• PLEASE study these instructions carefully before installing your new camshaft. If you have any questions or problems, do not hesitate to call our
Technical Hotline at: 1-800-416-8628.
• CAMSHAFT: Edelbrock Torker-Plus camshafts are ground specifically for use with the corresponding Torker II manifold. The Torker II manifold
#5001, and Torker-Plus camshaft #5002, are designed to work as a team to give you better driveability and performance. They are dyno-matched
and street-proven. For best results, use the Edelbrock manifold/camshaft package with the carburetor and headers we recommend. The Torker-
Plus camshafts are designed for use with modified or high performance cylinder heads and valve train components only. Screw-in studs and H.P.
adjustable rocker arms must be used.
NOTE: Maximum performance is achieved only when the Edelbrock Torker II Power Package components are used with the following equipment:
•
Torker II manifold/camshaft/timing set/valve springs
•
Performer Series carburetor #1407
•
fuel delivery system of sufficient capacity
• IMPORTANT: This instruction sheet provides general installation guidelines which can affect your warranty. Read it carefully. It is not our intent to
cover each detail of installation here; a step-by-step procedure manual would be far too lengthy. We want to caution you that installing a
camshaft is a complicated procedure that requires a good general knowledge of automotive engines. If you are not confident that you can com-
plete the camshaft installation successfully, we suggest you consider having it installed by an experienced mechanic.
CAUTION: Improper installation will result in LOW MILEAGE, POOR PERFORMANCE, COSTLY REINSTALLATION, and ENGINE DAMAGE.
TO AVOID THESE PROBLEMS YOU MUST DO THE FOLLOWING:
Carefully study and understand all instructions.
Examine the camshaft for possible shipping damage (if damaged contact you dealer immediately).
PREPARATION CHECKLIST
• TOOLS AND EQUIPMENT
Use the following checklist for items needed:
box and open-end wrenches
socket set
distributor wrench
pliers (channel locks & hose clamp)
screw drivers (regular and phillips)
torque wrench
hammer
gasket scraper or putty knife
timing light
vacuum gauge
rags
water bucket
harmonic balancer puller
• BEFORE CAMSHAFT INSTALLATION
1. Disconnect battery.
2. For ease of installation, keep all parts in some sort of order.
WARNING: Do not remove radiator cap or radiator hose if engine is hot.
©2008 Edelbrock Corp
•
•
• HARDWARE & PARTS TO BUY
INSTRUCTIONS FOR ENGINE PARTS REMOVAL
MODEL: 265-400 c.i.d. Chevrolet V8
1-3/4" headers
aftermarket/re-curved distributors
Edelbrock Performer-Link True Rolling Timing Chain and
Gear Set #7800 or Accu-Drive Gear Drive #7890
Edelbrock Sure Seat Valve Springs, #5703
Manifold bolt kit #8504
Manifold gaskets #7201
Edelbrock Gasgacinch, #9300
engine gaskets- water pump, front cover, front cover seal, etc.
pipe plugs, if needed
RTV Silicon Gasket Sealer
chalk
paper and pencil
radiator coolant
teflon tape
TORKER-PLUS
Camshaft/Lifters/Lube Kit
CATALOG #5002
Rev 9/08 - AJ/mc
Brochure #63-5002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Edelbrock Torker-Plus 265-400
Summary of Contents for Edelbrock Torker-Plus 265-400
- Page 1 Technical Hotline at: 1-800-416-8628. • CAMSHAFT: Edelbrock Torker-Plus camshafts are ground specifically for use with the corresponding Torker II manifold. The Torker II manifold #5001, and Torker-Plus camshaft #5002, are designed to work as a team to give you better driveability and performance. They are dyno-matched and street-proven.
-
Page 2: Valve Springs
CAUTION: WARNINGS ABOUT YOUR WARRANTY In order for this Torker-Plus cam and lifter kit to be covered under ANY WARRANTY you MUST use the correct Edelbrock Sure Seat Valve Springs. Failure to install new Edelbrock valve springs with your new Torker-Plus cam could cause the cam lobes to wear excessively and could cause additional engine damage. -
Page 3: Special Instructions
• SPECIAL INSTRUCTIONS With the Edelbrock manifold and camshaft package plus a header installation, a carburetor jet change may be required for best performance. Due to the varied applications of year and model of vehicles, no one combination could suffice for all installations. The following procedure is only a guideline and in many cases, the manufacturing specifications for recommended carburetors or timing may be best. - Page 4 • WARNING In order for this Torker-Plus cam and lifter kit to be covered under ANY WARRANTY you MUST use the correct Edelbrock Sure Seat Valve Springs. The end flap or label from your Sure Seat Valve Spring box must be sent in with your camshaft warranty card.
- Page 5 47° BBDC Intake Centerline: 106° Lobe Separation: 108° • CAUTION: Use Edelbrock Performer-Link Timing Chain and Gear Set #7800 or Accu-Drive gear drive #7890. Do not use late model timing chain and gear sets that are designed for emis- sion-controlled engines. These timing sets are machined in a retarded position and are not recommended for this camshaft installation.
