EAW Subwoofer DCT1 Specifications

FEATURES
• Dedicated supertweeter array
• Four high frequency compression tweeters
• 360° (H) dispersion suspended directly overhead
DESCRIPTION
The DCT1 is engineered for use inpermanent installations. The
system mounts four horn-loaded 1.33-in exit compression
tweeters in an inverted pyramid enclosure. The driver/phase
plug assemblies are engineered to minimize beaming of
soundwaves with the smallest wavelengths, particularly in the
horizontal plane.
APPLICATION
The DCT1's inverted pyramid configuration delivers optimized
360° horizontal dispersion of high frequencies when suspend-
ed directly overhead. It provides very high levels of high fre-
quency sound reinforcement for high energy dance clubs.
Like all EAW products, it can be special ordered in virtually any
color to match a specific décor. Six year warranty.
PERFORMANCE
Frequency Response
±3 dB 5 kHz to 15 kHz
-10 dB 4.5 kHz
Axial Sensitivity (dB SPL, 1 watt @ 1 m)
HF 110
Nominal Input Impedance (ohms)
HF 32
Power Handling (watts, continuous)
HF 100
Recommended High-Pass Frequency
24 dB/octave 5 kHz
Calculated Output Limit (dB SPL @ 1 m)
HF Peak 136
HF Long Term 130
Nominal Beamwidth (degrees @ -6 dB SPL)
Horizontal 360
Vertical 45
One Main Street, Whitinsville, MA 01588
EAW products are continually improved. All specifications are therefore subject to change without notice.
Dimensions
Weights
508 234 6158 Toll Free 800 992 5013
SPECIFICATIONS DCT1
PHYSICAL
Product Group Avalon
Configuration Dedicated VHF
VHF Subsystem 4x 1.33-in compression tweeters,
Enclosure Material Exterior-grade Baltic birch plywood
Finish Wear-resistant textured black paint
Connectors 2x Neutrik NL4 Speakon
Suspension Hardware 4x 1/4"-20 threaded mounting
Height 9.0
Width 12.0
Depth 12.0
Baffle Angle 50°
Net Weight 22
Shipping Weight 28
FAX 508 234 8251
DCT1/2 pp
horn-loaded
points (4 top)
inches millimeters
229
305
305
pounds kilograms
10.0
12.7
info@eaw.com www.eaw.com
October 2001 Printed in USA
