SERVICE MANUAL

MODEL
..............
VPD-MX10
DEST.
.........
WORLD
MODEL
..............
RM-PJM11
DEST.
.........
WORLD
DATA PROJECTOR

Advertisement

Table of Contents
loading

Related Manuals for Sony VPD-MX10

Summary of Contents for Sony VPD-MX10

  • Page 1: Service Manual

    SERVICE MANUAL MODEL MODEL DEST. DEST..........VPD-MX10 RM-PJM11 WORLD WORLD DATA PROJECTOR...
  • Page 2 LES SCHÉMAS DE PRINCIPE, LES VUES EXPLOSÉES ET LES CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO- LISTES DE PIECES SONT D’UNE IMPORTANCE CRITIQUE NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR POUR LA SÉCURITÉ DU FONCTIONNEMENT. NE LES AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- REMPLACER QUE PAR DES COMPOSANTS SONY DONT LE LISHED BY SONY.
  • Page 3 For the customers in the Netherlands Voor de klanten in Nederland •Gooi de batterij niet weg, maar lever hem in als KCA.

  • Page 5: Table Of Contents

    White Balance Adjustment ................. 2-2 2-3-1. White Balance Adjustment of INPUT-A ........2-2 2-3-2. White Balance Adjustment of VIDEO ........2-2 2-4. Memory ....................... 2-3 2-5. Adjustment Item Initialize Data ..............2-4 3. Semiconductors IC ......................... 3-1 Transistor ..................... 3-3 Diode ......................3-4 VPD-MX10...
  • Page 6 Frame Schematic Diagram ................6-1 6-2. Schematic Diagrams and Printed Wiring Boards ........6-3 Schematic Diagrams ......................6-5 ....................... 6-12 ....................... 6-22 ....................... 6-23 ....................... 6-24 ....................... 6-24 Printed Wiring Boards ......................6-4 ....................... 6-10 ....................... 6-22 ....................... 6-22 ....................... 6-24 ....................... 6-24 VPD-MX10...

  • Page 7: Service Informations

    Section 1 Service Informations 1-1. Board Layout Lamp power Power block VPD-MX10...

  • Page 8: Disassembly And Extension Boards

    1-2. Disassembly and Extension Boards 1-2-1. Top Cover and H Board Removal 2 Top cover assy 7 Key control 6 Key power 5 H board 3 Two screws (H) 4 Four screws (H) 1 Shaft VPD-MX10...

  • Page 9: 1-2-2.Bb Board Removal

    (+B2.6 x 4) CN1012 CN1003 CN1000 CN1013 CN1004 CN1014 CN1010 CN1005 CN1008 2 BB board CN1001 1-2-3. B Block (BC and BA boards) Removal 3 Two screws (+B2.6 x 4) 4 B block assy 2 Connector screws 1 Connector cover VPD-MX10...

  • Page 10: Bc Board Removal

    1 Screw (+B2.6 x 4) 1-2-5. BA Board Removal * Remove the B Block. (Refer to Sec.1-2-3.) * Remove the BC Board. (Refer to Sec.1-2-4.) B block holder 2 BA board Sheet (B) assy 1 Two screws (+B2.6 x 4) VPD-MX10...

  • Page 11: 1-2-6.Power Block Removal

    2 Two screws (+B2.6 x 4) 3 Power block 1 AC holder 4 Seet (G) 1-2-7. QA Board Removal * Remove the B Block. (Refer to Sec.1-2-3.) 2 Screw (+B2.6 x 4) CN1101 3 QA board 1 Two connector screws VPD-MX10...

  • Page 12: 1-2-8.Lamp Power Block Removal

    1-2-9. NF Board Removal 7 Two screrws (+BVTP 3 x 6) 4 Screw (+B 2.6 x 4) CN870 5 Slit (F) 8 NF board 2 Screw (+B 2.6 x 4) 6 Front panel 3 Screw (+B 2.6 x 4) 1 Front cover VPD-MX10...

  • Page 13: 1-2-10.Extension Boards And Extension Cables Connection

    (A-1391-140-A) (A-1391-141-A) XB Board : A-1400-239-A Flexible Cable(50P) : 1-900-258-22 Two Screws(+B2.6 x 4) CN1002 Cable (5pin) CN901 BB Board X5 Board Cable XA-XB (50pin) Cable (12pin) X4 Board XB Board XA Board XB Board XA Board BA Board VPD-MX10...

  • Page 14: Power Cord

    C7-2 YC-13L Cord type SPT-2 H03VVH2-F H03VVH2-F H03VVH2-F VCTFK Rated Voltage & Current 10 A/125 V 2.5 A/250 V 2.5 A/250 V 2.5 A/250 V 7 A/125 V Safety approval UL/CSA DENAN 1)Use the correct Plug for your country. VPD-MX10...

  • Page 15: Electrical Adjustments

    8. Select the item 08 YUV COL. Use the key , or PAL 100% Color bar both, to adjust level of two color bars, the left and right Fig. 2-2-2 end so that they will come to the same level. VPD-MX10...

  • Page 16: White Balance Adjustment

    5. BIAS G and B in the HIGH Mode of W/B an adjusted so that the chromaticity (x, y) may become the follow- ing standard value. Standard value (x, y) = (xlow ±0.002, ylow ± 0.004) 6. Set the INPUT signal to the 80 IRE. VPD-MX10...

  • Page 17: Memory

    HIGH HIGH HIGH Memory Memory Memory HIGH HIGH Non Reverse upside down Non Reverse upside down Installation Memory Installation Installation Memory Memory Reverse upside down Reverse upside down CPU ROM External NVM CPU RAM Initialize Memory Active memory copy VPD-MX10...

  • Page 18: Adjustment Item Initialize Data

    : “DOT PHASE, SIZE H, SHIFT H/V, SCAN CONV, ASPECT and BLANKING” in the “INPUT SETTING” menu have an initial value respectively in accordance with the input signal (PRESET MEMORY No.). Note : There are nonadjustable items in accordance with the input signal. VPD-MX10...
  • Page 19 MemoryName Remarks STATUS W/B MEMORY MEMORY VIDEO- VIDEO-LOW RGB-HIGH RGB-LOW HIGH 15 (*) ON (*) 4:3 (*) 0 (*) VPD-MX10...
  • Page 20 SID LVL Fixed Value PRG LVL Fixed Value INSTALLATION Fixed Value SC FILTER Fixed Value BD ENABLE Fixed Value WHITE PEAKING Fixed Value Fixed Value DMD BIN Note : There are nonadjustable items in accordance with the input signal. VPD-MX10...
  • Page 21 Fixed Value impossible Adjustment is LAMP FAN 2 Fixed Value impossible Adjustment is PANEL FAN 2 Fixed Value impossible SYNCHRONOUS Fixed Value GAMMA Factory default setting value Note : There are nonadjustable items in accordance with the input signal. VPD-MX10...

  • Page 23: Semiconductors

    TC7S14FU(TE85R) TC7SET08FU(TE85R) TC7SZ05(TE85L) TC7SZ126(TE85L) TOP VIEW 16PIN SOP TOP VIEW BOTTOM VIEW 144PIN PGA 54PIN TSOP 74VHC02MTCX 74VHC125MTCX BA10339FV BA10339FV-E2 CXA2101AQ M52758FP HD64F2633 TC74LCX125FT CXA2101AQ-TL HD64F2633TE TC74LCX125FT(EL) TOP VIEW TOP VIEW TOP VIEW 14PIN SOP TOP VIEW 36PIN SOP VPD-MX10...
  • Page 24 PQ2TZ15U S-80828ANNP S-80828ANNP-EDR-T2 S-80842ANNP S-80842ANNP-ED6 S-80842ANNP-ED6-T2 TOP VIEW 4PIN CHIP PW365-10U TA78M09F(TE16L) TOP VIEW RCV4-A1T-MASK-25 ST72T631K4M41-201 THC63DV151 TOP VIEW TOP VIEW 34PIN SOP 100PIN QFP RS-140-T VPD-MX10...

  • Page 25: Transistor

    Transistor HN1B01FU-T 2SA1162 HN1B01FU-TE85R 2SA1162-G HN1C01FU-TE85R 2SA1162-YG-TE85L 2SA1611 2SA1611-M5M6 2SA1611T1-M5M6 2SC2712 2SC2712-YG-TE85L DTC114EK DTC144EKA-T146 DTC144EUA DTC144EUA-T10 VPD-MX10...

  • Page 26: Diode

    Diode DAN202K HN1D03FU-TE85 UMZ6.8M 1SS226 DAN202K-T-146 HN1D03FU-TE85L UMZ6.8M-T106 HN1D03FU-TE85R DAP202K-T-146 1SS355 DAP202U 1SS355TE-17 DTZ2.4B-TT11 SEC1901C MA111-(K8).S0 SEC2422C MA111-TX RD5.6SB-T1SB2 CATHODE MARK RD9.1SB2 RD9.1SB2-T1 UDZSTE-173.9B UDZ-TE-17-3.9B UDZS-TE17-5.6B ANODE CATHODE VPD-MX10...

  • Page 27: Spare Parts

    Ne les remplacer que par une pièce portant le numéro spécifié. 2. Standardization of Parts Some repair parts supplied by Sony differ from those used for the unit. These are because of parts common- ality and improvement. Parts List has the present standardized repair parts.

  • Page 28: Exploded Views

    X-4039-660-1 s GRIP (TOP) ASSY Screws 7-685-645-14 s SCREW +BVTP 3X6 TYPE2 SLIT 4-085-993-01 s KEY, CONTROL 7-621-773-86 s SCREW +B 2.6X4 4-086-007-01 s KEY, POWER A-1375-228-A s MOUNTED CIRCUIT BOARD, H 4-086-212-01 s SCREW (H) 4-085-981-01 o HOLDER, SPEAKER VPD-MX10...

  • Page 29: Chassis 1

    ! 1-468-635-12 s POWER BLOCK (WITH MOUNT) 7-682-552-09 s SCREW +B 3X16 7-682-545-04 s SCREW +B 3X4 4-085-983-01 o CUSHION (BB) 1-900-262-62 o CONNECTOR ASSY 12P A-1136-260-A s MOUNTED CIRCUIT BOARD, BB A-1136-259-A s MOUNTED CIRCUIT BOARD, BA X-4039-665-1 o SHEET (B) ASSY VPD-MX10...

  • Page 30: Chassis 2

    1-900-265-11 o CONNECTOR ASSY 14P 4-086-711-01 o HOLDER (QA) 1-763-676-11 s FAN, DC 4-086-107-01 s MASK DMD (A), FAN Screws 4-086-001-01 o BRACKET, DMD FAN 7-682-547-04 s SCREW +B 3X6 7-682-553-09 s SCREW +B 3X20 7-685-645-14 s SCREW +BVTP 3X6 TYPE2 SLIT VPD-MX10...

  • Page 31: Optical Unit

    9-885-019-46 s WHEEL SENSOR SCREW 7-621-772-20 s SCREW +B 2.6X5 9-885-019-45 s COLOR WHEEL UNIT 7-621-772-40 s SCREW +B 2X8 9-885-019-37 s DMD SET(XGA) 7-621-772-50 s SCREW +B 2X10 7-682-247-09 s SCREW +K 3X6 7-682-547-09 s SCREW +B 3X6 VPD-MX10...

  • Page 32: Electrical Parts List

    1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C335 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C336 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V C247 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C337 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V C248 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C338 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V VPD-MX10...
  • Page 33 8-719-158-37 s DIODE RD9.1SB2 L301 1-414-754-11 s INDUCTOR 10.0UH L302 1-414-754-11 s INDUCTOR 10.0UH D201 8-719-914-43 s DIODE DAN202K L303 1-414-754-11 s INDUCTOR 10.0UH D300 8-719-914-43 s DIODE DAN202K D401 8-719-058-24 s DIODE RB501V-40TE17 L501 1-412-028-11 s INDUCTOR,CHIP 4.7UH (3225) VPD-MX10...
  • Page 34 1-216-818-11 s RESISTOR, CHIP 560 1/16W 1608 R301 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 R206 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) R302 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 R207 1-216-827-11 s RESISTOR, CHIP 3.3K 1/16W 1608 R303 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 VPD-MX10...
  • Page 35 1-216-799-11 s RESISTOR, CHIP 15 1/16W 1608 R435 1-216-799-11 s RESISTOR, CHIP 15 1/16W 1608 R436 1-216-835-11 s RESISTOR,CHIP 15K 1/16W R437 1-216-835-11 s RESISTOR,CHIP 15K 1/16W R438 1-216-835-11 s RESISTOR,CHIP 15K 1/16W R439 1-216-835-11 s RESISTOR,CHIP 15K 1/16W R440 1-216-835-11 s RESISTOR,CHIP 15K 1/16W VPD-MX10...
  • Page 36 1-165-176-11 s CAPACITOR,CERAMIC 47000PF/16V C423 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C424 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 C310 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C425 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C311 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C426 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 4-10 VPD-MX10...
  • Page 37 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C625 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C921 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C626 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C922 1-109-982-11 s CAPACITOR,CHIP CERAMIC 1MF/10V C627 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C1000 1-163-251-11 s CAPACITOR CERAMIC 100PF/50V 4-11 VPD-MX10...
  • Page 38 8-759-456-26 s IC 74LCX541MTCX D606 8-719-081-42 s DIODE UMZ6.8N-T106 IC201 8-759-456-26 s IC 74LCX541MTCX D607 8-719-081-42 s DIODE UMZ6.8N-T106 IC202 8-759-456-26 s IC 74LCX541MTCX D608 8-719-083-58 s DIODE UDZSTE-173.9B D901 8-719-024-77 s DIODE HN1D03FU-TE85L IC203 8-759-456-26 s IC 74LCX541MTCX 4-12 VPD-MX10...
  • Page 39 8-759-478-92 s IC TC7SET04FU(TE85R) R139 1-216-821-11 s RESISTOR,CHIP 1.0K 1/16W(1608) IC1601 8-759-831-96 s IC MD2305E R140 1-218-734-11 s RESISTOR,CHIP 56K 1/16W(1608) IC5016 8-759-331-71 s IC NJM4558E (TE2) R142 1-216-827-11 s RESISTOR, CHIP 3.3K 1/16W 1608 R144 1-216-821-11 s RESISTOR,CHIP 1.0K 1/16W(1608) 4-13 VPD-MX10...
  • Page 40 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) R520 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) R351 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R521 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) R352 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) R522 1-216-825-11 s RESISTOR,CHIP 2.2K 1/16W 1608 4-14 VPD-MX10...
  • Page 41 1-216-823-11 s RESISTOR, CHIP 1.5K 1/16W R710 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R643 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) R712 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R644 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R713 1-216-821-11 s RESISTOR,CHIP 1.0K 1/16W(1608) 4-15 VPD-MX10...
  • Page 42 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) R1033 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) R930 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) R1035 1-216-837-11 s RESISTOR,CHIP 22K 1/16W 1608 R931 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) R1055 1-216-837-11 s RESISTOR,CHIP 22K 1/16W 1608 4-16 VPD-MX10...
  • Page 43 1-233-576-11 s RESISTOR,CHIP NETWORK 100 RB902 1-233-412-11 s RESISTOR,CHIP NETWORK 1K RB903 1-233-576-11 s RESISTOR,CHIP NETWORK 100 RB904 1-233-576-11 s RESISTOR,CHIP NETWORK 100 RB905 1-236-908-11 s RESISTOR,NETWORK 10K (3216) RB906 1-233-576-11 s RESISTOR,CHIP NETWORK 100 RB907 1-233-576-11 s RESISTOR,CHIP NETWORK 100 4-17 VPD-MX10...
  • Page 44 8-759-661-55 s IC ST24FC21M6TR 6-701-842-01 s IC THC63DV151 8-759-592-50 s IC TC7SZ126FU(TE85R) J4402 1-779-677-11 s CONNECTOR, USB (B) 1-412-006-31 s CHIP INDUCTOR 10UH (2012) 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 1-216-864-11 s CONDUCTOR, CHIP (1608) 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 4-18 VPD-MX10...
  • Page 45 1-216-864-11 s CONDUCTOR, CHIP (1608) R1112 1-216-864-11 s CONDUCTOR, CHIP (1608) R1113 1-216-049-11 s RESISTOR, CHIP 1K 1/10W(2012) R1114 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 R1115 1-216-817-11 s RESISTOR,CHIP 470 1/16W 1608 R1116 1-216-049-11 s RESISTOR, CHIP 1K 1/10W(2012) 4-19 VPD-MX10...
  • Page 46 4-085-966-01 o OPERATING INSTRUCTIONS (JAPANESE/SIMPLIFIED CHINESE) 4-085-966-11 o OPERATING INSTRUCTIONS (ENGLISH/FRENCH/SPANISH) 4-085-966-21 o OPERATING INSTRUCTIONS (ITALIAN/GERMAN) 4-085-967-01 o OPERATING INSTRUCTIONS (JAPANESE/SIMPLIFIED CHINESE) 4-085-967-11 o OPERATING INSTRUCTIONS (ENGLISH/FRENCH/SPANISH) 4-085-967-21 o OPERATING INSTRUCTIONS (ITALIAN/GERMAN) A-1501-943-B s MS ASSY CORD, POWER (See 1-3.Power Cord) 4-20 VPD-MX10...

  • Page 47: Block Diagrams

    H,QA,BC H,QA,BC Section 5 Block Diagrams H Block QA Block BC Block VPD-MX10...

  • Page 48: Ba Block

    BA Block VPD-MX10...
  • Page 49 BA Block VPD-MX10...

  • Page 50: Bb(1/2) Block

    BB(1/2) BB(1/2) BB(1/2) Block VPD-MX10...

  • Page 51: Nf Block

    BB(1/2),NF BB(1/2),NF NF Block BB(1/2) Block VPD-MX10...
  • Page 52 BB(2/2) BB(2/2) BB(2/2) Block VPD-MX10...

  • Page 53: Diagrams

    Frame(1/2) Frame(1/2) Section 6 Diagrams 6-1. Frame Schematic Diagram VPD-MX10...
  • Page 54 Frame(2/2) Frame(2/2) VPD-MX10...

  • Page 55: Schematic Diagrams And Printed Wiring Boards

    : NONFLAMMABLE CEMENT : NONFLAMMABLE WIREWOUND : ADJUSTMENT RESISTOR COIL LF-8L : MICRO INDUCTOR CAPACITOR : TANTALUM : STYROL : POLYPROPYLENE : MYLAR : METALIZED POLYESTER : METALIZED POLYPROPYLENE : BIPOLAR : HIGH TEMPERATURE : HIGH RIPPLE VPD-MX10...
  • Page 56 C265 GND 4 C203 CN10 LATCH R103 LATCH CONTROL BUFFER R102 JL102 C103 -B SIDE- SHIFT JL103 Q102 REGISTOR JL114 SUFFIX: -11 JL130 JL107 JL115 JL132 JL129 JL116 8dB STEP 1dB STEP VOLUME VOLUME L103 – JL118 JL119 L104 VPD-MX10...
  • Page 57 BA (1/5) BA (1/5) VPD-MX10...
  • Page 58 BA (2/5) BA (2/5) VPD-MX10...
  • Page 59 BA (3/5) BA (3/5) 0.6Vp-p(H) 0.6Vp-p(H) 0.6Vp-p(H) VPD-MX10...
  • Page 60 BA (4/5) BA (4/5) VPD-MX10...
  • Page 61 BA (5/5) BA (5/5) VPD-MX10...
  • Page 62 R1013 JL1005 JL1025 JL1019 R1015 JL1016 D101 JL652 RB605 C603 Q101 JL1015 JL639 JL642 JL640 CN1013 CN1011 CN1012 Q102 R613 JL1007 RB611 JL645 JL637 Q103 JL1001 -B SIDE- RB606 JL638 C602 FB601 JL105 JL104 JL106 SUFFIX: -11 6-10 6-10 VPD-MX10...
  • Page 63 MODE SELECT INPUT PLL CLOCK 20 19 MULTIPLIER AND OUTPUT TC7W32FU (IC612) CLOCK OUT SPREAD BUFFER SPECTRUM LOW EMI CIRCUITRY ENABLE INPUT CRYSTAL OR CLOCK CRYSTAL OUTPUT 7 1Y OSCILLATOR BUFFER GND 4 XSEL OE (BOTH OUTPUTS) 6-11 6-11 VPD-MX10...
  • Page 64 BB (1/10) BB (1/10) 6-12 6-12 VPD-MX10...
  • Page 65 BB (2/10) BB (2/10) 6-13 6-13 VPD-MX10...
  • Page 66 BB (3/10) BB (3/10) 6-14 6-14 VPD-MX10...
  • Page 67 BB (4/10) BB (4/10) 6-15 6-15 VPD-MX10...
  • Page 68 BB (5/10) BB (5/10) 6-16 6-16 VPD-MX10...
  • Page 69 BB (6/10) BB (6/10) 6-17 6-17 VPD-MX10...
  • Page 70 BB (7/10) BB (7/10) 6-18 6-18 VPD-MX10...
  • Page 71 BB (8/10) BB (8/10) 6-19 6-19 VPD-MX10...
  • Page 72 BB (9/10) BB (9/10) 6-20 6-20 VPD-MX10...
  • Page 73 BB (10/10) BB (10/10) 6-21 6-21 VPD-MX10...
  • Page 74 JL809 D811 *F-2 *B-1 SUFFIX: -11 *:B Side mount *:B Side mount 24LC21AT (IC1) GENERATOR MEMORY EEPROM CONTROL CONTROL XDEC VCLK ARRAY LOGIC LOGIC PAGE LATCHES YDEC SENSE AMP R/W CONTROL 1 2 3 NC NC NC 6-22 6-22 VPD-MX10...
  • Page 75 6-23 6-23 VPD-MX10...
  • Page 76 C1102 C1100 C870 C1103 C1101 C1105 R870 R872 R873 R1108 R1106 R1102 R1101 R1107 R1105 CN870 R1110 R1109 R1104 -A SIDE- -B SIDE- SUFFIX: -11 SUFFIX: -11 CN1100 -B SIDE- -A SIDE- JL1110 SUFFIX: -11 SUFFIX: -11 6-24 6-24 VPD-MX10...
  • Page 77 SAFETY CHECK-OUT After correcting the original service problem, perform the following safety checks before releasing the set to the customer : Check the metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to...
  • Page 78 English Sony Corporation 01KY08-1 B&P Company ©2001.11 9-870-319-01...
