Hedge Clipper
Operator's Manual
MODEL
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation.
X7532240101
HC-201
Serial Number 02001001 - 02999999
WARNING
DANGER
X753000071
12/01
Advertisement
Table of Contents
Related Manuals for Echo HC-201
Summary of Contents for Echo HC-201
-
Page 1: Hedge Clipper
MODEL HC-201 Serial Number 02001001 - 02999999 WARNING DANGER Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X753000071 X7532240101... -
Page 2: Table Of Contents
NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operations tips and SAFETY messages. -
Page 3: Manual Safety Symbols And Important Information
Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. -
Page 4: International Symbols
Wear sturdy work shoes with nonskid soles; of machine vibration to your hands. • DO NOT WEAR OPEN TOED SHOES, • DO NOT OPERATE UNIT BAREFOOTED. Hearing Protection Wear no-slip, heavy duty work gloves. Wear hearing protection. ECHO recommends wearing hearing protection whenever unit is used. -
Page 5: Extended Operation/Extreme Conditions
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combi- nation. ECHO, INC. will not be responsible for the failure of cutting devices, attachments, or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual. -
Page 6: Safe Operation
SAFE OPERATION WARNING DANGER Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. Provide all users of this equipment with the Operator's Manual and instructions for Safe Operation. Keep a Solid Stance •... -
Page 7: Description
The ECHO product you purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. - Page 8 16. SAFETY VIDEO - (Not included with unit) P/N 99922202800 English version only is available at a cost of $5.00 from ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions and proper operating tech- niques and is supplemental to the Safety Manual. Read and understand the Safety Manual for complete information...
-
Page 9: Specifications
EDGE LIPPER PERATOR ANUAL PECIFICATIONS . t i . l f i r t SSEMBLY This model is factory assembled. -
Page 10: Pre-Operation
ISO-L-EGD and J.A.S.O. FC • Wipe any spilled fuel from the unit. certified oil, such as Echo Premium 50:1 Two-stroke Oil, will void the • Move at least 3 m (10 ft.) from refueling two-stroke engine warranty. -
Page 11: Operation
EDGE LIPPER PERATOR ANUAL PERATION NOTE The blade cover is used for transportation and storage. Remove blade cover before using unit. NOTE Refer to the Hedge Clipper Safety Manual for additional proper and safe Trimming Techniques. STARTING COLD ENGINE 1. Stop Switch Move stop switch (A) away from the STOP position. -
Page 12: Starting Warm Engine
The blades should not move at idle. If blades move, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. 6. After engine warm up, gradually depress throttle trigger to increase engine RPM to operating speed. -
Page 13: Stopping Engine
WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using hedge clipper again. HEDGE TRIMMING NOTE This unit is designed to cut shrubs and hedges with branches no larger than 6 mm (1/4 in.) in diameter. -
Page 14: Maintenance
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR- SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Service Dealer for repairs. -
Page 15: Air Filter
EDGE LIPPER PERATOR ANUAL AIR FILTER Level 1. Tools required: 25 or 50 mm (1 or 2 in.) medium bristle paint brush Parts required: 90008 REPOWER AIR & FUEL FILTER KIT 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. -
Page 16: Spark Plug
SPARK PLUG Level 2. Tools required: T-wrench, Feeler gauge, Soft metal brush Parts required: 90064 REPOWER 1. Remove spark plug and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean. - Page 17 The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service.
-
Page 18: Exhaust System
Idle speed can be adjusted as required. High Altitude Adjustment High altitude adjustment is not required for proper operation of this engine. Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). Parts required: None. - Page 19 Accelerate to full throttle to check for smooth transition from idle to full throttle. If engine stops or stalls after full warm up return the unit to your authorized ECHO dealer for repair. 6. Check HI speed RPM at W.O.T. (Wide Open Throttle). HI speed RPM should be set to specifications found on page 9 "Specifica-...
-
Page 20: Lubrication
Wipe excess oil from the blade before putting the unit back in service. Gear Box Assembly Level 2. Tools required: 13 mm Open End Wrench, Grease Gun, Clean Rag Parts Required: Gear Box Gasket, P/N 61041405360, ECHO LUBE (P/N 91015) or Lithium Based Grease. ®... -
Page 21: Sharpening Blades
4. Loosen blade bolt 1/2 turn then install locknut while holding blade bolt in place. 5. Lubricate blades. See "Blade Lubrication Instructions," on page 20. IMPORTANT Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise premature wear or internal damage may occur. -
Page 22: Troubleshooting
ROUBLESHOOTING r o t r o t i a r i l l r o t r e l i l y i l y r o t r e l f f u r e l h t i r u t r / n r i a... -
Page 23: Storage
EDGE LIPPER PERATOR ANUAL TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: Store unit in a dry, dust free place, out of the reach of children. -
Page 24: Servicing Information
• Sending a check or money order for $2.00 per Parts Catalog or $1.50 per Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper the model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address below.
