4. Press 'Y', and then the necessary information will be written to drives,
which may destroy the original data in the drives.
5. Next, the Array Name input line appears for the user to key in a name for
the newly created array. The effective characters for an array name is
'0'-'9', 'A'-'Z', 'a'-'z', space and underscore.
6. Lastly a prompt message 'Duplicate Data from M to m (Y/N)?' asks
whether to do drive copy. The source and target drives are indicated
by 'M' and 'm' in 'Drive Select Menu' respectively. Pressing 'Y' will
duplicate the data in source drive to the target drive. Make sure the
source drive is the correct one. If you press 'N', the data will be
inconsistent in the two drives.
7. After the RAID array has been created successfully, its information
shows up at RAID Array List.
8. The process status bar shows up during the duplication process.
Create RAID 0+1 for Striping, Mirroring
1. Press 'Enter' key to activate this item. An '+' flash cursor appears at the
'Drive Select Menu' for the user to choose the first drive for RAID 0+1.
2. Use 'Space' key to choose the desired drive for RAID 0+1. Then flash
cursor changes to an '+' flash cursor for the user to choose the
second, third and fourth drives for RAID 0+1.
3. The prompt 'Create RAID 1(Y/N)' appears after two drives are properly
assigned.
4. Press 'Y', and then the necessary information will be written to drives,
which may destroy the original data in the drives.
5. Next, the Array Name input line appears for the user to key in a name for
the newly created array. The effective characters for an array name is
'0'-'9', 'A'-'Z', 'a'-'z', space and underscore.
6. After the RAID array has been created successfully, its information
shows up at RAID Array List.
7. The process status bar shows up during the duplication process.
Create JBOD for Integrated Capacity
1. Press 'Enter' key to activate this item. A 'J' flash cursor appears at the
'Drive Select Menu' for the user to choose the first drive for JBOD.
2. Use 'Space' key to choose the desired drive for JBOD array. Use 'Enter'
key to finish JBOD drive selection. The maximum number of drives for
JBOD array is four and the minimum is two.
3. The prompt 'Create JBOD (Y/N)' appears.
4. Press 'Y' key and then the necessary information will be written to
drives, which may destroy the original data in the drives.
8
