  • Page 1: Table Of Contents

    NS-IW960 HOME CINEMA IN-WALL SPEAKER CONTENTS CONSUMER PRECAUTIONS ................UNPACKING ...................... TOOLS NEEDED ....................SPEAKER PLACEMENT ..................INSTALLATION ....................CONNECTIONS ....................PAINTING THE SPEAKER FRAME AND GRILL ..........SPECIFICATIONS ....................WARRANTY ..................Back cover OWNER’S MANUAL...

  • Page 2: Consumer Precautions

    Anytime you note distortion, reduce the volume control on your power amplifier/receiver to a lower setting. Never allow your power amplifier to be driven into “clipping”. • Secure placement or installation is the owner’s responsibility. YAMAHA shall not be liable for any accident caused by improper placement or installation of speakers. WARNING: Installation shall be in accordance with the applicable section of the National Electrical Code, ANSI/NFPA 70, and/or the National Fire Alarm Code, ANSI/NFPA 72, as applicable.

  • Page 3: Unpacking

    UNPACKING After unpacking, check that the following items are contained. 7-11/16” 3-17/32” 6-23/32” aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa TEMPLATE aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa...

  • Page 4: Installation

    INSTALLATION Before installation, check to ensure that the area you are installing the speaker is free of any wall studs, by tapping the wall or using a stud finder. If you wish to paint the speaker frame and grill, please refer to page 7 “PAINTING THE SPEAKER FRAME AND GRILL”...
  • Page 5 Connect the speaker cable to Attach the grill to the frame. the speaker and your receiver. Please refer to page 6, “CONNECTIONS” section for detailed instructions. aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaa...

  • Page 6: Connections

    CONNECTIONS • Connect the push-type input terminals at the rear of the speakers to the speaker output terminals of the receiver. • Connect the (+) terminals on the receiver and speakers using the corresponding side of the cable. Connect the (−) terminals on both components using the other side of the cable. NS-IW960 Receiver + −...

  • Page 7: Painting The Speaker Frame And Grill

    PAINTING THE SPEAKER FRAME AND GRILL The speaker frame and grill can be painted to match your room décor. Use high quality spray paint and select a well ventilated area before proceeding. Painting the frame Painting the grill • • 1 Remove the speaker from the wall if it is already Carefully remove the grill from the speaker, if installed.

  • Page 8: Warranty

    (6) Labor & materials required to remove and reinstall the loudspeaker. (7) Any unit which has not been purchased by the consumer directly from an authorized YAMAHA dealer in the USA or Puerto Rico. If you are uncertain as to whether a dealer has been authorized by YAMAHA, please contact YAMAHA at the telephone number shown below.
