- Page 1 24-004-2355-00 Rev1.0 Rack Mount Dimmer-12Channel It is important to read this instruction book prior to installing or using your new product for the first time. User Instructions RMD-1220...
-
Page 2: Table Of Contents
Contents Contents Important Safety Introductions...1 For Your Safety Caution General Introduction...2 Features Physical Dimensions Technical Specifications...3 Power Requirements Dimming Capacity Dimmer Output Connections Control Inputs Dmx Output DMX Input Physical Environment(Oprating) Overview...4 Front View...4 Rear View...6 Main Power & Output Termination...7 Operation Guide...8 Menus...8 1) Home(Live display)...8... -
Page 3: Important Safety Instructions
Operation Guide 7) SETUP 16. Use >> button to select and tap ENTER button to enter FAN COOLING menu. This menu allow you to control how the internal cooling fans operate. The menu gives you a choice of Normal, Full On and Silent. 17. -
Page 4: General Instructions
General Instructions Thanks for you purchasing Botex RMD-1220 Rack Mount Dimmer. RMD-1220 is designed to build and expand your lighting control console.It is compact, portable and easy to operate by menus. Features -19"/2U rack mount -12 channel modular digital dimmer pack,12 ways x 20A per channel... -
Page 5: Technical Specifications
Voltage: 120V AC Frequency: 60Hz All RMD-1220 Rack Mount Dimmers must be grounded for safety use. Each pack contains twelve dimmers each with a Maximum load of 20A(4.6kW) per dimmer-total 55.2kW per dimmer pack. -
Page 6: Overview
Overview Front View Operation Guide 7) SETUP This menu is to select what action the dimmer pack shoud follow. There are 5 modes available in this menu----- Protocol Assign, ArtNET Failed,DMX Failed, Fan Cooling and Default. 1. Tap UP/DOWN to scroll SETUP menu. SETUP MENU 2. -
Page 7: Operation Guide
Operation Guide 6) CURVES This menu is used to select a dimmer curve for any or all the dimmer in system. There are 3 dimmer curves available to choice from L-Linear, S-Square and N-NO-DIM. 1. Tap UP/DOWN button to scroll to CURVES menu. -
Page 8: Rear View
1. DMX Input The XLR connector is used to receive an incoming DMX signal 2. DMX Output Used to connect to DMX Input socket of next RMD-1220 for parallel control 3. Power Input Single phase input:AC 120V~60Hz,total 75A Three~phase input:AC 120V ~60Hz, total 75A per chase 4. -
Page 9: Main Power & Output Termination
Operation Guide 5) PLAY SCENE 1. Tap UP/DOWN button scroll to PLAY SCENE menu to perform scene out. MENU PLAY SCENE 2. In this menu, there are 2 sub-menus, Scene Chase and Scene. You can tap >> button to select the ENTER sub-menu you want to enter in. -
Page 10: Operation Guide
Operation Guide Menus There are 8 menus for RMD-1220: 1)Home(Live Display) 2)LOCAL CONTROL 3)ADDRESS, 4)SCENE REC 5)PLAY SCENE 6)CURVES 7)SETUP 8) INFORMATION. 1)Home (Live Display) Power on this unit, the POWER led will be lit and the LCD shows "Initialize...", then enter Home(Live Display) mode automatically. - Page 11 Operation Guide 4) Scenes REC 1. Tap UP/DOWN button to scroll to SCENES REC menu. SCENE REC MENU 2. Tap >> button to swap sub-menu between Assign Copy and Assign. ENTER 3. Tap ENTER button to enter the Sub-menu you selected, and tap UP/DOWN button to scroll scene number.
- Page 12 Operation Guide 3) Address This menu is used to set either the DMX512 start address or ArtNET address(SubNET and Universe are available). 1. Tap UP/DOWN button to scroll to ADDRESS menu. ADDRESS MENU 2. Tap >> button to select sub-menu ArtNET DMX-512A or ArtNET.
