Intel Desktop Board D945Gclf2D Components - Intel BOXD945GCLF2D Product Manual

Table 2. Intel Desktop Board D945GCLF2D Components
Label Description
A PCI bus add-in card connector
B Front panel audio header
C Back panel connectors
D 12 V processor core voltage connector (2 x 2)
E Rear fan (3-pin) header
F Processor
G DDR 2 DIMM connector
H Main power connector (2 x 12)
I IDE connector
J Serial ATA connectors (2)
K Front panel header
L Battery
M BIOS configuration jumper
N Hi-speed USB 2.0 header
O S/PDIF connector (3-pin)
Desktop Board Features
11
