NEC X463UN-TMX4P Short Manual

(46") ultra-narrow 2x2 tilematrix video wall solution - digital
Hide thumbs

Advertisement

Quick Links

QIG-TMXP-46UN
X463UN-TMX4P
Parts List
o (4) X463UN Displays
o (4) Overnight Onsite Service Warranties (OnSiteOn-46)
o (4) Peerless Pullout Wall Mount (DS-VW765-LAND)
o (2) Peerless Video Wall Spacers (DW-VWS013)
o (4) 2m DVI-D to DVI-D M/M cables
o (1) 5m DVI-D to DVI-D M/M cable
o (3) 10ft Null Modem to Null Modem F/F cables
o (1) IR/Remote Control Kit (KT-RC)
o (2) Overframe Bezel Kits (KT-46UN-OF2)
o (2) Tripp Lite 6 Outlet Strip (ISOBar6)
NOTES:
Any walls that this video wall solution is anchored to must be strong enough to support the displays and the
o
installation must be in accordance with any local building codes. All mounting apparatuses must make secure
contact to wooden studs.
Please read entire document before starting installation
o
NEC Display Solutions of America, Inc.
Rev 1.0
