EAW ASR695e Dimensions

NOTES:

1. SYMBOL INDICATES MOUNTING
POINT, 3/8-16 THREADED HOLE
(PI ANGLE).
2. SYMBOL INDICATES MOUNTING
POINT, 3/8-16 THREADED HOLE
(NUT PLATE).
3. SYMBOL INDICATES CENTER OF
BALANCE.
4. WEIGHT APPROX. 165 LBS.
5. SHIPPING WEIGHT APPROX. 180 LBS.
17.38
C L
10.50
10.75

LEFT SIDE

DIMENSIONS APPLY
TO BOTH SIDES
10.75
TOP/BOTTOM
3.00
18.60
22.50
GRILLE PARTIALLY SHOWN
(1.95)
FRONT
37.82
L C
17.38
3.00
41.50
5.00
6.75
22.50
ASR695e
7.38
4.00
C
L
ACCESS PANEL
BACK
PRODUCTION
(1.50)
L C
19.50
EASTERN ACOUSTIC WORKS
