Hunter 21732 Parts Manual

Hardware
(Drawn to Scale)
x 1
x 2
x 4
x 2
x 3
x 4
x 1
x 4
x 11
x 16
x 16
Balancing
x 1
Kit
x 3
Wire
x 4
Connector
x 3
Low Profile
Washer
3" Wood Screw
Flat Washer
Hanger
Bracket
Assembly
1.5" Wood Screw
Low Profile
Screw
Canopy Screw
Setscrew
Mounting Isolator
Screw, Blade
Iron Armature
Screw, Blade
Blade
Assembly
Assembly
Blade
Grommet
Screw, Switch
Housing Assembly
Switch
Housing
Screw,
Assembly
Machine, 6-32
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model # 21732

Parts List

Asm. Dwg. # 99111-01
Finish New Bronze
Item Name Qnty
Hanger Bracket Assembly 1 96759-30
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Low Profile Washer
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
Screw, Low Profile
Switch Housing Assembly 1 99168-30
Blade Iron Set 1 93301-05
Blade Set 1 G0761-21
Light Kit Assembly 1 84678-01
Hardware Kit 1 99111-00-860
Screw, Blade Iron Armature
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Balancing Kit 1 65666-01
Globe/Shade 1 84886-13
Bottom Cap 1 63987-05
Finial 1 07613-01
Switch Housing Cover 1 73853-01
Switch Housing Plug Button 1 73854-01
Dummy Terminal, Male 1 08198-00
Dummy Terminal, Female 1 08200-00
Pull Chain 1 63756-18
Pull Chain 2 63756-26
Pull Chain Pendant 2 74393-08
Light bulb / Bulb 2 65753-01
