NETGEAR WNDRMAC Installation Manual

N600 Wireless Dual Band Gigabit Router
WNDRMAC
Package Contents:
Ethernet Cable
N600 Wireless Router
Slide-on
Power Adapter
Router Stand
Attach the STAND to the ROUTER:
1. Place the stand on a level surface.
2. Slide the router onto the stand.
Step 1:
Installation Guide
Unplug the power
to turn off your MODEM.
Internet
Step 4:
Connect the power adapter to the
ROUTER, then plug it into an outlet.
Wait for the WLAN LED (
to turn on.
If none of the LEDs turn on, make sure the
Power On/Off button is in the ON position
(pushed in).
Step 2:
Connect one end of the yellow
ethernet cable (
and the other end to the Internet port.
N600 Wireless Router
DSL
or Cable
Modem
Step 5:
Connect the ROUTER
to your computer (
)
Use another ethernet cable to establish
a wired connection as shown in this diagram.
Optionally, connect wirelessly by using the
preconfigured wireless security settings
located on the bottom label.
Step 3:
Plug in, then turn on your MODEM.
) to your MODEM,
Wait approximately 2 minutes
until your modem turns on.
If your modem has a battery backup,
first remove and reinsert the battery
before connecting your
modem to power.
(not included)
Step 6:
Open a browser.
).
If the web page doesn't display,
close and re-open the browser to
http://routerlogin.net
address bar, or check the
"Troubleshooting" section on
the back of this installation guide.
Laptop or Desktop
Computer
in the
