Product features
Front panel components
1-2
Front panel components
1 Power button
2 Power LED
* For more information, refer to the model-specific QuickSpecs at
http://h18004.www1.hp.com/products/quickspecs/QuickSpecs_A
rchives/QuickSpecs_Archives.html.
www.hp.com
Flash activity LED
3
USB ports (2)
4
Hardware Reference Guide
