For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE 3 Models
41979-01 • 08/07/07
Advertisement
Related Manuals for Hunter 28480
Summary of Contents for Hunter 28480
- Page 1 Hunter For Your Records and Warranty Assistance Ceiling Fans Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ TYPE 3 Models For reference also attach your receipt or a copy of your receipt to the manual.
-
Page 2: Table Of Contents
• To reduce the risk of personal injury, do not bend the blade 7 • Completing Your Installation With attachment system when installing, balancing, or cleaning the fan. or Without a Light Fixture ....... 10 Never insert foreign objects between rotating fan blades. 8 • Operating and Cleaning • To reduce the risk of fire, electrical shock, or motor damage, do not Your Ceiling Fan..........14 use a solid-state speed control with this fan. Use only Hunter speed 9 • Troubleshooting ........... 15 controls. © 2007 Hunter Fan Company 41979-01 • 08/07/07 • Hunter Fan Company... - Page 3 Mounting and Optional Accessories Understanding Mounting Support Brace Hunter’s mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of two ways, depending on your preference: Standard or Angle mounting. The steps in this manual include instructions for both mounting methods. Ceiling Standard Outlet Box Note: This fan cannot be low-profile mounted. Mounting Style For ceilings higher than 8 feet, you can purchase Hunter extension downrods. All Hunter fans use sturdy 3/4” diameter pipe to assure stability and Standard Mounting hangs from the wobble-free performance.
-
Page 4: Getting Ready
To install a ceiling fan, be sure you can do the following: • Locate the ceiling joist or other suitable support in ceiling. • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: • Electric drill with 9/64” bit • Standard screwdriver (magnetic tip recommended) -
Page 5: Installing The Ceiling Plate
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 3” Wood Screw For Angled Ceilings: Be sure to orient the ceiling plate so that the arrows printed on the ceiling plate are pointing towards the ceiling peak. 41979-01 • 08/07/07 • Hunter Fan Company... - Page 6 3-5. Raise the fan and place the hook on the ceiling plate through the Step 3-3 U-shaped hole in the rim. WARNING: Fan may fall if not assembled as directed in these installation instructions. Spindle Step 3-5 U-shaped Set Screw Hole Step 3-4 Allen Head Set Screw 41979-01 • 08/07/07 • Hunter Fan Company...
- Page 7 4-2. Install the included 12-volt battery into the transmitter. Transmitter Dipswitches CAUTION: The remote control device complies with part 15 of the FCC rules. Changes or modifications not expressly approved by Hunter Fan Company could void your authority to operate this equipment. Example Dipswitch Settings Operation is subject to the following two conditions: Receiver 1 Receiver 2 1.
- Page 8 Steps 5-3 – 5-5 • The black/white wire (ungrounded) from the fan to the red wire (ungrounded) from the receiver (marked on white tag “LIGHT OUT”) • The black wire (ungrounded) from the fan to the black wire (ungrounded) from the receiver (marked on white tag “FAN OUT”) • The white wire (ungrounded) from the fan to the white wire (ungrounded) from the receiver (marked on white tag “COMMON OUT”) 41979-01 • 08/07/07 • Hunter Fan Company...
- Page 9 5-7. Spread the wires apart, with the ground wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 5-8. Position the receiver in the canopy so that the antenna is close to the edge of the ceiling plate for clear reception. 41979-01 • 08/07/07 • Hunter Fan Company...
-
Page 10: Installing The Canopy And Canopy Trim Ring
1. Locate the small bumps on top of the tabs. 2. Press firmly on opposite sides of the ring towards the canopy. The tabs will flex out releasing the trim ring from the canopy. Step 6-3 Steps 6-4 – 6-5 Canopy Screw 41979-01 • 08/07/07 • Hunter Fan Company... -
Page 11: Assembling The Blades
7-3. For each blade, insert one blade mounting screw through the blade iron, and attach lightly to the fan. Insert the second blade mounting screw, then securely tighten both mounting screws. Steps 7-1 – 7-3 Blade Mounting Screw Medallion Blade Assembly Screw 41979-01 • 08/07/07 • Hunter Fan Company... - Page 12 Tighten all three screws securely. Step 8-1 8-5. Install three candelabra bulbs (40 Watt maximum each). Housing Assembly 8-6. Remove the breakaway connectors from the light and fan pull Screw chains and thread them both through the hole in the center of the glass bowl. Candelabra Bulb Light Kit Metal Disk Steps 8-2 – 8-4 Step 8-5 Housing Assembly Screw 41979-01 • 08/07/07 • Hunter Fan Company...
- Page 13 8 • Installing the Light Fixture (Continued) 8-7. P lace the cover plate up against the glass bowl. Align the holes in the cover plate and glass bowl. 8-8. Thread the fan pull chain and light pull chain through the appropriate holes. 8-9. Screw the finial onto the threaded rod end until tight. Glass Bowl Cover Plate Finial Steps 8-7 – 8-9 Breakaway Connector 41979-01 • 08/07/07 • Hunter Fan Company...
- Page 14 Push the light button again to turn off the light. Fan Light 9-4. Press the OFF button to turn the fan off. 9-5. When necessary, replace the battery with a 12-volt type 23A, MN-21 battery or equivalent. 9-6. You can mount the remote holder to any toggle switch plate with the screws already in the switch plate. Or, you can simply mount the remote holder on the wall. Steps 9-1 – 9-4 Step 9-5 Step 9-6 41979-01 • 08/07/07 • Hunter Fan Company...
-
Page 15: Operating And Cleaning Your Ceiling Fan
In cold weather, use upward air flow pattern To Change Airflow Direction Turn the fan off and let it come to a complete stop. Slide the reversing switch on the fan to the opposite position. Restart fan. Reversing Switch 41979-01 • 08/07/07 • Hunter Fan Company... -
Page 16: Troubleshooting
2. Tighten all blade and/or blade iron screws. 3. Turn power off, support fan very carefully, and check that the hanger ball is properly seated. If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 41979-01 • 08/07/07 • Hunter Fan Company...
