RW media of the manufacturers above. Operation of other media cannot be guaranteed. ■ The actual number of rewrites to CD-RW is affected by the quality of the disc and the way it is used.

  • Page 84: When Writing Or Rewriting

    Write from the computer’s hard disk drive to the CD. Do not try to write from shared devices such as a LAN server or any other network device. ■ Writing with software other than Sonic TOSHIBA Disc Creator (optional) has not been confirmed. Therefore, operation with other software cannot be guaranteed.

  • Page 85: Writing Cd/Dvds On Dvd Super Multi Drive

    You can use the DVD Super Multi drive to write data to either CD-R/RW or DVD-R/-R DL/-RW/+R/+R DL/+RW/-RAM discs. The TOSHIBA Disc Creator (optional), the TOSHIBA Direct Disc Writer (optional), the RecordNow! Basic for TOSHIBA (optional) and the DLA for TOSHIBA (optional) are provided for writing. ■...

  • Page 86: Before Writing Or Rewriting

    Based on TOSHIBA’s limited compatibility testing, we suggest the following manufacturers of CD-R/RW and DVD-R/-R DL/+R/+R DL/-RW/+RW/-RAM disc. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates. CD-R: TAIYO YUDEN CO., LTD.
  • Page 87 Operating Basics This drive cannot use discs that allow writing faster than 16 speed (DVD-R, DVD+R), 6 speed (DVD-RW), 4 speed (DVD+RW), 5 speed (DVD-RAM), 4 speed (DVD-R DL, Double Layer supported model only), 8 speed (DVD+R DL, Double Layer supported model only). ■...
  • Page 88 LAN server or any other network device. ■ Writing with software other than RecordNow! Basic for TOSHIBA (optional), TOSHIBA Disc Creator (optional) and InterVideo WinDVD Creator Platinum is not recommended. When writing or rewriting Please observe/consider the following when you write or rewrite to a CD-R/RW, DVD-R/-R DL/-RW/-RAM or DVD+R/+R DL/+RW disc.
  • Page 89 Operating Basics RecordNow! Basic for TOSHIBA (preinstalled with some models) This function is only in Windows XP Professional model. Note the following limitations when you use RecordNow!: ■ DVD-Video cannot be created using RecordNow!. ■ DVD-Audio cannot be created using RecordNow!.
  • Page 90 TOSHIBA Disc Creator cannot record in packet format. ■ You might not be able to use the “Disk Backup” function of TOSHIBA Disc Creator to back up a DVD-R/-R DL/-RW or DVD+R/+R DL/+RW disc that was made with other software on a different DVD-R/-R DL/-RW or DVD+R/+R DL/+RW recorder.

  • Page 91: Data Verification

    4. Mark the Verify written data check box. 5. Select File Open or Full Compare mode. 6. Click the OK button. DLA for TOSHIBA (preinstalled with some models) This function is only in Windows XP Professional model. Note the following limitations when you use DLA: ■...

  • Page 92: When Using Windvd Creator Platinum

    Operating Basics TOSHIBA Direct Disc Writer (preinstalled with some models) This function is only in Windows XP Home Edition model. Note the following limitations when you use TOSHIBA Direct Disc Writer: ■ This software supports only rewritable discs (DVD+RW, DVD-RW, and CD-RW).

  • Page 93: How To Learn More About Intervideo Windvd Creator

    Operating Basics How to make a DVD-Video Simplified steps for making a DVD-Video from video data captured from a DV-Camcorder: 1. Click Start -> All Programs -> InterVideo WinDVD Creator2 -> InterVideo WinDVD Creator to launch WinDVD Creator. 2. Click Capture button then capture the video data from the DV-> Camcorder via IEEE1394.
  • Page 94 2. Before recording the video to DVD ■ When you record to DVD discs, please use only media recommended by TOSHIBA. ■ Do not set the working drive to a slow device like a USB 1.1 hard disk drive or it will fail to write the DVD.

  • Page 95: Media Care

    Operating Basics 4. About recorded DVDs ■ Some DVD-ROM drives for personal computers or other DVD players may not be able to read DVD-R/+R/-R DL/+R DL/-RW/+RW/-RAM discs. ■ When playing your recorded disc on your computer, please use the WinDVD software application. ■...

  • Page 96: Sound System

    Operating Basics 5. Never put a floppy disk in a location where water or other liquid may contact it or where it is excessively damp. It could cause data loss. Never use a wet or damp floppy disk. It could damage the floppy disk drive or other devices.

  • Page 97: Modem

    Operating Basics SoundMAX control panel The SoundMAX control panel lets you control additional functions for the Microphone Enhancement and Audio Power Management. To launch the SoundMAX Control Panel, follow the steps below. 1. Click start and click Control Panel. 2. If you are viewing the Control Panel in Category View, click on Switch to Classic View.

  • Page 98: Region Selection

    Check the specified areas carefully before using it. To select a region, follow the steps below. 1. Click start, point to All Programs, point to TOSHIBA, point to Networking and click Modem Region Select. Do not use the Country/Region Select function in the Modem setup utility in the Control Panel if the function is available.

  • Page 99: Modem Selection

    Operating Basics Open dialog box, if the modem and Telephony Current Location region code do not match. A warning dialog box is displayed if current settings for region code and telephony location are incorrect. Modem Selection If the computer cannot recognize the internal modem, a dialog box is displayed.
  • Page 100 Operating Basics 2. Plug the other end of the modular cable into a telephone jack. Telephone jack Modular cable Modem jack Connecting the internal modem Do not pull on the cable or move the computer while the cable is connected. If you use a storage device such as an optical disc drive or hard disk drive connected to a 16-bit PC card, you might experience the following modem problems:...

  • Page 101: Wireless Communications

    ■ TOSHIBA is not liable for the loss of data due to eavesdropping or illegal access through the wireless LAN and the damage thereof. User’s Manual...

  • Page 102: Bluetooth Wireless Technology

    Please refer also to the electronic information which is included with each software. This Bluetooth™ Stack is based on Bluetooth™ Version 1.1/1.2/2.0+EDR specification. TOSHIBA cannot confirm compatibility between any PC products and/or other electronic devices that use Bluetooth™ other than TOSHIBA mobile PCs.

  • Page 103: Product Support

    TOSHIBA 1. Install: ® On Windows2000 or Windows XP, Bluetooth™ Stack for Windows TOSHIBA does not have a digital signature. 2. Fax application software: Regarding FAX application software, there are some software that you cannot use on this Bluetooth™ Stack.

  • Page 104: Lan

    Operating Basics Wireless communication Indicator The wireless communication indicator indicates the status of the wireless communication functions. Indicator status Indication Indicator off Wireless communication switch is set to off. Automatic power down because of overheating. Power malfunction. Indicator glows Wireless communication switch is on. Wireless LAN or Bluetooth can be used by an application.

  • Page 105: Connecting Lan Cable

    Operating Basics If you are using Fast Ethernet LAN (100 megabits per second, 100BASE-TX), be sure to connect with a CAT5 cable or higher. You cannot use a CAT3 cable. If you are using Ethernet LAN (10 megabits per second, 10BASE-T), you can connect with a CAT3 or higher.

  • Page 106: Cleaning The Computer

    Operating Basics Disconnecting LAN cable To disconnect a LAN cable, follow the steps below. Make sure the LAN Active indicator (orange LED) is out before you disconnect the computer from the LAN. 1. Pinch the lever on the connector in the computer’s LAN jack and pull out the connector.

  • Page 107: Using The Hard Disk Drive (Hdd) Protection (Preinstalled With Some Models)

    Operating Basics ■ Before carrying your computer, shut down the computer, disconnect the power cable and wait until the PC cools down. Failure to follow this instruction could result in minor injury. ■ Always turn off the power when you move the computer. If the power button has a lock, set it to the lock position.

  • Page 108: Taskbar Icon

    HDD Protection is disabled. TOSHIBA HDD Protection Properties You can make the HDD Protection settings by using the TOSHIBA HDD Protection Properties window. To open the window, click start, point to All Programs, point to TOSHIBA, point to Utilities and click HDD Protection setting.
  • Page 109 AC power (desktop) or with batteries (handheld or mobile usage), the detection level automatically switches according to the power connection mode. Details To open the Details window, click the Setup Detail button in the TOSHIBA HDD Protection Properties window. Detail Properties Detection Level Amplification...

  • Page 110: Heat Dispersal

    CPU speed. Or, by lowering the CPU speed first, then if necessary, turning on the fan. Use the Cooling Method item of the Basic Setup tab in TOSHIBA Power Saver. When the CPU temperature falls to a normal range, the fan is turned off and the CPU operation returns to standard speed.

  • Page 111: Chapter 5 The Keyboard

    Chapter 5 The Keyboard The computer’s keyboard layouts are compatible with a 101/102-key enhanced keyboard. By pressing some keys in combination, all the 101/102-key keyboard functions can be executed on the computer. The number of keys on your keyboard depends on which country/region’s keyboard layout your computer is configured with.

  • Page 112: Function Keys: F1

    Soft keys: Fn key combinations The Fn (function) is unique to TOSHIBA computers and is used in combination with other keys to form soft keys. Soft keys are key combinations that enable, disable or configure specific features.

  • Page 113: Hot Keys

    The Keyboard Press Fn + F10 or Fn + F11 to access the integrated keypad. When activated, the keys with gray markings on the bottom edge become numeric keypad keys (Fn + F11) or cursor control keys (Fn + F10). Refer to Keypad overlay section in this chapter for more information on how to operate these keys.
  • Page 114 F2 again to toggle between the settings. Release both Fn and F2 to put the new setting into effect. You can also change this setting through the Profile options in TOSHIBA Power Saver. Standby: When you press Fn + F3, the computer enters the Standby Mode.
  • Page 115 You can also change this setting through the Screen brightness item of the Basic Setup tab in TOSHIBA Power Saver. ■ The brightness level is always set at the maximum value for about 18 seconds, when the internal LCD screen turns on.

  • Page 116: Windows Special Keys

    Fn key. Fn Sticky key You can use the TOSHIBA Accessibility Utility to make the Fn key sticky, that is, you can press it once, release it, and then press an “F number” key. To start the TOSHIBA Accessibility Utility, click start, point to All Programs, point to TOSHIBA, point to Utilities and click Accessibility.

  • Page 117: Keypad Overlay

    The Keyboard Keypad overlay Your computer’s keyboard does not have an independent numeric keypad, but its numeric keypad overlay functions like one. The keys in the centre of the keyboard with gray letters make up the numeric keypad overlay. The overlay provides the same functions as the numeric keypad on the 101/102-key enhanced keyboard.

  • Page 118: Generating Ascii Characters

    The Keyboard Temporarily using normal keyboard (overlay on) While using the overlay, you can temporarily access the normal keyboard without turning off the overlay: 1. Hold Fn and press any other key. All keys will operate as if the overlay were off.

  • Page 119: Chapter 6 Power And Power-Up Modes

    Chapter 6 Power and Power-Up Modes The computer’s power resources include the AC adaptor, battery pack and internal batteries. This chapter gives details on making the most effective use of these resources including charging and changing batteries, tips for saving battery power, and power up modes. Power conditions The computer’s operating capability and battery charge status are affected by the power conditions: whether an AC adaptor is connected, whether a...

  • Page 120: Power Indicators

    Power and Power-Up Modes Power conditions continued Power on Power off (no operation) AC adaptor Battery charge • Operates is above low • LED: Battery off connected battery trigger DC IN off point Battery charge • Operates is below low •...

  • Page 121: Battery Types

    Power and Power-Up Modes DC IN indicator Check the DC IN indicator to determine the power status with the AC adaptor connected: Indicates the AC adaptor is connected and Blue supplying proper power to the computer. Indicates a problem with the power supply. Plug Flashing orange the AC adaptor into another power outlet.
  • Page 122 Power and Power-Up Modes Using a battery pack other than one supplied or specified by TOSHIBA (PA3356U) for this PC would interfere with the computer’s display when open and could damage the LCD display panel. Do not change the battery pack while the AC adaptor is connected.

  • Page 123: Care And Use Of The Battery Pack

    The computer’s RTC battery is a Ni-MH battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations.
  • Page 124 Power and Power-Up Modes 3. Never short circuit the battery pack by either accidentally or intentionally bringing the battery terminals in contact with another conductive object. This could cause serious injury or a fire, and could also damage the battery pack. Always wrap the battery pack in plastic (or place it in a plastic bag) whenever transporting it, to avoid exposing the terminals to another conductive object which could result in serious injury.
  • Page 125 16. Keep the battery pack out of reach of infants and children. It can cause injury. Caution 1. Use only battery packs recommended by TOSHIBA as replacements. 2. When installing a battery pack or before moving the PC, always make sure the battery pack is inserted correctly and securely. If the battery falls out, while you are carrying the PC, you could be injured or the battery pack could be damaged.

  • Page 126: Charging The Batteries

    The Battery indicator glows orange when the battery is being charged. Use only the computer connected to an AC power source or the optional TOSHIBA Battery charger to charge the battery pack. Never attempt to charge the battery pack with any other charger.

  • Page 127: Battery Charging Notice

    Power and Power-Up Modes Time The following table shows the approximate time required to fully charge a discharged battery. Charging time (hours) Battery type Power on Power off Battery pack (4700mAh) about 5.5 to 12.0 about 3.0 RTC battery Doesn’t charge The charging time when the computer is on is affected by ambient temperature, the temperature of the computer and how you use the computer.

  • Page 128: Monitoring Battery Capacity

    Therefore, an often used, older battery will not operate for as long as a new battery even when both are fully charged. In this case, TOSHIBA Power Saver will indicate a 100% charge for both the old and new battery, but the displayed estimated time remaining will be shorter for the older battery.

  • Page 129: Retaining Data With Power Off

    Power and Power-Up Modes Retaining data with power off When you turn off your computer with fully charged batteries, the batteries retain data for the following approximate time periods: Retention time Battery type State and Retention Time Battery pack (4700mAh) about 6 days (Standby Mode) about 60 days (Boot mode) RTC battery...

  • Page 130: Replacing The Battery Pack

    Power and Power-Up Modes Replacing the battery pack Using a battery pack other than one supplied or specified by TOSHIBA (PA3356U) for this PC would interfere with the computer’s display when open and could damage the LCD display panel. The battery pack is classified as a consumable item.

  • Page 131: Toshiba Password Utility

    Windows password. User Password To start the utility, point to or click the following items: start -> All Programs -> TOSHIBA -> Utilities -> Password Utility The User Password dialog box contains two main fields: User Password and User Token.
  • Page 132 Power and Power-Up Modes User Password field ■ Set (button) Click this button to register a password of up to 50 characters. After a password is set, you will be prompted to enter it when you start the computer. Check “Set the same string simultaneously as HDD User Password” when setting the HDD User Password.
  • Page 133 Power and Power-Up Modes ■ If you forget your HDD User Password, TOSHIBA will NOT be able to assist you, and your HDD will be rendered COMPLETELY and PERMANENTLY INOPERABLE. TOSHIBA will NOT be held responsible for any loss of any data, any loss of use or access to your HDD, or for any other losses to you or any other person or organization that result from the loss of access to your HDD.

  • Page 134: Supervisor Password

    Register, delete or change the Supervisor Password. ■ Create or invalidate a Supervisor Password token. This function in the TOSHIBA Password Utility lets you invalidate only supervisor tokens or all tokens, including user and supervisor tokens. ■ Specify restrictions for general users.

  • Page 135: Power-Up Modes

    Started. Windows utilities You can configure various settings associated with both Standby Mode and Hibernation Mode within TOSHIBA Power Saver. Hot keys You can use hot keys Fn + F3 to enter Standby Mode and Fn + F4 to enter Hibernation.
  • Page 136 Power and Power-Up Modes 6-18 User’s Manual...

  • Page 137: Chapter 7 Hw Setup

    Chapter 7 HW Setup This chapter explains how to use TOSHIBA HW Setup program to configure your computer, and provides information on setting up the Execute-Disable Bit Capability and TPM (optional). Accessing HW Setup To run HW Setup, click start, click Control Panel, click Printers and Other Hardware and select TOSHIBA HWSetup.

  • Page 138: Power On Display

    HW Setup General This window displays the BIOS version and contains two buttons: Default and About. Returns all HW Setup values to the factory Default settings. Displays the HW Setup version. About Setup This field displays BIOS Version and date. Display This tab lets you customize your computer’s display settings for either the internal LCD screen or for an external monitor.

  • Page 139: Boot Priority

    HW Setup Boot Priority Boot Priority Options This option sets the priority for booting the computer. Select from the following settings: HDD −> FDD −> The computer looks for bootable files in the CD-ROM −> LAN following order: HDD, floppy disk drive* CD-ROM* and LAN (Default).
  • Page 140 HW Setup To change the boot drive, follow the steps below. 1. Hold down F12 and boot the computer. 2. The following menu will be displayed with the following icons: Built-in HDD, CD-ROM, FDD (or SD memory card), Network (LAN), USB Memory boot.
  • Page 141 HW Setup HDD Priority Options Set the priority of the HDD as a startup device. The priority is set as built-in HDD -> USB. Built-in HDD -> USB (Default) The priority is set as USB memory -> built-in USB -> Built-in HDD.
  • Page 142 HW Setup This function lets you set the CPU operating mode. ® This option is displayed only on models with an Intel Core™ Duo ® processor and Intel Core™ Solo processor. Dynamic CPU Frequency Mode This option lets you choose from the following settings: CPU power consumption and clock speed Dynamically automatic switching function is enabled.

  • Page 143: Device Config

    HW Setup Device Config Device Configuration This option lets you set the device configuration. BIOS sets all devices. All Devices Operating system sets devices that it can control Setup by OS (Default). USB KB/Mouse Legacy Emulation Use this option to enable or disable USB keyboard/mouse legacy emulation.

  • Page 144: Starting And Ending The Bios Setup Program

    ■ In most cases, changes to the system’s configuration should be made within Windows by using applications such as TOSHIBA HW Setup, TOSHIBA Password Utility, TOSHIBA Power Saver, Windows Device Manager and so forth. If you make changes to the configuration through the BIOS setup program, please be aware that the configuration set through the Windows applications will take priority.

  • Page 145: Ending The Bios Setup Program

    HW Setup Ending the BIOS Setup Program Save the changes and end the program. 1. Press the End Key. The “Are you sure? (Y/N) The changes you made will cause the system to reboot.” message is displayed. 2. Press the Y key. The configured settings are saved and the BIOS setup program ends.

  • Page 146: Security Controller

    Capability so that it is not available for use. (Default). System configuration changes, other than changes to this setting, should be made within Windows by using applications such as TOSHIBA HW Setup, TOSHIBA Password Utility, TOSHIBA Power Saver, Windows Device Manager and so forth.

  • Page 147: Lcd Display Stretch

    ■ System configuration changes other than changes to this setting should be made in Windows using TOSHIBA HW Setup, TOSHIBA Password Utility, TOSHIBA Power Saver, Device Manager, etc. ■ When using TPM, please install the Infineon TPM Installation Guide from the TOSHIBA Application Installer.
  • Page 148 HW Setup 7-12 User’s Manual...

  • Page 149: Chapter 8 Optional Devices

    Chapter 8 Optional Devices Optional devices can expand the computer’s capabilities and its versatility. This chapter describes connection or installation of the following devices, which are available from your TOSHIBA dealer: Cards/memory ■ PC card ■ Bridge media slot ■...

  • Page 150: Pc Card

    The computer is equipped with a PC card slot that can accommodate a Type II card. Any PC card that meets industry standards (manufactured by TOSHIBA or other vendor) can be installed. The slot supports 16-bit PC cards, including PC card 16’s multifunction card and CardBus PC cards.

  • Page 151: Bridge Media Slot

    Optional Devices Removing a PC card To remove the PC card, follow the steps below. 1. Open the Safely Remove Hardware icon on the Task Bar. 2. Point to PC card and click. 3. Press the PC card eject button to extend it. If the PC card is not inserted all the way, the eject button may not cause it to pop out sufficiently to allows it to be grasped.

  • Page 152: Memory Card Care

    Optional Devices Media care Observe the following precautions when handling the card. Card care ■ Do not twist or bend cards. ■ Do not expose cards to liquids or store in humid areas or lay media close to containers of liquid. ■...

  • Page 153: Inserting An Sd Card

    Optional Devices Inserting an SD card To insert an SD card, follow the steps below. 1. Insert an SD card in the Bridge media slot. 2. Press gently to ensure a firm connection. Bridge media slot SD card Inserting an SD card ■...

  • Page 154: Sd Memory Card

    TOSHIBA SD memory card format utility, not with the format commands provided within Windows. In order to run TOSHIBA SD memory card format, click start, point to All Programs, point to TOSHIBA, point to Utilities and click SD memory card Format.

  • Page 155: Write Protection

    Optional Devices ■ The slot does not support Magic Gate functions. ■ Memory Stick Duo/PRO Duo and the Memory Stick adaptor are not compatible with the Bridge media slot. Do not insert Memory Stick Duo/ PRO Duo into the slot. Data may be lost or damaged if you use any card other than those supported.

  • Page 156: Xd Picture Card

    Optional Devices xD picture card The computer is equipped with a Bridge media slot that can accommodate xD picture cards with various memory capacities. The xD picture card let you easily transfer data from devices, such as digital cameras that use xD picture card flash-memory.
  • Page 157 Optional Devices MultiMediaCard The computer is equipped with the Bridge media slot that can accommodate MultiMediaCard flash memory technology with various memory capacities. MultiMediaCards let you easily transfer data from devices, such as digital cameras and Personal Digital Assistants, that use MultiMediaCard flash-memory.

  • Page 158: Memory Expansion

    Optional Devices Removing a MultiMediaCard To remove a MultiMediaCard, follow the steps below. 1. Open the Safely Remove Hardware icon on the Task Bar. 2. Point to MultiMediaCard and click. 3. Push in the card and release it to pop the card out slightly. 4.

  • Page 159: Installing Memory Module

    Optional Devices ■ Use only memory modules approved by TOSHIBA. ■ Do not try to install or remove a memory module under the following conditions as you can damage the computer and/or the module, and you risk losing data: a. The computer is turned on.
  • Page 160 Optional Devices 6. Slip your finger under a notch at the end of the keyboard brace and lift up to release latches and remove the keyboard brace. Keyboard brace Removing the keyboard brace 7. Remove two screws securing the keyboard. Use a point size 1 Phillips screwdriver.
  • Page 161 Optional Devices 9. Remove the two screws and take off the memory module cover. Screws Memory module cover Removing the memory module cover ■ Do not touch the connectors on the memory module or on the computer. Debris on the connectors may cause memory access problems.

  • Page 162: Removing Memory Module

    Optional Devices 11. Replace the memory module cover and screw in the two screws. Screws Memory module cover Replace the memory module cover 12. Insert the tabs on the front of the keyboard into the corresponding notches on the computer and place the keyboard down. When seating the keyboard, be sure to connect the circuit board if the keyboard ribbon cable was pulled out while you were removing the keyboard.

  • Page 163: Battery Pack

    Optional Devices 6. Grasp the module by the sides and pull it out. ■ If you use the computer for a long time, the memory modules and the circuits located close to the memory modules will become hot. In this case, let them cool to room temperature before you replace them.

  • Page 164: Battery Charger

    Optional Devices Battery Charger The battery charger provides a convenient way to charge battery packs without requiring the use of your computer. The battery charger holds up to two battery packs (lithium ion). USB floppy disk drive (USB FDD Kit) The USB floppy disk drive module can be connected to the USB port.

  • Page 165: I.link (Ieee1394)

    There is a possibility that the original data will be damaged. There is a particular risk that some frames will be deleted in the case of digital video transfer. TOSHIBA assumes no liability for such loss of data. ■ Do not transfer data in areas where static electricity is easily generated or in areas subjected to electronic noise.

  • Page 166: Bluetooth Usb Adaptor

    Bluetooth USB Adaptor A Bluetooth adaptor that has a USB connector. Wireless communications can be carried out with Bluetooth-compatible equipment by connecting to the USB port of the computer. You can buy the module from TOSHIBA dealer. 8-18 User’s Manual...

  • Page 167: Wireless Optical Mouse With Bluetooth Technology

    The Wireless optical mouse with Bluetooth Technology is a wireless optical mouse compatible with Bluetooth. You can buy the Wireless optical mouse with Bluetooth Technology from TOSHIBA dealer. Wireless Stereo Headset with Bluetooth Technology The Wireless Stereo Headset with Bluetooth Technology is a wireless stereo headphone compatible with Bluetooth.
  • Page 168 Optional Devices 8-20 User’s Manual...

  • Page 169: Troubleshooting

    Chapter 9 Troubleshooting TOSHIBA designed the computer for durability. However, should problems occur, following the procedures in this chapter can help to determine the cause. All readers should become familiar with this chapter. Knowing what might go wrong can help prevent problems from occurring.

  • Page 170: Preliminary Checklist

    Troubleshooting Preliminary checklist Consider the simplest solution first. The items in this checklist are easy to fix and yet can cause what appears to be a serious problem. ■ Make sure you turn on all peripheral devices before you turn on the computer.

  • Page 171: Hardware And System Checklist

    Before using a peripheral device or application software that is not an authorized Toshiba part or product, make sure the device or software can be used with your PC. Use of incompatible devices may cause injury or may damage your PC.

  • Page 172: Self Test

    This message remains on the screen for a few seconds. If the self test is successful, the computer tries to load the operating system, depending on how the Boot Priority is set in the TOSHIBA HW Setup program. If any of the following conditions are present, the self test failed: ■...

  • Page 173: Ac Power

    Troubleshooting AC power If you have trouble turning on the computer with the AC adaptor connected, check the DC IN indicator. Refer to Chapter 6, Power and Power-Up Modes for more information. Problem Procedure AC adaptor doesn’t Check the connections. Make sure the cord is power the computer firmly connected to the computer and a power (DC IN indicator does...
  • Page 174 Fully discharge the battery, then try to charge it again. Check the power consumption settings in TOSHIBA Power Saver utility. Consider using a power saving mode. User’s Manual...

  • Page 175: Real Time Clock

    5. Press Y key. BIOS setup will terminate and the computer will be rebooted. Password Problem Procedure Cannot enter Refer to the TOSHIBA Password Utility section in password Chapter 6, Power and Power-Up Modes. Keyboard Keyboard problems can be caused by your setup configuration. For more information refer to Chapter 5, Keyboard.

  • Page 176: Internal Lcd Display Panel

    Troubleshooting Internal LCD display panel Apparent LCD problems may be related to the computer’s setup. Refer to Chapter 7, Setup, for more information. Problem Procedure No display Press hotkeys Fn + F5 to change the display priority, to make sure it is not set for an external monitor.
  • Page 177 Troubleshooting DVD-ROM&CD-R/RW drive For more information, refer to Chapter 4, Operating Basics. Problem Procedure You cannot access a Make sure the drive’s disc tray is securely CD/DVD in the drive closed. Press gently until it clicks into place. Open the disc tray and make sure the CD/DVD is properly seated.
  • Page 178 Procedure Cannot write correctly If you have trouble writing, make sure you are observing the following precautions: ■ Use only media recommended by TOSHIBA. ■ Do not use the mouse or keyboard during writing. ■ Use only the software supplied with the computer for recording.
  • Page 179 Troubleshooting Problem Procedure Some CD/DVDs run The software or hardware configuration may be correctly, but others do causing a problem. Make sure the hardware configuration matches your software’s needs. Check the CD/DVD’s documentation. Check the type of CD/DVD you are using. The drive supports: DVD-ROM: DVD-ROM, DVD-Video...
  • Page 180 Troubleshooting SD card Refer also to Chapter 8, Optional Devices. Problem Procedure SD card error occurs Reseat the SD card to make sure it is firmly connected. Check the card’s documentation. You cannot write to an Make sure the card is not write protected. SD memory card You cannot read a file Make sure the target file is on the SD memory...

  • Page 181: Touch Pad

    Troubleshooting xD picture card Refer also to Chapter 8, Optional Devices. Problem Procedure xD picture card error Reseat the xD picture card to make sure it is occurs firmly connected. Check the card’s documentation. You cannot read a file Make sure the target file is on the xD picture card inserted in the slot.

  • Page 182: Usb Mouse

    Troubleshooting Problem Procedure Double-tapping does Try changing the double-click speed setting in not work the mouse control utility. 1. Click start, click Control Panel, click Printers and Other Hardware and select Mouse icon. 2. Click the Buttons tab. 3. Set the double-click speed as required and click OK.
  • Page 183 Troubleshooting Problem Procedure The mouse pointer Try changing the speed setting in the mouse moves too fast or too control utility. slow 1. Click start, click Control Panel, click Printers and Other Hardware and select Mouse icon. 2. Click the Pointer Options tab. 3.

  • Page 184: Usb Device

    Troubleshooting USB device Refer also to your USB device’s documentation. Problem Procedure USB device does not Check for a firm cable connection between the work USB ports on the computer and the USB device. Make sure the USB device drivers are properly installed.
  • Page 185 Troubleshooting Sound system Refer also to documentation for your audio devices. Problem Procedure No sound is heard Adjust the volume control dial. Check the software volume settings. Make sure the headphone connection is secure. If problems persist, contact your dealer. Check Windows Device Manager.
  • Page 186 Troubleshooting i.LINK (IEEE1394) device Problem Procedure i.LINK device does not Make sure the cable is securely connected to the function computer and to the device. Make sure the device’s power is turned on. Reinstall the drivers. Open the Windows Control Panel and double-click the Add Hardware icon.

  • Page 187: Wireless Lan

    Troubleshooting Problem Procedure You cannot receive an Check the rings before auto answer setting in incoming call your communications application. If problems persist, contact your dealer. Problem Procedure Cannot access LAN Check for a firm cable connection between the LAN jack and the LAN hub. Wake-up on LAN does Make sure the AC adaptor is connected.

  • Page 188: Disposing Of Pc And Pc Batteries

    Troubleshooting Disposing of PC and PC batteries ■ Discard this PC in accordance with ordinances or rules of local regulations. For further information, contact your local government. ■ This PC contains rechargeable batteries. After repeated use, the batteries will finally lose their ability to hold a charge and you will need to replace them.

  • Page 189: Toshiba Support

    Troubleshooting TOSHIBA support If you require any additional help using your computer or if you are having problems operating the computer, you may need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience may be related to software or the operating system, it is important to investigate other sources of assistance first.
  • Page 190 Troubleshooting 9-22 User’s Manual...

  • Page 191: Chapter 10 Legal Footnotes

    (41°F to 86°F) or > 25°C (77°F) at high altitude (all temperature references are approximate and may vary depending on the specific computer model - please refer to your PC documentation or visit the Toshiba website at www.pcsupport.toshiba.com for details). CPU performance may also vary from specifications due to design configuration.
  • Page 192 Published battery life numbers are achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power.
  • Page 193 Legal Footnotes Over a period of time, and depending on the usage of the computer, the brightness of the LCD screen will deteriorate. This is an intrinsic characteristic of LCD technology. Maximum brightness is only available when operating in AC power mode. The screen will dim when the computer is operated on battery power and you may not be able to increase the brightness of the screen.
  • Page 194 Legal Footnotes 10-4 User’s Manual...

  • Page 195: Specifications

    Appendix A Specifications This appendix summarizes the computer’s technical specifications. Physical Dimensions Weight 1.86 kilograms, configured with: 12.1" WXGA, 512MB RAM, (typical) 40GB HDD, DVD-ROM&CD-R/RW, Wireless LAN. Weight will vary with other configurations. Above weights are measured at specific criteria. They are not guaranteed as the maximum weight of the actual product.

  • Page 196: Power Requirements

    Specifications Power Requirements AC adaptor 100-240 volts AC 50 or 60 hertz (cycles per second) Computer 15 VDC 4.0 amperes Built-in Modem Network control unit (NCU) Type of NCU Type of line Telephone line (analog only) Type of dialing Pulse Tone Control command AT commands...
  • Page 197 Specifications Transmitting level -10 dBm Receiving level -10 to -40 dBm Input/output 600 ohms ±30% impedance Error correcting MNP class 4 and ITU-T V.42 Data compression MNP class 5 and ITU-T V.42bis Power supply +3.3V (supplied by computer) User’s Manual...
  • Page 198 Specifications User’s Manual...

  • Page 199: Appendix B Display Controller And Modes

    Appendix B Display Controller and Modes Display controller The display controller interprets software commands into hardware commands that turn particular parts on the screen on or off. As indicated below, there are two types of video modes. ■ ® Intel 945GM model supports up to 2048 horizontal ×...
  • Page 200 Display Controller and Modes Table1 Video modes (VGA) Video Type Resolution Character Colors Scanning frequency mode matrix (pels) Vertical (Hz) 0, 1 40 × 25 8 × 8 16 of 256K Text Characters 2, 3 80 × 25 8 × 8 16 of 256K Text Characters...
  • Page 201 Display Controller and Modes Table1 Video modes (VGA) continued Video Type Resolution Character Colors Scanning frequency mode matrix (pels) Vertical (Hz) 320 × 200 8 × 8 16 of 256K Grph Pels 640 × 200 8 × 8 16 of 256K Grph Pels 640 ×...
  • Page 202 Display Controller and Modes Table 2 Video modes (Intel ® 945GM model) ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 203 Display Controller and Modes Table 2 Video modes (Intel ® 945GM model) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 204 Display Controller and Modes Table 2 Video modes (Intel ® 945GM model) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 205 Display Controller and Modes Table 3 Video modes (Intel ® 940GML model) ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 206 Display Controller and Modes Table 3 Video modes (Intel ® 940GML model) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 207 Display Controller and Modes Table 3 Video modes (Intel ® 940GML model) continued ■ Vertical Frequency can be set up when outputting to External Monitor. ■ The screen may not be displayed properly in high resolution mode while running 3D applications, during DVD playback, etc. Reduce the resolution until the screen is displayed properly in such cases.
  • Page 208 Display Controller and Modes B-10 User’s Manual...

  • Page 209: Wireless Lan

    Appendix C Wireless LAN Card Specifications Form Factor PCI-Ex MiniCard Type ■ IEEE 802.11 Standard for Wireless LANS Compatibility ■ Wi-Fi (Wireless Fidelity) certified by the Wi-Fi Alliance. The ‘Wi-Fi CERTIFIED’ logo is a certification mark of the Wi-Fi Alliance. ■...

  • Page 210: Supported Frequency Sub-Bands

    Subject to the radio regulations that apply in the countries/regions, your Wireless LAN card may support a different set of 5 GHz/2.4 GHz channels. Consult your Authorized Wireless LAN or TOSHIBA Sales office for information about the radio regulations that apply in the countries/regions.
  • Page 211 Wireless LAN 2452 2457* 2462 2467* 2472* *1 Factory-set default channels *2 Refer to the sheet Approved Countries/Regions for use for the countries/regions that in which these channels can be used. When installing Wireless LAN cards, the channel configuration is managed as follows: ■...
  • Page 212 Wireless LAN 5500 5520 5540 5560 5580 5600 5620 5640 5660 5680 5700 5745 5765 5785 5805 5825 User’s Manual...

  • Page 213: Ac Power Cord And Connectors

    Appendix D AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Length: Minimum 2 meters...
  • Page 214 AC Power Cord and Connectors In Europe, two conductors power cord must be VDE type, H05VVH2-F or H03VVH2-F and for three conductors power cord must be VDE type, H05VV-F. For the United States and Canada, two pin plug configuration must be a 2-15P (250V) or 1-15P (125V) and three pin plug configuration must be 6-15P (250V) or 5-15P (125V) as designated in the U.S.

  • Page 215: Appendix E If Your Computer Is Stolen

    What is your address, phone, and fax number? To register the theft on paper, please follow these procedures: ■ Fill in the TOSHIBA Theft Registration form (or a copy of it) below. ■ Attach a copy of your receipt showing where your computer was purchased.

  • Page 216: Toshiba Theft Registration

    If your computer is stolen TOSHIBA Theft Registration Send to: TOSHIBA Europe GmbH Technical Service and Support Leibnizstr. 2 93055 Regensburg Germany Fax number: +49 (0) 941 7807 921 Country stolen: Machine type: (e.g. TOSHIBA Pocket PC e350) Model number: (e.g.

  • Page 217: Glossary

    Glossary The terms in this glossary cover topics related to this manual. Alternate naming is included for reference. Abbreviations AC: alternating current AGP: accelerated graphics port ANSI: American National Standards Institute APM: advanced power manager ASCII: American Standard Code for Information Interchange BIOS: basic input output system CD-ROM: Compact Disc-Read Only Memory CD-RW: Compact Disc-ReWritable...
  • Page 218 VRT: voltage reduction technology WXGA: wide extended graphics array XGA: extended graphics array AccuPoint: A pointing device integrated into the TOSHIBA computer keyboard. adaptor: A device that provides an interface between two dissimilar electronic devices. For example, the AC adaptor modifies the power from a wall outlet for use by the computer.
  • Page 219 Glossary analog signal: A signal whose characteristics such as amplitude and frequency vary in proportion to (are an analog of) the value to be transmitted. Voice communications are analog signals. ANSI: American National Standards Institute. An organization established to adopt and define standards for a variety of technical disciplines. For example, ANSI defined the ASCII standard and other information processing requirements.
  • Page 220 Glossary bus: An interface for transmission of signals, data or electric power. byte: The representation of a single character. A sequence of eight bits treated as a single unit; also the smallest addressable unit within the system. cache memory: High speed memory which stores data that increases processor speed and data transfer rate.
  • Page 221 Glossary compatibility: 1) The ability of one computer to accept and process data in the same manner as another computer without modifying the data or the media upon which it is being transferred. 2) the ability of one device to connect to or communicate with another system or component.
  • Page 222 Glossary delete: To remove data from a disk or other data storage device. Synonymous with erase. device driver: A program that controls communication between a specific peripheral device and the computer. The CONFIG.SYS file contains device drivers that MS-DOS loads when you turn the computer on. dialog box: A window that accepts user input to make system settings or record other information.
  • Page 223 (FDD): An electromechanical device that reads and writes to floppy disks. Fn-esse: A TOSHIBA utility that lets you assign functions to hot keys. folder: An icon in Windows used to store documents or other folders. format: The process of readying a blank disk for its first use. Formatting establishes the structure of the disk that the operating system expects before it writes files or programs onto the disk.
  • Page 224 Fn, can be used to set system parameters, such as speaker volume. HW Setup: A TOSHIBA utility that lets you set the parameters for various hardware components. icon: A small graphic image displayed on the screen or in the indicator panel.
  • Page 225 Glossary I/O devices: Equipment used to communicate with the computer and transfer data to and from it. IrDA 1.1: An industry standard that enables cableless infrared serial data transfer at speeds of up to 4 Mbps. jumper: A small clip or wire that allows you to change the hardware characteristics by electrically connecting two points of a circuit.
  • Page 226 Glossary microprocessor: A hardware component contained in a single integrated circuit that carries out instructions. Also called the central processing unit (CPU), one of the main parts of the computer. mode: A method of operation, for example, the boot mode, Standby Mode or the Hibernation Mode.
  • Page 227 The electrical connection through which the computer sends and receives data to and from devices or other computers. Power Saver Utility: A TOSHIBA utility that lets you set the parameters for various power-saving functions. printed circuit board (PCB): A hardware component of a processor to which integrated circuits and other components are attached.
  • Page 228 Glossary Random Access Memory (RAM): High speed memory within the computer circuitry that can be read or written to. restart: Resetting a computer without turning it off (also called “warm boot” or “soft reset”). See also boot. RGB: Red, green, and blue. A device that uses three input signals, each activating an electron gun for a primary additive color (red, green, and blue) or port for using such a device.
  • Page 229 TFT display: A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology with thin film transistor (TFT) to drive each cell. Touch Pad: A pointing device integrated into the TOSHIBA computer palm rest. TTL: Transistor-transistor logic. A logic circuit design that uses switching transistors for gates and storage.
  • Page 230 Glossary Glossary-14 User’s Manual...
  • Page 231 Bluetooth Stack for Windows location, 2-1 by Toshiba, 1-14 Display screen problems, 9-19 location, 2-7 USB Adaptor, 1-18, 8-18 DLA for TOSHIBA, 1-17, 4-23 Wireless Optical Mouse with Documentation list, 1-3 Bluetooth Technology, 1-18, DVD Super Multi drive, 1-7 8-19 using, 4-11...
  • Page 232 Index DVD-ROM&CD-R/RW drive, 1-6 Front operation buttons, 1-11, 2-7 using, 4-11 location, 2-7 writing, 4-15 Function keys, 5-2 Environment, 3-1 Graphics controller, 1-7 Equipment checklist, 1-1 Equipment setup Hard disk drive, 1-6 general conditions, 3-2 automatic power off, 1-11 placement, 3-3 HDD Protection, 1-13 Ergonomics Headphone jack...
  • Page 233 Index Indicators, 2-9, 6-2 Arrow mode, 2-10 Media care, 4-27, 8-4 Battery, 2-9 Card care, 8-4 Bridge Media, 2-9 CD/DVDs, 4-27 DC IN, 2-9 floppy disks, 4-27 HDD, 2-9 Memory card care, 8-4 Numeric mode, 2-10 Memory, 1-5 Power, 2-9 expansion, 1-17, 8-10 Wireless communication, 2-9 Memory Stick/Memory Stick Pro,...
  • Page 234 Self test, 9-4 conditions, 6-1 Sound system, 9-17 hibernation mode, 3-12 System start-up, 9-3 indicator, 6-3 TOSHIBA support, 9-21 indicators, 6-2 Touch Pad, 9-13 panel on/off, 1-12, 6-17 USB floppy disk drive, 9-11 shut down mode (boot mode), USB mouse, 9-14...
  • Page 235 8-8 TOSHIBA ConfigFree, 1-15 inserting, 8-8 TOSHIBA Controls, 1-14 removing, 8-8 TOSHIBA Direct Disc Writer, 4-24 TOSHIBA Disc Creator, 1-15, 4-22 TOSHIBA Mic Effect, 1-16 TOSHIBA Password Utility, 1-16 TOSHIBA PC Diagnostic Tool, 1-15 TOSHIBA Power Saver, 1-13...
  • Page 236 Index Index-6 User’s Manual...

This manual is also suitable for:

U200

Table of Contents
