Thank you and Intro
Thank you for purchasing this EdgeStar wine cooler. Once you get this unit
set up, it will provide you and your family with years of great service.
If you are reading this owner's manual, you've probably already unpacked the
unit. Note that you should save the packaging in case you need to safely
transport this wine cooler in the future.
In order to assemble this wine cooler, carefully
unpack all parts. The only assembly required is that
of the handle. In order to install the handle, you
need a phillips screwdriver, the handle, and the two
installation screws.
• Open the door of the wine cooler.
• Locate the two screw holes on the inside of
the door (they may be partially obscured by
the door liner gasket.) If the gasket obscures
the screw holes, gently pull that section of the
gasket out of the door.
• Insert the screws into the holes. They should
now poke out of the front of the door.
• Line up the holes in the handle with the
screws and give each screw about 2-4 full
turns into the handle.
• Now screw the screws in all the way, reset the gasket into the door (if
you removed it) and your handle is installed!
After you get the handle installed, make sure that your wine cooler is fully
unpacked, and position it where you want it to go (remember, for the best
conditions for your wine, choose a spot in a cool (room temperature) area, out
of the sun, and with about 2-4" around all sides and the back for adequate
ventilation. Make sure the unit is set on a sturdy surface that can support its
weight. Note that you can screw in and out the legs to level the unit. You may
also want to clean the interior with a solution of mild soap and water and a
damp cloth. Then plug the unit in, set the temperature, and fill it with wine.
At what temperature should you set the wine cooler? Some of the experts
differ in their opinions, but we recommend low to mid 50's (F) for whites and
mid 60's (F) for reds. Enjoy!
Table of Contents
1
1
1
2
3
3
3
5
8
Note: Your door and
handle may appear
different than pictured
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EdgeStar Wine Cooler TWR125SS
Summary of Contents for EdgeStar Wine Cooler TWR125SS
- Page 1 5. Limited Warranty Thank you and Intro Thank you for purchasing this EdgeStar wine cooler. Once you get this unit set up, it will provide you and your family with years of great service. If you are reading this owner’s manual, you’ve probably already unpacked the unit.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS When using an electrical appliance, basic precautions should always be followed, including the following: BEFORE USE, PLEASE READ AND FOLLOW ALL INSTRUCTIONS FOR • Do not use if the power supply cord is damaged. If damaged, it must be replaced by the manufacturer or a similarly qualified person. -
Page 3: Specifications
• An empty cooler can be dangerous for children. If disposing of the cooler remove gaskets, latches, lids and the entire door from your unused appliance, or take other action to ensure that children cannot become trapped inside. • If your model of wine cooler is equipped with a lock, take care to keep the keys away from children. - Page 4 Your wine cooler has an interior light with an on/off switch. Turn the light on or off by pressing the switch. Leveling Legs Your wine cooler is shipped with leveling legs installed. To adjust these leveling legs, carefully lean the cooler to one side (make sure the cooler is empty and the door is secured) and unscrew the leveling legs to make them longer.
-
Page 5: Troubleshooting
Let any hot foods or drinks cool before placing them inside the cooler. 5. Troubleshooting Your EdgeStar wine cooler is a thermoelectric refrigeration unit that uses “green” thermoelectric cooling to store your wine under ideal conditions. What are the benefits of thermoelectric cooling? •... - Page 6 Symptoms Possible causes There is a power The wine failure. cooler does not turn on. The cooler is not plugged in. A house fuse has blown or the circuit breaker is tripped. The cooler is placed too close to a heat source.
- Page 7 Symptoms Possible causes The room temperature is higher than the recommended ambient temperature (77°F). The door is being The cooler opened often. turns on and off frequently. The door is not completely closed. The door gasket is not sealing properly. The cooler does not have the suggested ventilation.
-
Page 8: Limited Warranty
DESCRIPTION OF WARRANTY SERVICE: All defective product components covered by this warranty will be repaired or replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s authorized repair facility during the first 90 days from the date of original purchase. -
Page 9: Obtaining Warranty Service
Once an EdgeStar authorized representative has confirmed that your product is eligible for warranty service, the product must be returned to an EdgeStar authorized repair facility. The purchaser is solely responsible for prepaying all shipping related costs to and from the repair facility.
