CONNECTING TO A VCR
If there are no video IN and audio IN terminals on your TV set, you can connect Nitro
Vision™ to a VCR.
CARTRIDGES
Please take the cartridge out of the storage compartment in the top of the unit before using
the cartridge.
- Make sure the Nitro Vision™ console unit is turned OFF.
- Insert a cartridge into the cartridge slot on the front of the main console
unit. The cartridge should lock into place. Please use carefully when
inserting or removing the cartridge from the slot.
- Turn on the TV.
- Set your TV input mode to accept input from the port to which Nitro
Vision™ is connected. In many cases this will involve setting the TV
to "video" mode; however, since all TVs vary, please refer to your TV
or VCR manual for further details.
- Turn Nitro Vision™ on by pressing the ON Button.
NOTE: When Nitro Vision™ is running any activity, inserting a cartridge into the cartridge
slot is NOT RECOMMENDED. Inserting a cartridge will cause Nitro Vision™ to
reset. Please make sure the Nitro Vision™ unit is turned OFF when inserting any
cartridge.
Nitro Vision™ bonus activity cartridges are only to be used with the Nitro Vision™ console
unit.
7
FOR TVS WITH A MONO AUDIO INPUT
Connect the yellow plug on the Nitro Vision™ cable to the
-
yellow video input terminal on your TV.
Connect the white plug on the Nitro Vision™ cable to the white
-
audio input terminal on your TV.
- Connect the yellow plug on the Nitro Vision™ cable to the yellow
video input terminal on your VCR.
Connect the white plug on the Nitro Vision™ cable to the white
-
audio input terminal on your VCR.
