ELECTRICAL CONNECTION AND OPERATION

Please check that the voltage indicated on the rating
plate situated inside the compartment corresponds
to the voltage in your home. The earthing of this
appliace is compulsory by law. The
manufacturer will accept no liability for injury to
persons or damage to objects arising from the
non observance of this requirement.
When the appliance is plugged in, if the thermostat knob is not set to symbol 0, the green and the red lamps
(1) and (2) (Fig.1) light up and the temperature acoustic alarm sounds. The green control light always remains
alight and indicates the operation of the appliance. The red control light remains alight until the set operation
temperature has been attained. It lights up again when the temperature inside the freezer rises due to frequent
or prolonged door opening, and when the appliance has been loaded with fresh food to be frozen. In this case,
switch on the fast freeze facility until the red control light goes off. The acoustic signal indicates that the red
control light is alight. It stops when the red control light goes off or when the fast freeze facility is switched on
(yellow control light on).

ADJUSTMENT OF THE TEMPERATURE

The thermostat (Fig. 1) controls the temperature inside the appliance. Position 0 indicates that the operation
of appliance is interrupted. The ideal storage temperature of frozen food for a long time is -18°C. In normal
ambient conditions (temperature between +20°C and +25°C), we suggest you adjust the thermostat control
knob to a middle position. To obtain colder or warmer temperatures than -18°C, turn the thermostat control
knob to the highest or lowest setting respectively. We remind you that internal temperatures are affected by
the location of the appliance, the temperature of the surrounding air, the frequency of the door opening. The
setting of the thermostat may have to be varied to allow for these factors. To check the temperature of the
food stored, place the thermometer (if delivered) under the food; if it is placed on the food it will indicate the
temperature of the air which does not correspond to that of the food stored.

USE OF THE FREEZER COMPARTMENT

This appliance is equipped with an acoustic alarm which sounds when the door is left open. In case of prolonged
door opening, to stop the alarm pull switch (6) (Fig.1).
