Summary of Contents for Eicon Networks C2x Family
- Page 1 Eiconcard C2x Family for ISA-Compatible Bus www.eicon.com...
- Page 2 Eicon Networks Corporation. Changes are periodically made to the information herein; these changes will be incorporated into new editions of the publication. Eicon Networks may make improvements and/or changes in the products and/or programs described in this publication at any time.
-
Page 3: Table Of Contents
Table of Contents Introduction ... 5 About this Manual ... 5 Installing the Eiconcard C2x... 6 Making an ISDN Connection... 8 Termination ... 11 Making a V.24 Connection ... 13 Interface Specifications... 13 The V.24 DCE Interface ... 14 LED Functionality ... 15 Technical Specifications... - Page 4 www.eicon.com...
-
Page 5: Introduction
Introduction The Eiconcard C2x is an ISA Plug-and-Play (PnP) card that offers X.25 connectivity through a V.24 serial port at speeds of up to 64 Kbps, and/or through an ISDN BRI port (Eiconcard C21) at speeds of up to 128 Kbps (over the “D” channel or the “B” channels). The Eiconcard C2x is typically used for stand-alone or remote LAN gateways. -
Page 6: Installing The Eiconcard C2X
Installing the Eiconcard C2x Follow the steps below to install the Eiconcard C2x. If you want the Eiconcard C2x to be available to multiple users on a LAN, install it in the PC that will function as a gateway for the LAN. 1 Prepare the PC Turn off the PC and disconnect its power cable. - Page 7 Eiconcard ISA slot Figure 2. Inserting the Eiconcard C2x. Fasten the adapter with the screw (to ensure that the adapter is properly secured and grounded to the PC’s chassis). Replace the cover of your PC as described in your PC’s manual.
-
Page 8: Making An Isdn Connection
Making an ISDN Connection Only the Eiconcard C21 supports ISDN connections. Note After you have installed your Eiconcard C21, connect your ISDN line. In Europe and most countries worldwide In Europe as well as most countries outside of North America and Japan, your Eiconcard C21 adapter can be connected directly to your ISDN line using the included cable. - Page 9 Eiconcard C21 U-interface: If your Eiconcard C21 has a U-interface, the NT1 is integrated into the adapter, and you do not need a separate NT1. ISDN wall jack Eiconcard C21 Figure 4. Connecting the ISDN cable. 1 Take the cable included with the Eiconcard C21. 2 Plug the RJ-45 end into the Eiconcard C21.
- Page 10 Eiconcard C21 S/T-interface: If your Eiconcard C21 has an S/T-interface, you need a separate NT1. You can order an NT1 from Eicon Networks or from another Note supplier. Eiconcard C21 ISDN wall jack S/T jack U jack Figure 5. Connecting to an NT1.
-
Page 11: Termination
Termination This section applies to S/T interface users in Australia and North America, and provides instructions to help set up termination scenarios. Termination requirements vary according to: the number of devices connected to the NT1; and the distance between the devices and the NT1. - Page 12 Multiple ISDN Devices If the NT1 is connected to more than one ISDN device, follow the procedures below. 75 meters or more If the connection spans 75 meters (250 feet) or more, both end devices on the ISDN bus must be set to 100 ohm termination. If the Eiconcard is one of the end devices, connect the 100 ohm terminating resistor included with the ISDN cable.
-
Page 13: Making A V.24 Connection
Making a V.24 Connection The Eiconcard C21 can make V.24 connections using standard V.24 cables. Connection Eiconcard C21 to V.24 DCE V.24 DCE Cable Eiconcard C21 to V.24 DTE V.24 Null Modem Cable, or Table 1. Standard Interface Cables Interface Specifications The standards compliant with the V.24 interface are listed in Table 2. -
Page 14: The V.24 Dce Interface
The V.24 DCE Interface A pin-out diagram for the V.24 DCE interface is shown in Figure 6. The signal definitions and names are listed in Table 3. Pin # Signal Name PGND Protective Ground Transmit Data Receive Data Request to Send Clear to Send Data Set Ready SGND... -
Page 15: Led Functionality
LED Functionality The Eiconcard C20 only has the V.24 port, the Eiconcard C21 Note has both the ISDN BRI port and V.24 port.. ISDN (Eiconcard C21 only) D-channel Status The D-channel controls the link to your ISDN service provider. Off ...The line is not active. The cable may not be connected. -
Page 16: Technical Specifications
Technical Specifications Technical Data • PCI bus compatible (32-bit slot) Eiconcard CPU/Memory/Flash Eiconcard C20 15.36 MHz Motorola 68302 512 KB RAM / 512 KB Flash Eiconcard C21 15.36 MHz Motorola 68302 512 KB RAM / 512 KB Flash Hardware Installation •... -
Page 17: International Regulatory Information
International Regulatory Information Regulatory Information for the USA: WARNING. Changes or modifications to this unit not expressly approved by Eicon Networks Corporation could void the user's authority to operate the equipment. Declaration of Conformity Eicon Networks Corporation 2155 Chenault Drive, Suite 503... - Page 18 FCC Part 68 Notice This unit complies with Part 68 of the FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number. If requested, this information must be provided to the telephone company.
-
Page 19: Regulatory Information For Canada
Regulatory Information for Canada NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. Industry Canada does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. -
Page 20: Regulatory Information For Europe
ÏÁ˜·ÌfiÏ·Ù· ›˜ÔıÌ ÙÈÚ ‚·ÛÈÍ›Ú · ·ÈÙÔ˝ÏÂÌÂÚ Òԉȷ„Ò·ˆ›Ú Í·È ı ¸ÍÂÈÌÙ·È ÛÙÈÚ ı ¸ÎÔÈ ÂÚ Û˜ÂÙÈÍ›Ú ‰È·Ù‹ÓÂÈÚ ÙÁÚ œ‰Á„ÁÙÈÍfiÚ 1999/5/EC. IC: Eicon Networks Corporation lýsir hér með yfir að þetta tæki uppfyllir grunnkröfur og tengd ákvæði ESB tilskipunar nr. 1999/5/EC. IT: La Eicon Networks Corporation certifica che la presente apparecchiatura è... - Page 21 Safety Status: SELV No voltages within this equipment exceed SELV voltages. All interconnection points and ports are SELV. User/Installer Instructions for the United Kingdom Important Safety Considerations When Installing Into A Host Computer System The Eiconcard C2x is a single PCI card. Installation Within A Spare Slot Position Warning: It is essential that, when other option cards are introduced...
-
Page 22: Regulatory Information For Australia
Regulatory information for Australia • This customer equipment shall only be installed in a PC that requires the use of a tool to gain access to internal parts (e.g. this customer equipment must not be installed in a PC with a ‘flip lid’). •... - Page 24 203-225-01...
