SPECIFICATIONS
AC Specifications:
Protect or Disconnect™ Circuitry__________________Yes
Thermal Fusing_______________________________Yes
Line Voltage_______________________120VAC, 50/60Hz
Initial Clamping Level____________200V Peak, 141V RMS
UL 1449 Suppression Rating____________________330V
Protection Modes______________________L-N, L-G, N-G
Maximum Current Rating________________15A (1800W)
EMI/RFI Noise Filtration_________45dB (100kHz – 1 MHz)
Response Time______________________________< 1 ns
Single Pulse Energy Dissipation____________1125 Joules
Peak Impulse Current_______________________52,000 A
Telco Protection:
Fuseless/Auto-Resettable________________________Yes
Clamping Level______________________________260V
Capacitance _________________________30 pf (approx.)
Suppression Modes_____________Metallic & Longitudinal
Wires Protected____________________2 wire, 1 pair (3,4)
Connectors_________________________________RJ-11
CATV, SATELLITE & Cable Modem Protection:
Bi-Directional_________________________________Yes
Shielded_____________________________________Yes
Clamping Level ____________________________1.5V
Frequency Range____________________5MHz – 950MHz
Insertion Loss_______________________________<1 dB
Connections___________________Female "F", Gold Plated
General:
Lightning Protection____________________________Yes
Product Warranty_________________________Lifetime*
Connected Equipment Protection Policy__Up to $100,000*
Specifications subject to change without notice due to continuing product
updates and improvements.
*See enclosed documentation for terms and conditions.
1690 Corporate Circle, Petaluma, CA 94954
800-472-5555 • 707-283-5900
www.panamax.com
Designed in U.S.A. Made in China
Model: PM8C-EX
Tested & Approved Modem & TV Protection
®
FEATURES & INCLUDED ACCESSORIES
Noise Filtration/Surge Protection For Audio/Video Systems -
Including PLASMA TV, VCR, DVD
• Solid-State Telephone Line Protection
•
Solid-State Telephone Line Protection
•
• Eight AC Outlets with Transformer Spacing
Eight AC Outlets with Transformer Spacing
Accepts Add-on Signal Line Modules to
Accepts Add-on Signal Line Modules to
• •
Accommodate System Expansion
Accommodate System Expansion
Power ON/
Protection OK LED
Ground OK LED
In/Out Telco
Connectors
Includes: 4 ft. Phone Cable
CATV / Satellite
Connectors
Includes RG-6 Coax Cable
6' Power Cord
with Right Angle
45° Offset Plug
© 2008 Panamax. The Panamax logo is a registered US trademark of Panamax. Protect or Disconnect is a trademark of Panamax.
Time Warner Cable is a registered trademark of Time Warner Cable, Inc.
PM8C-EX
