P A R TS GUIDE P A R TS GUIDE
P A R TS GUIDE P A R TS GUIDE
Using the Parts Guide belo w , check to make su r e all parts a r e included in the box .
PLEASE DO NOT RETURN THIS PRODUCT T O THE ST ORE.
Before inst alling your fan, record the following informatio n for your records and warranty assist ance.
Fan Parts
Hanger Ball /
7
Downrod
Assembly
46
Blade Set
44 Blade Iron Set
Hardware
70
Canopy Screw
62
Scre w , Blade Iron Armature
47
If parts ar e missing or damaged call 1-888-830-1326.
(Not Drawn to Scale)
3
Motor Housing Assembly
45
Blade Medallion
Set
W ood Screw
64
Wire Nut
Scre w , Machine, 6-32
69
68 Flat W asher
Ceiling Plate
2
4 Canopy
T rim Ring
Balancing Kit
75
Canopy
Light Kit Assembly
49
Gobe / Shade
150
Finial
149
Bottom Cap
148
(Drawn to Scale)
W ood Screw
65
Mounting
71
Isolator
Model Name
Cat alog No.
Serial No.
Date Purchased
Where Purchased
Missing / Broken Part s:
Call 1-888-830-1326
Fan does not work:
1. Reference the T rouble Shooting guide in
your Instruction Manual.
2. Call your Local Service Center .
3. Call T echnical Support at 901-248-2222.
For additional information on:
Hunter Products T rouble Shooting
Dealer Location Service Center Locator
Call 1-800-448-6837
www .hunterfan.com
Remote Control
88
Cradle
Remote Control
86
Receiver
Spindle
221
67 Blade Assembly Screw
79 Allen W rench
Remote Control
87
Transmitter
