Quantum Scalar 50 Instructions Manual
Magazine upgrade or exchange
Hide thumbs
Also See for Scalar 50:
- User manual (290 pages) ,
- Quick start manual (42 pages) ,
- Installation instructions manual (24 pages)
Advertisement
Introduction
Preparing the Library
Magazine Upgrade Procedure
Document 81-81771-01 A01, June 2007
Magazine Upgrade or Exchange
Required Upgrade Kit ..................................................................................3
Ejecting the Original Magazine ...................................................................4
Installing the New Magazines .....................................................................5
Quantum Scalar 50
Instructions
3
3
4
1
Advertisement
Table of Contents
Related Manuals for Quantum Scalar 50
Summary of Contents for Quantum Scalar 50
- Page 1 Quantum Scalar 50 Magazine Upgrade or Exchange Instructions Introduction Preparing the Library Required Upgrade Kit ..................3 Magazine Upgrade Procedure Ejecting the Original Magazine ..............4 Installing the New Magazines ..............5 Document 81-81771-01 A01, June 2007...
- Page 2 Made in the USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice.
-
Page 3: Preparing The Library
Quantum Scalar 50 Magazine Upgrade or Exchange Instructions Document 81-81771-01 A01 June 2007 Introduction This document explains how to upgrade or exchange your Scalar 50 library with either SDLT or LTO magazines. • Preparing the Library • Magazine Upgrade Procedure... - Page 4 Quantum Scalar 50 Magazine Upgrade or Exchange Instructions Document 81-81771-01 A01 June 2007 Table 2 LTO Magazine Illustration Description Upgrade Kit PN PR-UU9MZ-YF LTO Magazine (18 bins) Handle Flat head Phillips screws (must use with new handles) Quantum Scalar 50 Magazine Upgrade Instructions (PN 81-81771)
- Page 5 Quantum Scalar 50 Magazine Upgrade or Exchange Instructions Document 81-81771-01 A01 June 2007 Figure 1 Library Operations Screen 3 Use the up and down arrows to highlight the option Release magazines and press Enter 4 Use the up and down arrows to highlight the magazine to be removed...
- Page 6 Quantum Scalar 50 Magazine Upgrade or Exchange Instructions Document 81-81771-01 A01 June 2007 Figure 3 Installing the Grooves on top Magazine Handles Handles 2 Replace the tape cartridges into the new magazine. 3 Insert the new magazine into the library (see...
