Welcome and Thank You
Welcome and thank you for purchasing this EdgeStar® wine cooler. Once you
complete our easy unit set up by following this manual, it will provide you and
your family years of great service.
If you are reading this owner's manual, you've probably already unpacked the
unit. Note that you should save the packaging in case you need to safely
transport this wine cooler in the future.
In order to assemble this wine cooler, carefully
unpack all parts. The only assembly required is that
of the handle(s). In order to install a handle, you
need a Phillips head screwdriver, the handle(s), and
the two installation screws.
• Open the door of the wine cooler.
• Locate the two screw holes on the inside of
the door (they may be partially obscured by
the door liner gasket.
• Insert the screws into the holes. They should
now poke out of the front of the door.
• Line up the holes in the handle with the
screws and give each screw about 2-4 full
turns into the handle.
• Now screw the screws in all the way, and
your handle is installed!
After you get the handle(s) installed, make sure that your wine cooler is fully
unpacked, and position it into your preferred location (remember, for the best
conditions for your wine, choose a spot in a cool (room temperature) area,
away from direct sunlight leaving about 2-4 inches around all sides,
specifically the back for adequate ventilation. Make sure the unit is set on a
sturdy surface that can support its weight.
Note: that you can screw in and out the legs to level the unit. You may also
want to clean the interior with a solution of mild soap and water and a damp
cloth. Then plug the unit in, set the temperature, and fill it with wine.
Table of Contents
1
1
1
2
3
4
4
7
9
Advertisement
Table of Contents
Related Manuals for EdgeStar Wine Cooler TWR210EBL
Summary of Contents for EdgeStar Wine Cooler TWR210EBL
- Page 1 5. Limited Warranty Welcome and Thank You Welcome and thank you for purchasing this EdgeStar® wine cooler. Once you complete our easy unit set up by following this manual, it will provide you and your family years of great service.
-
Page 2: Important Safeguards
At what temperatures should you set the wine cooler? Experts differ in opinion, but we recommend low to mid 50’s (F) for whites and mid 60’s (F) for reds. Enjoy! IMPORTANT SAFEGUARDS When using an electrical appliance, basic precautions should always be followed, including the following: BEFORE USE, PLEASE READ AND FOLLOW ALL INSTRUCTIONS FOR •... -
Page 3: Specifications
• An empty cooler can be dangerous for children. If disposing of the cooler remove gaskets, latches, lids and the entire door from your unused appliance, or take other action to ensure that children cannot become trapped inside. • If your model of wine cooler is equipped with a lock, take care to keep the keys away from children. -
Page 4: Operation
2. Parts and Features 1. LIGHT 2. FAN GRATE 5. HINGE 6.TEMPERATURE DISPLAY 7. TEMPERATURE CONTROLS 8. DOOR FRAME Note: The above diagram is for reference only- your specific model of wine cooler will likely differ slightly from the diagram above (in light placement, bottle capacity, etc,) but its operation will be essentially the same. - Page 5 Bottle Capacity Bottle capacity listed for your wine cooler is an estimated maximum capacity based on standard 750 mL wine bottles. For any other size bottles, capacity will vary. Racks Please note that the racks for your cooler have a top and a bottom. If you are having trouble fitting the stated number of bottles in the cooler (provided you have standard wine bottles), try flipping over one or more racks.
-
Page 6: Troubleshooting
Let any hot foods or drinks cool before placing them inside the cooler. 5. Troubleshooting Your EdgeStar wine cooler is a thermoelectric refrigeration unit that uses “green” thermoelectric cooling to store your wine under ideal conditions. What are the benefits of thermoelectric cooling? •... - Page 7 Symptoms Possible causes There is a power The wine failure. cooler does not turn on. The cooler is not plugged in. A house fuse has blown or the circuit breaker is tripped. The cooler is placed too close to a heat source.
- Page 8 Symptoms Possible causes The room temperature is higher than the recommended ambient temperature (77°F). The door is being The cooler opened often. turns on and off frequently. The door is not completely closed. The door gasket is not sealing properly. The cooler does not have the suggested ventilation.
-
Page 9: Limited Warranty
DESCRIPTION OF WARRANTY SERVICE: All defective product components covered by this warranty will be repaired or replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s authorized repair facility during the first 90 days from the date of original purchase. -
Page 10: Obtaining Warranty Service
Once an EdgeStar authorized representative has confirmed that your product is eligible for warranty service, the product must be returned to an EdgeStar authorized repair facility. The purchaser is solely responsible for prepaying all shipping related costs to and from the repair facility.
