Duracell Alkaline-Manganese Dioxide Battery MX2400 Specification Sheet

10.5
0.8 mm
MIN.
3.8 mm
Max
+
( )
44.5
43.5
–
( )
Dimensions shown are ANSI standards
Berkshire Corporate Park Berkshire Corporate Park Berkshire Corporate Park Berkshire Corporate Park
Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A. Bethel, CT 06801 U.S.A.
Telephone: Toll-free 1-800-544-5454 Telephone: Toll-free 1-800-544-5454 Telephone: Toll-free 1-800 Telephone: Toll-free 1-800
Internet: www. Internet: www.duracell duracell .com .com
* *
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
mm
9.5
mm
TYPICAL DISCHARGE CHARACTERISTICS AT VARIOUS POWER DRAINS
TYPICAL DISCHARGE CHARACTERISTICS AT VARIOUS POWER DRAINS
Alkaline-Manganese Dioxide Battery
Nominal Voltage:
Operating Voltage
Impedance:
Typical Weight:
Typical Volume:
Terminals:
Storage Temperature
Range:
Operating Temperature
Range:
ANSI:
IEC:
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0 0.5 1 1.5
Service Hours
MX2400
Size: AAA (LR03)
1.5 V
1.6 - 0.75V
114 m-ohm @ 1kHz
11 gm (0.4 oz.)
3.5 cm 3 (0.2 in. 3 )
Flat
o o
C
-20 C to 35
o o
-20 C to 54 C
o o
(-4 F to 130 F)
24A
LR03
1.00 W
0.75 W
0.50 W
0.25 W
2 2.5 3 3.5 4
Temp: 21°C (70°F)
4.5
6/08
