DLP PROJECTOR
SL 703S
USER'S GUIDE
Thank you for purchasing the Benq DLP Projector.
Please read this user's guide to ensure correct use of the device. Save this
user's guide for future reference.
OUTLINE
This DLP Projector can display various computer signals and NTSC/PAL/SECAM video
signals.
FEATURES
1. High Brightness
2. High Resolution
3. Compact Size, Feather Weight for
Portability
4. Durable Magnesium Alloy Body
5. RGB Output Terminal
6. One Touch Auto-Adjustment Function
7. Easy Keystone Adjustment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL703S - DLP Micro SVGA Projector and is the answer not in the manual?

Questions and answers

Related Manuals for BenQ SL703S - DLP Micro SVGA Projector

Summary of Contents for BenQ SL703S - DLP Micro SVGA Projector

  • Page 1 DLP PROJECTOR SL 703S USER’S GUIDE Thank you for purchasing the Benq DLP Projector. Please read this user’s guide to ensure correct use of the device. Save this user’s guide for future reference. OUTLINE This DLP Projector can display various computer signals and NTSC/PAL/SECAM video signals.
  • Page 2 Benq Corporation Copyright Copyright © 2002 by Benq Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Benq Corporation.
  • Page 3 Disclaimer...

  • Page 4: Table Of Contents

    Benq Corporation Table of Contents Introduction ....... 1 Safety Instructions ......... . 1 Warranty .
  • Page 5 Benq Corporation Troubleshooting ......23 Status Messages ......... . 24 Specifications .

  • Page 6: Introduction

    Benq Corporation INTRODUCTION Caution TO PREVENT SHOCK, DO NOT OPEN THE CABINET. NO USER –SER- VICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. PLEASE READ THIS USER’S GUIDE BEFORE YOU OPER- ATE YOUR PROJECTOR. SAVE THIS USER’S GUIDE FOR FUTURE REF- ERENCE .

  • Page 7: Warranty

    In the event this product is found to be defective within the warranty period, Benq’s only obligation and your exclusive remedy shall be replacement of any defec- tive parts (labor included). To obtain warranty service, notify the dealer immediately from which you purchased the product of any defects.

  • Page 8: Shipping Contents

    Benq Corporation Shipping Contents The Projector is shipped with the necessary cables required for standard PC, Macintosh or laptop computer connections. Carefully unpack and verify that you have all the items shown below. If any of these items are missing, please contact your place of purchase.

  • Page 9: Projector Description

    Benq Corporation Projector Description Projector External control panel Video connector (see next page) 10. D-sub connector Projection lens (for computer/ HDTV input) Front adjustment feet 11. Audio input IR remote sensor 12. Rear adjustment feet Ventilation grill 13. Lamp access door...

  • Page 10: External Control Panel

    Benq Corporation External Control Panel Exit Keystone/ Left Keystone/ Right Menu Power Auto Source Lamp status indicator • The Infrared Remote Receiver (Front and Rear) allows the projector to accept signals from the remote control. For best results, be sure to aim the control toward the sensor without any obstructions between the two, and at a distance no greater than 6 meters.

  • Page 11: Adjuster

    Benq Corporation Adjuster The projector is equipped with a quick-release adjuster foot and button for adjusting its tilt angle. Lift the projector up and press the adjuster button to release the adjuster. The adjuster will drop into position and be locked.

  • Page 12: Remote Control Description

    Benq Corporation Remote Control Description Remote Control Features The remote control sensors are located in the front/ back of the projector. The distance between the sensor and the remote control should not exceed 6 meters. Introduction...
  • Page 13 Benq Corporation FREEZE The image can be frozen when FREEZE is pressed. A “Pause” icon will appear in the lower right corner of the screen for three seconds. To release the freeze function, press the FREEZE button, RETURN button or SOURCE button (when the input source is switched over during display) again.

  • Page 14: Installing Or Replacing Batteries

    Benq Corporation Installing or Replacing Batteries • Push and slide the battery compartment lid in the direction shown. • Install a battery as indicated by the diagram inside the compartment. • Position the lid over the compartment and snap it back into place.

  • Page 15: Installation

    Benq Corporation INSTALLATION Screen Size Place the projector at the required distance from the screen according to the desired picture size (see the table below). Connecting to Various Equipment It only takes a few seconds to connect your projector to your computer/notebook, VCR or other systems.

  • Page 16: Operation

    Benq Corporation OPERATION Start Up Plug the power cord into a wall socket. Press POWER for 1 second. Projector Remote Control Power Power • The back-lit POWER key blinks green and stays green when the power is turned (When the power is turned off, there is a 60-second cooling period before the projector can be re-started.)

  • Page 17: Digital Keystone Correction

    Benq Corporation Digital Keystone Correction Keystoning is when the projected image is noticeably wider on either the top or bottom. To correct this, press KEYSTONE +/- (hot key) on the control panel of the projector or on the remote control, then adjust the sliding bar labeled Keystone, as needed.

  • Page 18: Source Selection

    Benq Corporation Source Selection When several input sources are available, press the SOURCE key to make a selection from the control panel of the projector or the remote control. Remote control Projector Source Power Power Auto Source Menu System Press Menu for the main menu and press to select a sub-menu.

  • Page 19: Display Menu

    Benq Corporation 1. Display Menu Corrects the keystone of the image. Keystone Adjusts the brightness of image. Brightness Adjusts the degree of difference between darkness and lightness of image. Contrast Adjusts to fit in the desired image size. Phase *This function is not available when the input mode are Video, S- video.

  • Page 20: Image Menu

    Benq Corporation 2. Image Menu The following functions are available when the input mode is PC. Makes the best fit of the image to the screen, Auto resize Adjusts the horizontal position of image. H-position Adjusts the vertical positon of image.

  • Page 21: Source Menu

    Benq Corporation 3. Source Menu Mirror Default Ceiling - mounted projection Rear screen projection Ceiling - mounted and rear screen projection Selects sources between PC, Video, S-video, and YPbPr. Source Adjusts the volume level. Volume Adjusts the treble level. Treble Adjusts the bass level.

  • Page 22: Control Menu

    Benq Corporation 4.Control Menu Language sets the OSD to display in one of 7 languages. Use Left/Right key to select the languages: English, French, Language German, Italian, Spanish, Simplified Chinese and Traditional Chinese. Selects a desired OSD position. Sets the length of time the OSD will remain active after the last OSD Time time you pressed the button.

  • Page 23: Shutdown

    Benq Corporation Shutdown Press POWER and a warning message will prompt up. To turn off the projector, Press POWER again. The fan will continue to run for approximately 60 seconds. Power Power Disconnect the power cord from the wall socket.

  • Page 24: Maintenance

    Benq Corporation MAINTENANCE Lamp Information Use and Replacement of Lamp When the Lamp Indicator lights up red or a message displays to suggest the time of lamp replacement, please change a new lamp or consult your dealer. An old lamp could cause a malfunction to the projector and may explode.
  • Page 25 Benq Corporation Press the POWER button to switch off the projector. Disconnect the power cord from the outlet and the projector. Loosen the screw and remove the lamp cover. If the lamp is hot, avoid burns by waiting 45 minutes until the lamp has cooled.

  • Page 26: Resetting Lamp Hours

    Benq Corporation Caution To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp. To reduce the risk of injuries to fingers and damage to internal components, use caution when removing lamp glass that has shattered into sharp pieces.

  • Page 27: Service Information

    HDTV Cable ..........50.J2401.001 Ordering Parts or Getting Information For product information, product assistance, service information, or to order accessories, please contact Benq corporation. at http://www.benq.com. Maintenance...

  • Page 28: Troubleshooting

    Benq Corporation TROUBLESHOOTING Common Problems & Solutions PROBLEMS TRY THESE SOLUTIONS • Plug the power cord into the AC inlet. • Plug the power cord into the power inlet. NO POWER • Wait two minutes after the projector is turned off before turning the projector back on.

  • Page 29: Status Messages

    Benq Corporation Status Messages On Screen Messages Description Projector is searching for input. SEARCHING Projector has identified the input signal and is running the INPUT SIGNAL auto image adjustment function. DETECTED, ACTIVATING AUTO IMAGE Input signal frequency exceeds the projector’s.

  • Page 30: Specifications

    Benq Corporation SPECIFICATIONS Projector Specifications Technical Specifications Note: All specifications are subject to change without notice. General Product name Personal Projector Model name SL703S (SVGA) 800X600 SVGA Optical Display system 1-CHIP DMD Lens F/Number F/2.6 Lamp 120W VIP lamp Electrical Power supply AC100 ~ 240V, 2.3A, 50/60 Hz (Automatic)

  • Page 31: Timing Chart

    Benq Corporation Timing Chart Resolution H Sync (kHz) V Sync (Hz) Remark 640x350 31.5 70.1 640x400 37.9 85.1 VESA 720x400 31.5 70.0 720x400 37.9 85.1 VESA 640x480 31.5 60.0 VESA 640x480 37.9 72.8 VESA 640x480 35.0 66.7 Macintosh 640x480 43.3 85.0...

  • Page 32: Dimensions

    Benq Corporation DIMENSIONS 220 mm 175 mm 52 mm Dimensions...
