Eicon Networks Eiconcard S50 Installation Manual

For isa-compatible bus
Hide thumbs Also See for Eiconcard S50:
Table of Contents

Advertisement

Quick Links

Download this manual
Eiconcard S5x Family
for ISA-Compatible Bus
www.eicon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eiconcard S50 and is the answer not in the manual?

Questions and answers

Related Manuals for Eicon Networks Eiconcard S50

Summary of Contents for Eicon Networks Eiconcard S50

  • Page 1 Eiconcard S5x Family for ISA-Compatible Bus www.eicon.com...
  • Page 2 Fourth Edition (July 2001) 203-078-04 Eicon, Eiconcard, and the Eicon logo are either trademarks or registered trademarks of Eicon Networks Corporation. Changes are periodically made to the information herein; these changes will be incorporated into new editions of the publication. Eicon Networks may make improvements and/or changes in the products and/or programs described in this publication at any time.

  • Page 3: Table Of Contents

    Table of Contents Introduction ... 5 Installing the Eiconcard S5x... 6 Making an ISDN Connection... 9 Connecting to an Eicon Networks NT1... 9 Connecting to a Third Party NT1 ... 9 Termination ... 11 Making an HSI Connection ... 13 Interface Specifications ...
  • Page 4 www.eicon.com...

  • Page 5: Introduction

    29 before installing and using your adapter. Hardware Features The Eiconcard S5x features the following: Eiconcard CPU/Memory Eiconcard S50 20 MHz Motorola 68302 / 2 MB RAM Eiconcard S51 20 MHz Motorola 68302 / 2 MB RAM...

  • Page 6: Installing The Eiconcard S5X

    Installing the Eiconcard S5x Follow the steps below to install the Eiconcard S5x. If you want the Eiconcard S5x to be available to multiple users on a LAN, install it in the PC that will function as a gateway for the LAN. 1 Prepare the PC Turn off the PC and disconnect its power cable.
  • Page 7 If there is a metal plate at the end of the slot, remove it and keep the screw. Firmly insert the adapter into the selected slot. To avoid damaging your hardware, insert the adapter only into a slot with the same bus type as the adapter. Inserting the adapter into any other type of slot can damage your adapter, your PC, or both.
  • Page 8 5 Test the Eiconcard S5x The application software purchased with the Eiconcard S5x contains a test program to verify the card’s integrity. Consult the documentation supplied with this software for details. 6 Connect to the outside world You are now ready to connect the Eiconcard S5x to the outside world.

  • Page 9: Making An Isdn Connection

    Making an ISDN Connection Only the Eiconcard S51 supports ISDN connections. Note After you have installed your Eiconcard S51, connect your ISDN line. • If you plan to use an Eicon Networks NT1, see “Connecting to an Eicon Networks NT1,” below. •...

  • Page 10: Connecting To A Third Party Nt1

    Connecting to a Third Party NT1 To connect to a third party NT1, you must use the ISDN S/T Cable. This cable includes interface circuitry which is not normally provided by the third party NT1 (but which is provided by Eicon’s NT1). Plug the ISDN S/T Cable into the DIN-4 port on the card as illustrated in Figure 4.

  • Page 11: Termination

    Termination This section applies to S/T interface users in Australia and North America, and provides instructions to help set up termination scenarios. Termination requirements vary according to: the number of devices connected to the NT1; and the distance between the devices and the NT1.

  • Page 12: Multiple Isdn Devices

    Multiple ISDN Devices If the NT1 is connected to more than one ISDN device, follow the procedures below. 75 meters or more If the connection spans 75 meters (250 feet) or more, both end devices on the ISDN bus must be set to 100 ohm termination. If the Eiconcard is one of the end devices, connect the 100 ohm terminating resistor included with the ISDN cable.

  • Page 13: Making An Hsi Connection

    Making an HSI Connection The Eiconcard S5x can connect as a DTE to devices such as Data Service Units (DSUs) which support one of the following interfaces: V.24, V.35, or X.21. It can also connect directly to a host computer, or back-to-back to another Eiconcard.

  • Page 14: Interface Specifications

    Interface Specifications The standards compliant with the interfaces supported on the HSI port are listed in Table 2. The rest of this section describes the allocation of pins used to implement the electrical and signalling requirements of each interface. Interface Standard V.24 CCITT V.24...

  • Page 15: Cable Construction Information

    Cable Construction Information If you plan to construct your own HSI cables, be sure to observe the guidelines given below. Wire Gauge, Grounding, and Pairing • Use 26 or 24 AWG wire. Contacts should be 30 microinch gold flash. • The cable must be grounded both by a drain wire connected to pin 1 on both sides (pin A on the type M connector) and by the braid.

  • Page 16: The V.24 Interface

    The V.24 Interface A pin-out diagram for the V.24 DCE interface is shown in Figure 5. The signal definitions and names are listed in Table 4. Pin # Signal Name PGND Protective Ground Transmit Data Receive Data Request to Send Clear to Send Data Set Ready SGND...

  • Page 17: The V.35 Interface

    The V.35 Interface A pin-out diagram for the V.35 interface is shown in Figure 6. The signal definitions and names are listed in Table 5. Pin # Signal Name PGND Protective Ground Request to Send Clear to Send Data Set Ready SGND Signal Ground Data Carrier Detect...

  • Page 18: The X.21 Interface

    The X.21 Interface A pin-out diagram for the X.21 interface is shown in Figure 7. The signal definitions and names are listed in Table 6. Pin # Signal Name PGND Protective Ground SGND Signal Ground S(A) Signal Element Timing (+) S(B) Signal Element Timing (-) R(A)

  • Page 19: Null-Modem Cables

    Null-Modem Cables The wiring diagrams below shows the connections required to construct a back-to-back HSI—HSI cable, and V.35 - AS/400 cable. For additional information required to construct your own cables, see “Cable Construction Information” on page 15. DRAIN WIRE Figure 8. HSI V.24/V.35 Null-Modem Cable (300-031) TWISTED PAIRS (MANDATORY) BRAID...
  • Page 20 Figure 9. HSI X.21 Null-Modem Cable (300-032) Figure 10. HSI V.35 Null-Modem Cable for AS/400 (300-047) TWISTED PAIRS (MANDATORY) DRAIN WIRE BRAID TWISTED PAIRS (MANDATORY) DRAIN WIRE BRAID Null-Modem Cables Type M...
  • Page 21 DRAIN WIRE Figure 11. HSI Null-Modem Conversion Cable (300-033) Null-Modem Cables TWISTED PAIRS (MANDATORY) BRAID...

  • Page 22: Appendix

    Appendix Setting the I/O Address The Eiconcard S5x is shipped with the I/O address set to 380h. This setting only needs to be changed if another card in your PC uses an I/O address in the range 380h to 387h. You can set the Eiconcard to use any of the standard I/O addresses listed in Table 7.
  • Page 23 Setting I/O Addresses when Installing Multiple Eiconcards If you are installing two or more Eiconcards in the PC, for every Eiconcard installed at a primary I/O address, you can install one at a secondary I/O address. This reduces the number of I/O addresses consumed since primary and secondary I/O addresses occupy the same position in the PC I/O address space.

  • Page 24: Selecting An Interface

    Selecting an Interface The Eiconcard S5x is capable of connecting as a DTE to devices which support the V.24, V.35, or X.21 interface. It can also connect directly to a host computer or back-to-back to another Eiconcard. The Eiconcard S5x is shipped with the HSI port set to the V.24 and V.35 interfaces.

  • Page 25: Software Configuration

    Software Configuration Use the information below to assign the card’s interrupt request level and memory segment address. Interrupt Request Level Only one device can use each interrupt request level (IRQ). Make sure you assign an unused IRQ to the Eiconcard S5x. The usual assignment of IRQs in a PC is listed in Table 9.

  • Page 26: Led Functionality

    LED Functionality Eiconcard S50, S52 The Eiconcard S50 has only one HSI port. Note Configuration Status This status light illuminates during configuration to indicate which card and/or port is being configured. This is most useful when more than one Eiconcard is installed in the PC.
  • Page 27 Eiconcard S51 The Eiconcard S51 has three status lights (LEDs) on the end bracket. Two of these lights indicate the status of the ISDN connection, and the third identifies the card during configuration. D-channel Status The D-channel controls the link to your ISDN service provider.

  • Page 28: Technical Specifications

    Technical Specifications Technical Data • IBM PC, PC AT, and PS/2 Model 30 bus compatible Eiconcard CPU/Memory Eiconcard S50 20 MHz Motorola 68302 / 2 MB RAM Eiconcard S51 20 MHz Motorola 68302 / 2 MB RAM Eiconcard S52 20 MHz Motorola 68302 /...

  • Page 29: International Regulatory Information

    International Regulatory Information Regulatory Information for the USA: WARNING. Changes or modifications to this unit not expressly approved by Eicon Networks Corporation could void the user's authority to operate the equipment. Declaration of Conformity Eicon Networks Corporation 2155 Chenault Drive, Suite 503 Carrollton, Texas USA 75006 1-800-80-EICON (972) 417-5500...

  • Page 30: Fcc Part 68 Notice

    FCC Part 68 Notice This unit complies with Part 68 of the FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number. If requested, this information must be provided to the telephone company.

  • Page 31: Regulatory Information For Canada

    Regulatory Information for Canada NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. Industry Canada does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.

  • Page 32: Regulatory Information For Europe

    Regulatory Information for Europe EU Declaration of Conformity EN: Eicon Networks Corporation declares that this equipment is in compliance with the essential requirements and other relevant provisions of Directive1999/5/EC. DE: Eicon Networks Corporation erklärt, daß diese Telekommunikations-endeinrichtung den grundlegenden Anforderungen und anderen relevanten Bestimmungen der Richtlinie 1999/5/EG entspricht.
  • Page 33 Safety Status: SELV No voltages within this equipment exceed SELV voltages. All interconnection points and ports are SELV. User/Installer Instructions for the United Kingdom Important Safety Considerations When Installing Into A Host Computer System The Eiconcard S5x is a single PCI card. Installation Within A Spare Slot Position Warning: It is essential that, when other option cards are introduced...

  • Page 34: Regulatory Information For Australia

    Regulatory information for Australia • This customer equipment shall only be installed in a PC that requires the use of a tool to gain access to internal parts (e.g. this customer equipment must not be installed in a PC with a ‘flip lid’). •...
  • Page 36 203-078-04...
