Page 1: Wan Router
Eicon 1550/1551 WAN Router Quickstart Guide www.eicon.com... -
Page 2: Package Contents
X.25. As settings are changed through a web browser, the Eicon 1550/1551 is very easy to use and configure. Both the Eicon 1550 and Eicon 1551 are equipped with four Ethernet ports and one VHSI port. The Eicon 1551 is also equipped with an ISDN port, designed to be used as a backup in case the VHSI connection fails. -
Page 3: Step 1: Connect The Cables
Step 1: Connect the Cables This section will describe how to connect one computer to the Eicon 1550/1551. Once the setup is running correctly, you can connect up to three other LAN devices, such as other computers or a network-capable printer. -
Page 4: Step 3: Select The Vhsi Protocol
Step 3: Select the VHSI Protocol Settings for particular connections are contained in profiles on the Eicon 1550/1551. However, before you begin creat- ing connection profiles, including any backup profiles, you should verify the protocol setting for the VHSI port (set to ‘X.25’... - Page 5 Step 4: Create Connection Profiles Once the VHSI port protocol is verified, you can begin cre- ating connection profiles. Creating a Profile From the menu, click the ‘Connection’ link. The ‘Connection Profiles’ page appears. As no profiles yet exist, the only section on this page is an area to create a new profile.
-
Page 6: Step 5: Modify Other Settings
‘Indicator Lights’ on page 8. button • The User’s Guide (located in the ‘doc’ folder on the Eicon CD-ROM) contains more information on using and configuring the Eicon 1550/1551. The guide is available in PDF and HTML formats. Online help window ‘Reset... -
Page 7: Troubleshooting
It could be another ISDN profile or a VHSI profile. The Eicon 1550 does not have an ISDN port. However, if you are using X.25, a second VHSI profile can be created and used as a backup in case the primary connection fails. -
Page 8: Indicator Lights
Indicator Lights The following diagram describes the behavior of the indicator lights on the Eicon 1550/1551. Power Light Solid green: Power adapter is properly connected. Flashing red only: Device firmware is being upgraded. Do not reset or unplug the power adapter.
