Removing the Thermal Module
1. See "Removing the Upper Cover" on page 62.
2. See "Removing the Mainboard" on page 77.
3. Disconnect the fan cable.
4. Remove the four (4) securing screws (in reverse numerical order from screw 4 to screw 1) from the Thermal
Module.
Step
Thermal Module
Chapter 3
Size
M1.98*3.0
2
1
4
3
Quantity
4
Screw Type
81
