Tascam HD-R1 Release Note

Contents

Updates

............................................................... 1

New functions

.................................................... 1

V1.10 additions ....................................................................................................1

V1.01 Additions ....................................................................................................2
Maintenance Items
V1.10 Changes ......................................................................................................2
V1.01 Changes ......................................................................................................3
Updates
Always use the most recent firmware for this device.
Please visit the TASCAM web site at http://www.tascam.
com to check for the latest firmware.
New functions
V1.10 additions
< Web Server Based Control function added.
A browser on a computer connected to the unit by LAN
(Ethernet) can be used to send transport commands
and to edit various settings.
NOTE
•
The only browsers that can be used at this time are
Internet Explorer 7 and 8, Firefox 3.5.6 or later and
Safari.
•
Network settings cannot be changed from the browser.
< The internal clock can be synchronized with an SNTP
server via the Internet.
NOTE
•
An Internet connection is necessary to use this
function.
•
Take care when connecting the HD-R1 to a network
that is route-able from the public internet. Telnet
access requires no password, so the HD-R1 can be
controlled at any time by anyone who knows the IP
address.
•
The Daylight Saving Time function is only for North
America.
•
Restarting the unit is necessary after turning this
function on or off.
< Playback from USB memory has been added.
NOTE
•
Recording to USB memory is not supported. Even
if the "Media Speed Check" result is "Ok"
could occur during writing, which would stop
recording.
•
Use of a USB hub is not supported.
•
The USB memory must be formatted as FAT32 (or
FAT16 if less than 2 GB).
< Login is no longer required for serial control.
D01140220A
........................................... 2
delays
,
HD-R1
Release Notes
Known Issues
..................................................... 3
V1.01 ..............................................................................................................................3
Checking The Firmware Version
Firmware Update Procedures
< Parts of the menu structure have been altered due to
the addition of USB and SMTP client functions.
< Serial control commands have been added.
•
track name command:
You can designate a track name. This command only
works when the unit is stopped.
This only works for tracks that are in the currently loaded
media. Moreover, the full directory path of the track
name, excluding the media name, must be used.
When the "Playback mode"
this function only works with tracks in the currently
designated folder. The full path must be used in this
case as well. Example:
track name=AUDIO01¥TRACK001.WAV
Use a Query to show the current track name. (track name?)
•
delete track command:
Use this command to delete the designated track. You must
reenter this command within 60 seconds for confirmation.
Examples:
delete track=USB:Track01.wav
delete track=CF:audio¥Track023.mp3
•
media command:
Use this command to change the active media. This
function only works when the unit is stopped. Examples:
media=usb
media=cf
Use a Query to show the current media name. (media?)
•
format media command:
Use this command to reformat the designated media.
You must reenter this command within 60 seconds for
confirmation. Examples:
format media=usb
format media=cf
•
location command:
Use this command to designate the time at which the
current track should start playback. Example:
location=1 : 00 : 00. 00
....................... 3
.......................... 4
is "Folder" or "Single" ,
1
TASCAM HD-R1
