Lexmark™ X85x

Clearing Jams

Guide

Avoiding jams

The following hints can help you avoid jams:
•
Use only recommended print media.
• Do not overload the print media sources. Make
sure the stack height does not exceed the
maximum height indicated by the stack line on
the labels in the sources.
•
Do not load wrinkled, creased, damp, or curled
print media.
•
Flex, fan, and straighten print media before you
load it. If jams do occur with print media, try
feeding one sheet at a time through the
multipurpose feeder.
• Do not use print media that you have cut or
trimmed yourself.
•
Do not mix print media sizes, weights, or types
in the same print media source.
•
Make sure the recommended print side is
loaded in the source according to your simplex
or duplex needs.
• Keep print media stored in an acceptable
environment.
•
Do not remove trays during a print job.
•
Push all trays in firmly after loading them.
• Make sure the guides in the trays are properly
positioned for the size of print media you have
loaded. Make sure the guides are not placed
too tightly against the stack of print media.
Clearing Jams

Understanding jam numbers

Jam What to do
200–202 Jams
Open Door A, and remove the
jam.
203 Jam
Open the Door A and Door E,
and remove the jam.
230 Jam
Open Door D, and remove the
jam. Open the Door A and Door
E, and remove the jam.
231 Jam
Open Door D, and remove the
jam. Open the Door A and Door
E, and remove the jam.
24x Jams
Open each tray, and remove any
jammed media.
250 Jam Remove all media from the
multipurpose feeder, flex and
stack the media, reload the
multipurpose feeder, and adjust
the guide.
280-288 Jams
As directed by the message,
check area F, G, or H, then
remove the jam.
289 Jam Remove the staple cartridge,
then remove any jammed
staples.
290, 291, 292, and Open the ADF cover and the
294 Jams scanner cover, and remove any
jammed media.
293 Jam Select the location of your
original document, finish your job
without further scanning, restart
scanning, or cancel the job and
clear the message.
200–202 Jams
1
Open Door A by pushing the release latch and
lowering the door.
CAUTION:
The inside of the MFP might be hot.
2
Pull the print media up and toward you.
Warning: If the print media does not move
immediately when you pull, stop
pulling. Push down and pull the
green lever to make it easier to
remove the media. Make sure all
paper fragments are removed.
3
Close Door A.
4
Touch Continue.
