CanoScan LiDE 200 On-screen Manual
MC-2437-V1.00
How to Use This Manual
Printing This Manual
Obtaining the Latest Scanner Driver
Using Your Scanner Functions
Scanning Photos and Documents
Scanning Multiple Documents at One Time
Scanning Images Larger than the Platen
Making fine adjustments to image brightness and
color when scanning images
Sharpening out-of-focus photographs, removing
spots/scratches and correcting faded colors when
scanning images
Correcting/Enhancing scanned photographs
Printing scanned photographs in various ways
Sending scanned images via e-mail
Searching for lost images
