Duracell Coppertop MN1604 Specification Sheet

17.5
15.5
12.95
12.45
26.5
24.5
– +
( ) ( )
46.4 mm
MAX.
Dimensions shown are IEC/ANSI standards
Berkshire Corporate Park Berkshire Corporate Park Berkshire Corporate Park Berkshire Corporate Park
Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A.
Telephone: Toll-free 1-800-544-5454 Telephone: Toll-free 1-800-544-5454
Internet: www.duracell Internet: www. duracell.com .com
* *
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
MN1604_US_CT.PDF
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
Page 1 of 2
mm
mm
mm
48.5
mm
46.5
Alkaline-Manganese Dioxide Battery
Nominal Voltage:
Operating Voltage:
Impedance:
Typical Weight:
Typical Volume:
Terminals:
Storage Temperature
Range:
Operating Temperature
Range:
ANSI:
IEC:
TYPICAL DISCHARGE CHARACTERISTICS AT 21
9.5
8.5
7.5
6.5
5.5
4.5
0 10 20 30
MN1604
Size: 9V (6LR61)
9 V
9.6 - 4.8 V
1,700 m-ohm @ 1kHz
45 gm (1.6 oz.)
22.8 cm 3 (1.4 in. 3 )
Miniature Snap
o o
-20 C to 35 C
o o
-20 C to 54 C
o o
(-4 F to 130 F)
1604A
6LR61
°
40 50 60 70 80
Service Hours
°
C (70 F)
100 OHM
200 OHM
500 OHM
1000 OHM
90 100
6/08
