ProSafe™ Wireless Access Point 802.11g

Product Specifications

• Wireless:
- Standards: IEEE 802.11g 54 Mbps
- Antennas: Two (2) 5 dBi detachable
- Typical maximum power output: 19.8 dBm
- Typical maximum receive sensitivity: 96 dB
Note: Maximum Tx varies based on country and/or region
selection to ensure local regulatory compliance.
• Physical Interfaces:
- LAN Port: One (1) 10/100BASE-T Ethernet
(RJ-45) port with Auto Uplink
with IEEE 802.3af Power over Ethernet (PoE)
support
- Power adapter: Output 12 VDC, 1.2 A; plug is
localized to country of sale
- Five (5) LEDs: Power, Test, 100 Mbps, Link/ACT,
and WLAN 802.11g
- Console Port: One (1) with standard RS-232C
interface with DB-9 male connector
- Antenna Connectors: Two (2) reverse SMA
• Network Management:
- Remote configuration and management through
Web browser, SNMP or Telnet with command
line interface (CLI)
- SNMP management supports SNMP MIB I,
MIB II, and 802.11 MIB
• Advanced Wireless Features:
- Bridging and repeater mode
- Simultaneous wireless bridge and access point mode
- Adjustable transmit power control 100 mW
down to 0 mW
- Dynamic transmit power control and channel
selection with AutoCell
- Wi-Fi Multimedia (WMM
audio, video and voice applications
• Receive Sensitivity:
- 802.11b
1 Mbps -93 dBm
™
2 Mbps -92 dBm
5.5 Mbps -92 dBm
11 Mbps -89 dBm
- 802.11g
6 Mbps -93 dBm
9 Mbps -90 dBm
12 Mbps -90 dBm
18 Mbps -88 dBm
24 Mbps -84 dBm
36 Mbps -80 dBm
48 Mbps -76 dBm
54 Mbps -75 dBm
• Security:
- Wi-Fi Protected Access 2 (WPA2), 802.11i
- Block SSID Broadcast
- VPN pass-through support
- MAC address filtering with access control lists –
up to 256 users
- 802.1x RADIUS support with EAP TLS, TTLS, PEAP
- Secure SSH Telnet
- Secure Socket Layer (SSL) remote management login
- Wireless isolation enables peer-to-peer blocking
so users may not access another user's PC
• Standards, Safety and Electromagnetic
Conformance:
- IEEE 802.11g (2.4 GHz Frequency Band, DSSS
- IEEE 802.3af Power over Ethernet (PoE)
- FCC Part 15 Subpart B and Subpart C
- CE EN60950, EN 300328-2 v1.1.1 (2000-07),
™ (Auto MDI-X)
• Physical Specifications:
- Dimensions: 25.4 x 17.8 x 3.18 cm (10 x 7 x 1.25 in.)
- Weight: 574 g (1.27 lb)
- Processor and memory: Intel
• Environmental Specifications:
- Operating temperature: 0 to 40° C (32 to 104° F)
- Operating humidity: 90% maximum relative
• Warranty:
NETGEAR 3-year warranty
Package Contents
- ProSafe 802.11g Wireless Access Point WG302
- Two (2) 5 dBi Detachable Antennas
- Resource CD
- Power adapter
- Ethernet cable
- Wall Mounting Kit
- Installation guide
- Warranty/support information card
™
) to optimize
System Requirements
- Windows
- 2 Mbytes of available disk space
Antennas and Accessories
- ANT24O5 5 dBi Omni-directional antenna
- ANT2409 9 dBi Indoor/Outdoor Omni-directional
- ANT24D18 18 dBi Indoor/Outdoor Directional
- Five (5) antenna cable lengths: 1.5,
AutoCell RF Management and Control
AutoCell RF Management technology is sophisticated
cognitive radio software embedded in the WG302 firmware
that is accessed via the user interface. The AutoCell-enabled
WG302 monitors radio frequency (RF) patterns and
automatically tunes the access point signal strength
and channel selection to avoid interference to achieve
optimum performance.
Modulation Type)
EMC EN301489-1 v1.2.1 (2000-08), and
EN301489-17 v1.1.1 (2000-09), EN55022(B),
CISPR22(B), AS/NZS 3548(B)
® IXP422, 8 MB
Flash, 16 MB DRAM
humidity, noncondensing
98, Me, 2000, or XP
®
Antenna
antenna
3, 5, 10, and 30 m
