Hedge Clipper
Operator's Manual
MODELS:
HC-1500
HC-1500 - Type 2E
HC-1600
HC-1600 - Type 1E
HC-2000
HC-2000 - Type 1E
HC-2400
HC-2410
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation.
X7502248103
Serial Number 001001 - 999999
Serial Number 001001 - 672900
Serial Number 001001 - 999999
Serial Number 001001 - 526700
Serial Number 001001 - 999999
Serial Number 001001 - 523200
Serial Number 001001 - 999999
Serial Number 001001 - 999999
WARNING
WARNING
The engine exhaust from this
product contains chemicals known
to the State of California to cause
cancer, birth defects or other
reproductive harm.
DANGER
89861105635
12/00
Advertisement
Table of Contents
Related Manuals for Echo HC-2410
Summary of Contents for Echo HC-2410
-
Page 1: Hedge Clipper
HC-2000 - Type 1E HC-2400 HC-2410 WARNING Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X7502248103 Serial Number 001001 - 999999... - Page 3 Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.
-
